01.06.2007 / Page 4
Doc. No: 4812 722 28036

Spare part list

Model
AWE 4017
Service No.
859340142070
Version
859340142070
Pos. No. 12NC Code
Description
002 0
4812 459 38057
Flap round GW
002 1
4812 459 38058
Hinge flap GW
004 0
4812 440 19625
Drip tray assy
010 0
4812 459 48175
Door frame inner GW
010 1
4812 440 11637
Frame Top+nozzle box KIT
011 0
4812 462 48054
Foot
012 7
4812 310 18497
Trolley kit front
012 8
4812 528 78075
Foot rear
021 0
4812 440 10838
Front panel WH GW
022 0
4812 440 10839
Side panel right GW
022 1
4812 440 10841
Side panel left GW
024 0
4812 440 11638
Rear panel
040 0
4812 417 19155
Hinge bolt lid GW
061 0
4812 466 88995
Counter weight rear, 5 pts
061 1
4812 466 88996
Counter weight front
061 2
4812 466 88492
Counter weight bottom
081 4
4812 529 18043
Shock absorber
086 4
4812 529 18045
Pin f. Shock absorber
086 5
4812 529 18052
Damper f. Shock absorber
100 1
4812 440 10842
Lid outer GW
100 3
4812 440 10843
Lid inner GW
100 5
4812 440 10845
Lid assembly WH GW
110 4
4812 498 18249
Handle cpl. WH GW
130 0
4812 417 19193
Door latch GW
191 0
4812 466 68596
Door bellow
191 1
4812 492 98037
Strap f. bellow
200 0
4812 418 18633
Tub LR 5pts/T20-40
200 1
4812 418 18634
Tub LR 5 pts/20-40WELDED
201 0
4812 440 11679
Cover for tub ALL/T20-40
220 0
4812 418 18635
Drum LR 05-06/SO 6/7 NIT
223 0
4812 418 48725
Drum lifter
271 0
4812 358 18167
Belt Poly V 1204 H8 MA
272 0
4812 528 88083
Pulley 298 mm
290 0
4812 532 68078
Gasket
301 0
4812 453 10434
Control panel AWE 4017
331 0
4812 414 58306
Knob timer EBL WP25
331 2
4812 414 58307
Knob timer ring, bush spring
332 0
4812 410 29501
Push button 4-opt.
333 0
4812 410 29503
Push button start/reset
400 0
4812 361 58444
Motor 1BA5736-0WA/BSH
Interf.filter 1,00 µ F
421 0
4812 121 18285
421 2
4812 404 38679
Holder RFI
430 0
4812 360 18577
Pump,draining
451 0
4812 259 28919
Heating element 2050W, 230V + NTC
490 0
4812 321 18311
Cable mains ISRAELE
490 1
4812 321 28367
Strain relief
521 0
4812 214 70092
Control unit DOMINO, basic
521 0
4812 214 70331
Control unit DOMINO, programmed
571 0
4812 281 28468
Valve magnet
571 1
4812 281 18069
Cover for top frame
581 0
4812 271 28585
Pressostat 50/25 INVENS.
620 0
4812 239 58046
Module E3/4 Opt.
630 0
4812 271 38519
Door lock 3P ROLD
653 0
4812 134 18079
Light guide PR.FLOW-START/RST
653 1
4812 134 18081
Light guide 4 OPTIONS-noRPM
AWE 4017
8593 401 42070
Pos. No. 12NC Code
691 0
701 0
702 2
707 0
707 1
712 4
712 6
712 9
753 0
754 0
754 1
760 0
781 0
782 0
787 0
787 1
794 0
900 0
900 1
900 2
900 3
901 0
910 0
910 1
910 3
910 4
910 5
910 6
921 0
930 1
930 2
941 0
953 0
962 0
962 2
965 0
990 0
990 2
993 0
993 1
Whirlpool Europe
S E R V I C E
Customer Service
Description
4812 282 19485
Sensor NTC SC1,OMEGA3
4812 530 29329
Hose inlet EN 11770 Reflex
4812 530 29453
Hose valve-dispenser
4812 526 48242
Nozzle box cold cpl.
4812 526 48049
Clamp f. nozzle box
4812 418 68302
Siphon f. softener
4812 418 68164
Clip SOAP DISPENSER
4812 418 68404
Soap dispenser cpl. 3 ch.
4812 418 68187
Chamber,air
4812 530 28938
Drainhose
4812 530 28832
Lock eco
4812 480 58089
Filter set pump
4819 530 29035
Hose draining
4812 530 28941
Hose Pressostat
4812 530 29309
Hose Air Exaust
4812 530 29311
Cover of hose
4812 530 58098
Gasket Airtrap
4819 401 18686
Clamp hose
4812 401 18431
Clamp to pump
4812 255 18304
Hose Holder
4819 401 18529
Clamp hose
4812 401 18462
Clamp hose drain hose
4812 502 48347
Screw,selftap 3,5x14SS
4812 502 38151
Screw 4x14
4812 502 18404
Screw
4812 502 18423
Screw PT 7x15
4812 502 18705
Screw M8x35
4812 502 18399
Nut Push in M 8
4812 400 18047
Washer
4812 492 48171
Torsions spring
4812 492 48162
Spring
4812 310 19144
Bearing kit ALL 1100
4812 325 68001
Shaft seal
4812 440 98142
Cover for Motor AC
4812 440 11424
Spacer
4812 462 79974
Cap Transport blocking
4812 310 18504
Fixing mat.set front counter
4812 310 18506
Fixing mat.set bottom
4819 530 29028
Bow
4812 290 18025
Clamp heatingelement
