Hunter Hydrawise HPC Quick Start Manual

HPC - Using Hunter Remotes
The HPC face panel quickly and easily upgrades Pro-C® controllers (PC400 models
manufactured since March 2014) to next-generation smart controllers via the Hydrawise
platform. In addition, it lets contractors continue using their Roam and Roam XL remotes
for quick on-site management. HCC is also compatible with Hunter's ROAM and ROAM XL
remotes, allowing for fast and reliable manual operation in the field from long-range
distances without the need for a smartphone. There is no need to remove the smart port
adapter from the controllers when doing a facepack upgrade.
Compatible models include all Hunter remotes: SRR, ICR, ROAM, and the ROAM-XL.
If the Smartport is not installed on the controller, see illustrations below for wiring
instructions.
Note: Any extension of the wiring on the SmartPort may result in an error message in
the controller display and possible malfunction of the remote unit due to radio interference.
In
some situations, lengthening of the harness may work fine, in others it may not work at all
(it is
site specific). In either case, extending the wiring harness should be done using shielded
cable to
minimize the possible effects of electrical noise. For easiest installation, order the Hunter
SmartPort shielded cable wiring harness. (P/N ROAM-SCWH) with a full 25' (7.6 meters)
of
shielded cable.
Wiring
1. Bottom 24 VAC terminal - Red wire
2. Second 24 VAC terminal - White wire
3. Remote terminal - Blue wire
Smart Port Wiring
