Spare Part List - Whirlpool AWE 9630 Service Information

SERVICE

Spare Part List

Pos 12NC Description
002 0 4812 459 38057 Flap round GW
002 1 4812 459 38058 Hinge flap GW
004 0 4812 440 10727 Drip tray assy
010 0 4812 459 48219 Frame inner,soft open
010 1 4812 440 11663 Frame Top + nozzle box
011 0 4812 462 48054 Foot
012 7 4812 310 18497 Trolley kit front
012 8 4812 528 78075 Foot rear
021 0 4812 440 10742 Front panel GW
022 0 4812 440 10743 Side panel right GW
022 1 4812 440 10744 Side panel left GW
024 0 4801 111 04682 Rear panel
040 0 4812 417 19155 Hinge bolt lid GW
061 0 4801 111 04683 Counter weight
061 1 4812 466 88465 Counter weight right
081 4 4812 529 18043 Shock absorber
086 2 4812 401 18412 Stopper
086 4 4812 529 18045 Pin f. Shock absorber
086 5 4812 529 18052 Damper f. Shock absorber
100 1 4812 440 10745 Lid outer GW
100 3 4812 440 11824 Lid inner +hook+spring
100 5 4801 111 04684 Lid cpl.
110 4 4801 111 04685 Handle cpl.
130 0 4812 417 19156 Hook f. Lid GW
191 0 4801 101 00143 Door bellow
191 1 4812 492 98012 Strap f. Doorbellow
191 2 4812 466 88703 Seal
200 0 4801 111 04686 Tub
201 0 4801 111 04687 Cover for tub
220 0 4801 111 04688 Drum
221 1 4812 310 18843 Kit latch f.drum
223 0 4801 101 00104 Drum lifter low
290 0 4812 532 68078 Gasket
301 0 4801 111 04689 Control panel AWE 9630
321 3 4812 453 10906 Window FLD
331 0 4801 111 01462 Knob timer Core 08, metallic
331 2 4812 414 58307 Spring Knob timer
332 0 4812 410 29581 Button 4 options
333 0 4812 410 29582 Push button Reset/Drain
4812 410 29583
333 1 Button 2 option WP
333 2 4801 111 03029 Button window, left
333 3 4801 111 03031 Button window, middle
333 4 4801 111 03032 Button window, right
350 0 4801 111 04691 Control unit Motor
4812 239 58089
350 1 Module B4,FLD
400 0 4801 111 04692 Motor
421 0 4812 121 18285 Interf.filter
421 2 4812 404 38679 Holder RFI
4801 111 04693
430 0 Pump,draining
451 0 4812 259 28919 Heating element 2050W, 230V + NTC
