10.11.2004 / Page 4
Doc. No: 4812 722 23187

Spare part list

Model AWO 5963
Service No. 859202715000
Version 859202715000
Pos. No. 12NC Code Description
001 0 4812 440 10784 Cabinet GW
002 0 4812 440 11131 Flap square EBL
011 0 4812 462 48421 Adjust. foot
021 0 4812 440 11132 Front square Flap EBL
024 0 4812 440 18998 Panel, rear
025 0 4812 404 38737 Support EBL
030 0 4812 440 11178 Table top
040 0 4812 417 18787 Hinge
050 0 4812 440 89097 Plinth EBL
061 0 4812 466 88818 Counterweight upper 1600
061 1 4812 466 88819 Counterweight bottom 1600
061 3 4812 094 98006 Mounting kit Weight bottom, 1600
061 4 4812 466 88821 Counterweight front 1600
061 5 4812 094 98007 Mounting kit weight front, 1600
065 2 4812 310 18401 Insulation
081 0 4812 466 48088 Shock absorber 1400
084 0 4812 466 58001 Silent block
086 2 4812 401 18412 Stopper
110 0 4812 498 18361 Handle, door
130 0 4812 417 28047 Plate Door lock
130 1 4812 417 28048 Plate Door lock Lower
131 0 4812 417 28046 Lock Door
131 1 4812 417 28045 Pin Door Lock
131 2 4812 492 58022 Spring Door Lock
135 1 4812 498 18262 Knob Door safety GW
135 2 4812 492 58023 Spring Door Safety
135 3 4812 290 68153 Holder, adjust. Door Safety
140 0 4812 450 58983 Door glass
143 0 4812 440 11142 Glass door frame galv. EBL
144 0 4812 440 11139 Frame, door glass
191 0 4812 466 68841 Door bellow short 1600
191 1 4812 401 18673 Strap 1600
191 2 4819 530 58059 Ring
200 1 4812 418 18534 Tub, half front 53l, 1600
200 2 4812 418 18533 Tub, half rear 53l, 1600
200 4 4812 290 88054 Clamp for tub
220 0 4812 418 18532 Drum 1600, 53l, PP
271 0 4812 358 18194 Belt POLY-5 1272 J 5
272 0 4812 528 58039 Pulley 1600
272 3 4812 505 18371 Nut M 12
292 0 4812 530 58176 Gasket Tub 1600
301 0 4812 452 14948 Control panel + handle drawer
331 0 4812 414 58272 Knob, timer galv./bi. EBL
332 2 4812 513 18146 Push button without LED EBL
332 3 4812 513 18145 Push button with LED EBL
332 4 4812 513 18153 Push button temp. +/- EBL
333 0 4812 513 18143 Push button Start EBL
333 1 4812 513 18144 Push button Start Delay EBL
400 0 4812 361 58413 Motor 1600
409 0 4812 362 48004 Brush, carbon motor CESET
Interf. filter 1,00 µ F
421 0 4812 121 18142
430 0 4812 310 28144 Pump, draining KIT
451 0 4812 259 28766 Heating element 240V, 53l
480 0 4812 321 78109 Cable Motor SC1/OM PP/ALPHA/GA
490 0 4812 321 18043 Connect. cable 5m
AWO 5963
8592 027 15000
Pos. No. 12NC Code
491 0
491 1
500 0
571 0
573 0
581 0
620 0
630 0
691 0
700 0
701 0
701 1
702 0
702 1
707 0
707 1
707 2
707 3
708 1
711 0
712 0
713 0
717 0
717 1
717 2
717 3
717 4
717 5
718 0
718 1
718 2
750 0
753 1
754 0
754 1
754 2
760 0
781 0
782 0
783 1
783 3
783 4
787 0
787 2
794 5
900 0
900 1
900 2
900 3
900 4
900 5
900 6
900 7
900 8
900 9
Whirlpool Europe
S E R V I C E
Customer Service
Description
4812 321 28367 Strain relief
4812 502 38152 Screw 4.8x19
4812 282 19853 Timer SC1 (EI,EC,PW,IR,RH)
4812 281 28382 Valve, magnet cold
4812 271 28449 Valve, magnet hot
4812 276 18327 Pressostat 55/35
4812 239 58031 Module "A" C/DS A+
4812 280 58044 Door lock
4812 282 18702 Sensor NTC (SC1,OMEGA,ACCESS)
4819 530 28928 Hose, inlet 2m
4819 530 28848 Hose, inlet
4819 466 69704 Gasket and filter
4819 530 29019 Hose intern
4819 530 28971 Hose, inlet intern
4812 526 48031 Nozzle Distribution
4812 526 48028 Nozzle
4812 526 48034 Nozzle hot
4812 526 48035 Nozzle hot
4812 530 48143 Bend
4812 418 68324 Dispenser 3 C. EBL UK
4812 418 68319 Drawer 3 C. cpl. EBL
4812 418 89042 Flap drawer 3 C. EBL
4819 321 28092 Bowden cable
4812 321 38013 Lever, Nozzle
4812 321 38012 Holder, adjust.
4812 278 88018 Slide
4812 492 38359 Spring, Nozzle
4812 282 18807 Cam 3 C. SC1/VBL/WH
4812 526 48051 Siphon
4812 418 89041 Separator 3 C. EBL
4812 418 89043 Grille drawer 3 C. EBL
4812 530 48139 Chamber, expand.
4819 418 68234 Chamber, air
4812 530 28826 Drain hose
4812 530 28832 Lock eco
4812 530 29352 Flange eco
4812 480 58105 Filter set pump
4819 530 28959 Hose
4812 530 28827 Hose Pressostat
4812 530 29353 Steam hose
4812 530 18001 Connection Part
4812 530 28818 Hose
4812 530 28819 Hose with hole
4819 401 18868 Clamp, hose 26.8 mm
4812 530 58098 Gasket Airtrap
4812 255 18204 Holder Hose outlet
4812 290 88086 Bracket
4812 290 88077 Cable clamp
4812 401 18446 Cable clamp
4819 401 18872 Clamp, hose
4819 401 18529 Clamp, hose
4812 401 18444 Support Heating element
4812 256 98031 Holder pressostat
4819 401 18823 Clamp
4819 404 78449 Support
