INTENDED USE
This washing machine is exclusively destined to treat
machine washable laundry in quantities which are
usual for private households.
• Observe the instructions given in these Instructions
for Use and the Programme Chart when using the
washing machine.
SAFETY AND GENERAL RECOMMENDATIONS
1. Safety instructions
• The washing machine is
appropriate for indoor use
only.
• Do not store flammable fluids
near the appliance.
• Children must not be allowed
to play with the washing
machine or to climb into the
drum.
• This washing machine is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
• Do not operate the washing
machine at temperatures
below 5°C.
• For freestanding models: if you
want to place a dryer on top
of your washing machine, first
contact our After-Sales Service
or your specialist dealer to
verify if this is possible. This
is only admitted if the dryer is
fixed on the washing machine
by using an appropriate
stacking kit available through
our After-Sales Service or your
specialist dealer.
• Keep these Instructions for Use and the
Programme Chart; if you pass on the washing
machine to another person, also give him/her
Instructions for Use and Programme Chart.
• Do not leave the appliance
plugged in when not in use.
• Turn off the tap when not in
use.
• Before any cleaning and
maintenance switch off the
machine or disconnect it from
the mains supply.
• Never open the door forcibly
or use it as a step.
• If necessary, the power
cable may be replaced with
an identical one obtained
from our After-Sales Service.
The power cable must only
be replaced by a qualified
technician or by our After-
Sales Service.
• If your washing machine is a
built-in model:
- do not operate it unless it is
built-in
- you must not remove the
top cover.
2. Packaging
• The packaging material is entirely recyclable, and
marked with the recycling symbol
to current local regulations when disposing of
packaging material.
3. Disposing of packaging and scrapping
old washing machines
• The washing machine is built from reusable
materials. It must be disposed of in compliance
with current local waste disposal regulations.
• Before scrapping, remove all detergent residues
and cut off the power cable so that the washing
machine is made unusable.
• This appliance is marked according to the
European directive 2002/96/EC on Waste Electrical
and Electronic Equipment (WEEE).
GB 1
