QG-PM 56 S B&S; EX; UK
Petrol Lawn Mower
Komponenten / Ersatzteile
Position
Artikel-Nr.
1
340075202001
3
340075201003
7
340075201007
9
340075201009
10
340075201010
12
340075201012
13
340075201013
14
340075201014
Beschreibung
engine B/S ECO
drive clutch lever
flywheel brake lever (Motorbremse)
hook
nut M8
throttle control assy.
cable unit
cable clamp
Artikel-Nr.: 3400752
Ident-Nr.:
11021
Position
Artikel-Nr.
15
340075201015
25
340075201025
26
340075201026
28
340075201028
32
340075201032
36
340075201036
37
340075201037
43
340075201043
Beschreibung
lower handle
torsion spring
side cover
pivot shaft
rear guard
rear cover
rod for rear cover für Auswurfklappe
V-belt A813

Advertisement

Table of Contents
loading

Related Manuals for Qualcast 56cm Self Propelled Lawnmower

Summary of Contents for Qualcast 56cm Self Propelled Lawnmower

  • Page 1 QG-PM 56 S B&S; EX; UK Artikel-Nr.: 3400752 Petrol Lawn Mower Ident-Nr.: 11021 Komponenten / Ersatzteile Position Artikel-Nr. Beschreibung Position Artikel-Nr. Beschreibung 340075202001 engine B/S ECO 340075201015 lower handle 340075201003 drive clutch lever 340075201025 torsion spring 340075201007 flywheel brake lever (Motorbremse) 340075201026 side cover 340075201009...
  • Page 3 Komponenten / Ersatzteile Position Artikel-Nr. Beschreibung 340075201044 mulch plug 340075201045 side guard 340075201051 hub cap for front wheel für Hinterrad 340075201052 hub cap for rear wheel für Vorderrad 340075201055 Hinterrad 11'x2.5' 340075201061 Vorderrad 8'x2.5' 340075201062 front shaft assembly 340075201077 GT transmission 340075201079 blade connector 340075201081...
  • Page 4 56cm Self Propelled Lawnmower Original Operating Instructions POWERFUL 190CC BRIGGS & STRATTON 625 SERIES PETROL ENGINE Ideal for medium to large gardens ADJUSTABLE AND FOLDING HANDLE Allows for handle to be adjusted for comfort and easy storage 56CM METAL DECK For improved durability and long life 5 CENTRALLY ADJUSTED CUTTING HEIGHTS...

  • Page 5: Technical Data

    Contents Safety Guide Product Diagrams 1 0. Technical Data Assembly Declaration of Conformity Product Guarantee Packaging The unit is supplied in packaging to prevent its being damaged in transit. This packaging is raw material and can therefore be reused or can be returned to the raw material system. Helpline No.
  • Page 6 Preliminary measures Important! When using the equipment, safety precautions must be observed to avoid injuries and damage. 1. Always wear sturdy, non-slip footwear and long Please read the complete operating instructions trousers when mowing. Never mow barefoot or and safety regulations with due care. Keep this in sandals.
  • Page 7 Helpline No. UK 0151 649 1500 / IRE 189 094 6244...
  • Page 8 Helpline No. UK 0151 649 1500 / IRE 189 094 6244...
  • Page 9 Helpline No. UK 0151 649 1500 / IRE 189 094 6244...
  • Page 10 Helpline No. UK 0151 649 1500 / IRE 189 094 6244...
  • Page 11 Handling 16. Never put your hands or feet near or under any rotating parts. Keep clear of the chute opening at all times. 1. Do not let the combustion engine run in enclosed areas, as dangerous carbon 17. Never lift or carry a lawn mower with the monoxide gas can build up.

  • Page 12: Maintenance And Storage

    Maintenance and storage 2. Layout (Fig. 1+2) 1. Make sure that all nuts, bolts and screws are 1. Engine start/stop lever – engine brake tightened securely and that the machine is in 2. Top push bar safe working condition. 3. Handle 2.

  • Page 13: Before Starting The Equipment

    3. Proper operation 4. Technical data The petrol lawn mower is intended for private use Note: The enclosed manual from Briggs & i.e. for use in home and gardening environments. Stratton provides detailed technical data on the engine! Private use of the lawn mower refers an annual operating time generally not exceeding that of Engine type: 50 hours, during which time the machine is...
  • Page 14 Assembly - Pull the adjustor lever out and select the desired cutting height. The lever snaps into the desired position. 1. Take the mower and attachment parts out of the packaging and check that all parts are present (Fig. 2). 6.
  • Page 15 2. Drive lever (clutch lever) (Fig. 5a/Item 18): If you drive; by pulling the Drive lever towards the top press this (Fig. 5c) the clutch for the drive will be push bar (Fig. 5c). Always walk behind the closed and the lawnmower will start to move with lawnmower whist the drive is working.
  • Page 16 5. Exhaust gas is dangerous. Only start the engine Keep the underside of the mower housing clean out in the open. and remove grass build-up. Deposits not only make it more difficult to start the mower; they 6. Make sure that all the guards are fitted and decrease the quality of the cut and make it that they are in good working order.
  • Page 17 7. Pay special attention if you are mowing directly grabbing onto the grass collection bag handle next to a street or are close by one (traffic). Always with the other. Hook on the grass collection bag keep the grass chute pointed away from the from the top.
  • Page 18 running. Any work not described in these mow the lawn with a bent or heavily worn blade Operating Instructions must be performed by an as this will cause vibrations and can lead to further authorized service workshop only. damage to the lawn mower. 7.1 Cleaning Important: There is a risk of injury if you work with a damaged blade.

  • Page 19: Disposal And Recycling

    8. Disposal and recycling IMPORTANT! 7.4 Preparing the mower for transportation The unit is supplied in packaging to prevent its 1. Empty the petrol tank (see item 7.3.1). being damaged in transit. This packaging is raw 2. Always let the engine run until it has used up the material and can therefore be reused or can remainder of petrol in the tank.
  • Page 20 Notes Helpline No. UK 0151 649 1500 / IRE 189 094 6244...
  • Page 21 EÚ a noriem pre výrobok og standarder for artikkel A a cikkekhez az EU-irányvonal és Normák szerint a E Lýsir uppfyllingu EU-reglna og annarra staðla vöru következő konformitást jelenti ki Petrol Lawn Mower QG-PM 56 S B&S (Qualcast) 87/404/EC_2009/105/EC 2006/42/EC Annex IV 2005/32/EC_2009/125/EC...
  • Page 22 GUARANTEE CERTIFICATE Dear Customer, In the unlikely event that your device develops a fault, please contact our Customer service department on the telephone number shown below. 1. These guarantee terms cover additional guarantee rights and do not affect your statutory warranty rights. Claims must be accompanied by Proof of Purchase.
  • Page 23 AFTER SALES SUPPORT UK / IRELAND HELPLINE NO 0151 6491500 REP . IRELAND HELPLINE NO 1890 946244 WEB SUPPORT www.einhell-uk.co.uk MODEL NUMBER: QG-PM 56S B&S MANUFACTURERS ARTICLE NO: 34.007.52...
