Grandstream Networks GXV 3140 Quick Installation Manual

QUIcK
InStallatIon
GUIde
Grandstream GXV 3140

Basic Installation Instructions:

for connecting the GXV-3000 video phone
to the Internet via a router connected to a
cable or DSL modem

Your Start-up Kit should include:

GXV-3140 Main Case
Handset
Phone Cord
Universal Power Adapter
Ethernet Cable
Phone stand
Quick Installation Guide
Installation Guide: Setting Up Your Grandstream GXV 3140
Step 1:
Connect the handset to the phone with the provided phone cord.
Step 2: Connect the WAN port to a switch, router or modem using the Ethernet cable.
Step 3:
Connect the power adapter to the 12V DC input on the back of the phone.
Step 4:
Connect a switch or computer to the LAN port (optional).
For a complete users guide:
Video Phone
(optional)
Computer
http://www.grandstream.com/user_manuals/
1
2
3
1
2
3
