SERVICE
© Whirlpool EMEA
Whirlpool EMEA
Service Information
Washing machine Frontloader
AWO 3361
8592 111 53001
Last Modification: 24/07/08
Creation Date: 07/06/08
Service Bulletin 4812 712 40367
Service Bulletin 4812 712 40307
This document is only intended for qualified technicans who are aware of the
respective safety regulations.
Subject to modifications
AWO 3361
2
5
7
8
www.scc-service.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Whirlpool AWO 3361
Summary of Contents for Whirlpool AWO 3361
- Page 1 Whirlpool EMEA SERVICE AWO 3361 Customer Services Service Information Washing machine Frontloader AWO 3361 8592 111 53001 Last Modification: 24/07/08 Creation Date: 07/06/08 Spare Part List Exploded View Service Bulletin 4812 712 40367 Service Bulletin 4812 712 40307 This document is only intended for qualified technicans who are aware of the respective safety regulations.
-
Page 2: Customer Services
400 1 4812 502 18737 Screw 8x38 409 0 4812 362 48004 Brush,carbon, Motor CESET 421 0 4812 121 18285 E01E6f.filter 4812 310 28145 430 0 Pump,draining KIT 451 0 4812 259 28766 Heating element 240V, 53l © Whirlpool EMEA www.scc-service.com... - Page 3 900 3 4812 401 18446 Cable clamp 900 4 4812 401 18549 Clamp hose 900 5 4819 401 18529 Clamp hose 900 6 4812 401 18444 Support Heatingelement; Heatingelement 4812 256 98031 900 7 Holder pressostat © Whirlpool EMEA www.scc-service.com...
- Page 4 965 0 4812 466 68545 Cover BK/WH 965 1 4812 462 78165 Threaded cap 965 2 4812 462 28678 Stopper dispenser 993 0 4819 530 29028 U Curve for outlet hose 993 3 4812 395 58004 Tool © Whirlpool EMEA www.scc-service.com...
-
Page 5: Exploded View
8592 111 53001, 24/07/08 Whirlpool EMEA SERVICE page 5 of 9 Customer Services Exploded View © Whirlpool EMEA www.scc-service.com... - Page 6 8592 111 53001, 24/07/08 Whirlpool EMEA SERVICE page 6 of 9 Customer Services Exploded View © Whirlpool EMEA www.scc-service.com...
- Page 7 (Attention: It is important that tere are only few seconds between the disconnection of the appliance and the measurement!!!) 4. In case the NTC is outside of specification (low resistance) replace the NTC. NTC order code: 4812 282 19485 SB:481271240367 SymptomCode:A1C ComponentCode:6910 DefectCode:1X RepairActionCode:A Technical Failure Code A1C 6910 1X A © Whirlpool EMEA www.scc-service.com...
- Page 8 If in Service Manual one of the old shaft seals is used, replace it by the related new one. Use grease “Amblygon” (4812 169 28222) on inner side when installing the new shaft seal. When reassembling the tub a © Whirlpool EMEA www.scc-service.com...
- Page 9 8592 111 53001, 24/07/08 Whirlpool EMEA SERVICE page 9 of 9 Customer Services new sealing between the two half tubs must be used in order to avoid any leakage. © Whirlpool EMEA www.scc-service.com...
