SERVICE MANUL
AWO5100
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It
dose not contain warnings and cautions to advice non-technical individuals of potential dangers in attempting to service a product.
Product powered by electricity should by serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
SERVICE MANUAL
MODEL: AWO5100
WARNING
Washing Machine
All rights reserved. Unauthorized copying and distribution is a violation of law.
Washing Machine
１
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Whirlpool AWO5100
Summary of Contents for Whirlpool AWO5100
- Page 1 AWO5100 SERVICE MANUAL Washing Machine MODEL: AWO5100 WARNING This service information is designed for experienced repair technicians only and is not designed for use by the general public. It dose not contain warnings and cautions to advice non-technical individuals of potential dangers in attempting to service a product.
-
Page 2: Table Of Contents
SERVICE MANUL ２ AWO5100 Contents Chapter 1 General Information ________________________________________________ ４ 1-1. General Guidelines _____________________________________________________４ 1-2. Caution and Warning symbols ____________________________________________ ４ 1-3. Function indication symbols ______________________________________________ ４ Chapter 2 Product Feature ___________________________________________________ ５ 2-1. Features _____________________________________________________________ ５ 2-2. Specification __________________________________________________________ ６... - Page 3 SERVICE MANUL ３ AWO5100 8-3. Adjusting the washing machine _________________________________________ １６ 8-4. Joining the Inlet Hose to the Washing Machine _____________________________ １７ 8-5. Drainage Hose ______________________________________________________ １７ 8-6. Connecting to the Power Supply ________________________________________ １７ Chapter 9 Wiring circuit and Self check ______________________________________ １８...
-
Page 4: Chapter 1 General Information
SERVICE MANUL ４ AWO5100 Chapter 1 General Information 1-1. General Guidelines When servicing,observe the original lead dress.If a short circuit is found, replace all parts which are overheated or damaged by the short circuit.After servicing ,see to it that all the protective devices such as insulation barriers ,insulation papers shields are properly installed .Confirm that the screws,parts and wiring... -
Page 5: Chapter 2 Product Feature
SERVICE MANUL ５ AWO5100 Chapter 2 Product Feature 2-1. Features (1). 300mm diameter porthole, door may be open at a 180 degrees. Facilitate view of wash process, facilitate unloading and easy to use with large port. (2). Class A energy-saving... -
Page 6: Specification
SERVICE MANUL ６ AWO5100 2-2. Specification washing machines Product identification Description of appliance Washing machine Type of appliance(FS = standing, BI = built-in) Supplier own brand Supplier bar code （ Europe ） Commercial Brand / Model Commercial bar code Key-Features... - Page 7 SERVICE MANUL ７ AWO5100 Auto water cool-down (before drain 90°C boiled water) Water overflow protection Acqua Stop kit Child protection Programs n° 1) Strong action /cotton cycles (90°C/60°C/40°C/30°C/※) / 2) Normal action / synthetics (90°C/60°C/40°C/30°C/※) n° /...
-
Page 8: During Use
SERVICE MANUL ９ AWO5100 3-2. During Use... -
Page 9: Chapter 3 Matters Needing Attention
SERVICE MANUL ８ AWO5100 Chapter 3 Matters needing attention 3-1. Safety... - Page 11 SERVICE MANUL １１ AWO5100...
-
Page 12: Chapter 5 Program Introduction
SERVICE MANUL １２ AWO5100 Chapter 5 Program Introduction... -
Page 13: Chapter 6 Washing Mathods
SERVICE MANUL １３ AWO5100 Chapter 6 Washing Mathods 6-1. Loading 6-2. Adding detergent 6-3. Selecting washing program... -
Page 14: Chapter 7 Appearance Brief Introduction
SERVICE MANUL １４ AWO5100 Chapter 7 Appearance brief introduction 7-1. Name of parts... -
Page 15: Net Dimension
SERVICE MANUL １５ AWO5100 7-2. Net dimension Delay Spin PROG. Prewash Delicate Wash Temperature Cotton Silk Rinse Synthetic Quick Spin Wool Drain Delay Start/Pause On/Off Temperature Spin height:850mm / width:595mm / depth:535mm... -
Page 16: Chapter 8 Disassembly And Installation
SERVICE MANUL １６ AWO5100 Chapter 8 Disassembly and Installation 8-1. Remove packing materials 8-2. Dismantle packing bolts 8-3. Adjusting the washing machine... -
Page 17: Joining The Inlet Hose To The Washing Machine
SERVICE MANUL １７ AWO5100 8-4. Joining the Inlet Hose to the Washing Machine 8-5. Drainage Hose 8-6. Connecting to the Power Supply... -
Page 18: Chapter 9 Wiring Circuit And Self Check
SERVICE MANUL １８ AWO5100 Chapter 9 Wiring circuit and Self check 9-1. Wiring circuit PCB-Printed Circuit Board NTC-Temperature Sensor FA-Interference Suppresser MR-Door Lock Switch-Power Switch EVP,EVF-Water Inlet Magnetic Valve P- Pressure Switch B1-Drainage Pump R-Heating element M-Motor... -
Page 19: Self Check
SERVICE MANUL １９ AWO5100 9-2. Self check Press the “temperature”and “delay”button at the same time，then switch on the power ,wait for about 3 secs ,the led will display “TEST”,now you can press “start/pause”to let washing maching start test function softy... -
Page 20: Chapter 10 Error Display And Troubleshooting
SERVICE MANUL ２０ AWO5100 Chapter 10 Error Display and troubleshooting 10-1. Error Display Error message:Door is not properly shut 20s after program is started. Troubleshooting: Shut the door properly Pushing the door to Check Whether Door is properly shut or not Door lock is broken and need replacing, Cut off the power and then turn on again. - Page 21 SERVICE MANUL ２１ AWO5100 Error message:Temperature sensor is not properly connected or damaged (display at the end of a program). Troubleshooting: Cut off power and measure the resistance NTC exist open circuit. Replace it of temperature sensor by multimeter , is it between 5-14kΩ...
- Page 22 SERVICE MANUL ２２ AWO5100 Error message: The required water level is not reached within 8 min, or the water level exceeds the protection value Troubleshooting: Connect it well. Check if water is leaking from washer bottom. Inlet pipe. drain pipe or...
- Page 23 SERVICE MANUL ２３ AWO5100 Error message. Motor overheat protection or is damaged. Troubleshooting: Cut off power and check if motor wires Reconnect well are connected well Put the motor in normal temperature about ten minutes, and then test again. If the resistance is natural, it Measure if the resistance of motor is caused by overheated protection.
-
Page 24: Examination & Troubleshooting
SERVICE MANUL ２４ AWO5100 10-2. Examination & Troubleshooting 10-2-1. Display nothing Troubleshooting: Repair power supply Measure the power supply ,is it exists 220V-240V AC voltage？ Press the power switch Is power switch on? Make sure power supply cable Press power switch and check the... -
Page 25: No Draining
SERVICE MANUL ２５ AWO5100 10-2-3. No draining Troubleshooting: Adjust the height of drainpipe to Is the height of drain pipe too high? 80-100 cm Turn filter anticlockwise ， open and check if filter is jammed Clean and tighten filter clockwise. -
Page 26: Water Leaking
SERVICE MANUL ２６ AWO5100 10-2-5. Water leaking Troubleshooting: Check if water is leaking from the inlet pipe Readjust it or the tap Is drain pipe broken？ Replace drainpipe Check if there is foreign material nipped Remove clothes between cushion of sight window and... -
Page 27: Chapter 11 Maintenance
SERVICE MANUL ２７ AWO5100 Chapter 11 Maintenance... - Page 28 SERVICE MANUL ２８ AWO5100...
- Page 29 SERVICE MANUL ２９ AWO5100 Sincere Forever...
