Installing The Module In A 4- Or 8-Slot Chassis - 3Com NETBUILDER II Installation Manual

1-4 C 1: I
HAPTER NSTALLATION
Installing the
Module in a 4- or
8-Slot Chassis
HSS RS-232
3-PORT
® DTE/DCE
J1 (A)
Jumper E2 set for DTE Jumper E1 set for DTE
(corresponds to cable (corresponds to cable
connector J2 (B))
E2
Figure 1-1 Changing the Jumper Settings to Connect to DTE Devices
When cabling one or more of the module ports to a DTE device, you need to attach a
DTE-to-DCE adapter available from 3Com to the connector of each of the three cables
that is to connect to a DTE device. This procedure is described in "Cabling Instructions"
on .
You also must set the -PATH Service CLock parameter from External to Internal for the port
that you are connecting to a DTE device. Refer to the CLock parameter in the "Path Service
Parameters" chapter in the NETBuilder Family Bridge/Router Reference Guide for
instructions.
You can install up to three HSS RS-232 3-Port DTE/DCE modules at a time into a
NETBuilder II 4-Slot chassis and up to seven in an 8-Slot chassis.
You will need a small flat-blade screwdriver.
You can safely install a module without turning off or rebooting the NETBuilder II
system.
To install the module into a NETBuilder II 4- or 8-Slot chassis, follow these steps:
1 Remove the filler panel from the I/O slot you have selected.
You do not need to remove the cable strain-relief bracket that came with your
NETBuilder II chassis.
STATUS
J2 (B)
Jumper E4 off
connector J1 (A))
E1
J3 (C)
Jumper E3 set for DCE
(corresponds to cable
connector J3 (C))
DTE
DCE
E3
