Hunter Pro-C Controller Product Information page 30

INSTALLATION AND PROGRAMMING
Run Time
You have the ability to adjust the amount of
time that a station will run once it has been
turned on by your SRR System. This does
not affect the run time programmed into your
controller. This adjustment is made at the
transmitter as described below.
To change the Run Time follow the
steps below:
1. If the unit is OFF (no display), power the
transmitter up by pressing any of the but-
tons for at least 1 second then releasing the
button. The transmitter will first illuminate
the entire display for 1 second then display
the active station.
2. Simultaneously press the
until the word "RUN TIME" along with the
current Run Time is displayed (default is
10 minutes). The display will be blinking
at this point. If more than 5 seconds go by
without a button being pressed, the Trans-
mitter will revert back to displaying the
active station.
3. Use the or buttons to change the Run
Time to any of 8 settings ranging from 1 to
30 minutes. Then do not touch any of the
buttons for 5 seconds and the display will
stop blinking, and return back to the active
station.
Activating a Station with the SRR Remote
Control System
The SRR System will allow you to remotely
turn on and off any station on your Pro-C
controller with the press of a button. Once on,
the station will run for the run time you have
designated in the remote.
To remotely activate a station or program
follow the steps below:
1. Plug the Receiver into an active wiring
harness (one attached to a powered
controller) and wait for 2 beeps indicating
that the Receiver is ready.
2. If your Transmitter is not on (no display),
press any button for at least 1 second
and release. The Transmitter will first
illuminate the entire display, then display
the active station.
28
3. Use the
4. Momentarily press the "ON" button
5. Press the "OFF" button to turn off
and buttons,
Note:
If a sensor device has been wired to
the controller and the rain sensor switch
is in the active position, the SRR remote
will not override the sensor for manual
operation.
Changing the Maximum Station
Number
Your SRR Transmitter comes from
the factory with the maximum station
number set to 9. This means that when
you use the
the station, you may change it to any
number between 1 and 9. However,
if you have a 3 or 6-station Pro-C
controller, you will not need to access
the station numbers above your station
count. Likewise, perhaps you own a 12-station
Pro-C controller, so in this case you will
want to access the stations above 9. The SRR
Transmitter allows you to set the maximum
(continued)
or buttons to display the
station or program you would like to start.
to start the station or program. The
Transmitter will display the word
"TRANSMIT" and will flash for about
4 seconds indicating that it is sending
the command to the Receiver. If you
are near the Receiver, you will hear
it beep 2 times, indicating that it has
received the command.
any station that is on. The display
will again read "TRANSMIT" and
flash, and the Receiver will again beep
twice. The SRR System is designed
to turn one station on at a time.
Therefore, turning a station on while
another station is already on will cause the
first station to turn off.
The SRR remote can activate any station
on the controller whether the controller
dial is in the "System Off", "Run" or any
other position.
and buttons to change
Receiver Unit
Transmitter Unit
