Storage and Transportation
Cable tidy system
After use, wrap your extension cable around the cable hooks and secure the plug in place.
To release the extension cable for machine use, just rotate the cable hook .
Handle positions storage
Handle operating Handle - park
position position
Push the lower handle to the right and then rotate forward, make sure the lower handle is out of
the block position. Release the CAM levers and fold the handle down.
Transportation
1. Switch the product off and disconnect it from power supply before transporting it anywhere.
2. Always carry the product by the central carry handle.
3. Protect the product from any heavy impact or strong vibrations which may occur during
transportation in vehicles.
4. Secure the product to prevent it from slipping or falling over.
NOTE! Always carry the product by the central carry handle.
Customer Helpline 01904 727500
12
www.gardenservicecentre.co.uk

Troubleshooting

General Troubleshooting
WARNING! Only perform the steps described within these instructions!
All further inspection, maintenance and repair work must be performed by an authorised service
centre or a similarly qualified specialist if you cannot solve the problem yourself!
Suspected malfunctions, disturbances or damages are often due to causes that the user can
cable clip
fix themself. Therefore check the product using this section. In most cases the problem can be
solved quickly.
Problem
Product does not
start
Product does not
reach full power
Machine not cutting
Machine leaves
ragged finish
Cutting blades not
rotating
Excessive vibration/
noise
Rollers do not rotate

Technical Data

Technical Data Table
WARNING! The vibration emission value during actual use of the tool can differ from the declared
value depending on the ways in which the tool is used. Identify safety measures to protect the
operator that are based on an estimation of exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as the times when the tool is switched off and when
it is running idle in addition to the trigger time).
The sound intensity level for the operator may exceed 85dB(A) and ear protection measures are
necessary.
Possible Cause Solution
1. Not connected to power supply 1. Connect to power supply
2. Power connection is loosen 2.Connect the power supply and tool
well
3. Other electrical defect to the
product
3. Check by a specialist electrician
1. Extension cord not suitable for 1. Use a proper extension cord
operation with this product
2. Connect to another power source
2. Power source (e.g. generator)
has too low voltage
3. Machines internal wiring 3. Contact the customer helpline
damaged
1. Height of cut too low 1. Increase height of cut (See --
Adjusting the cutting height)
2.Blades require adjustment (See—
2. Blades off cut
Adjusting the blades clearance)
1.Cutting blades blunt Blade require adjustment (See-
Adjusting the blades clearance)
1.Cutting blades obstructed 1.Clear obstruction
2.Belt is slipping or is damaged 2.Contact customer helpline
1.Cutting blades damaged 1.Contact customer helpline
2.Cutting blades not adjusted 2.Blades require adjustment(See-
evenly Adjusting the blades clearance)
Roller is blocked by debris Clean all roller slots
