- Page 1 RSE300, RSE600 Thermal Imagers Users Manual May 2018 (English) © 2018 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction....................How to Contact Fluke ................Safety Information ..................Product Familiarization ................Features....................LED Indicator ..................Operation....................SmartView Software .................. Download SmartView Software ............Download Firmware................Enable the Radio .................. Accessories ....................Optional Lenses..................Maintenance .................... - Page 4 RSE300, RSE600 Users Manual...
-
Page 5: Introduction
Introduction The RSE300 and RSE600 Thermal Imagers (the Product or Imager) are stationary, infrared imaging cameras for use in many applications. These applications include equipment troubleshooting, preventive and predictive maintenance, building diagnostics, and research and development. The Imager can stream live infrared and IR-Fusion technology video to a PC that has SmartView software installed or to the Fluke Connect app (where available). - Page 6 RSE300, RSE600 Users Manual • See emissivity information for actual temperatures. Reflective objects result in lower than actual temperature measurements. These objects pose a burn hazard. • Use only the external mains power supply included with the Product. • Do not put metal objects into connectors.
-
Page 7: Product Familiarization
Thermal Imagers Product Familiarization Product Familiarization Features Table lists the features of the Product. Table 2. Features Item Description Item Description Lens cover LED indicator (See Indicator) Visual light lens M16 DC power jack M12 ethernet and power over ethernet ... -
Page 8: Led Indicator
RSE300, RSE600 Users Manual LED Indicator Table explains what the colors on the LED indicator means. Table 3. LED Indicator Light Colors Color Description Action Wait for the Product to warm up. The Product is warming up. Blinking red Connect the RJ45 connector end of the ethernet cable to the ethernet switch and There is no ethernet connection. -
Page 9: Smartview Software
Update the firmware for new Imager features. Download SmartView Software To download SmartView Software: 1. Go to www.fluke.com/smartviewdownload. The software automatically downloads to the PC. 2. On the PC, follow the instructions to install SmartView software. (Administrator privileges are required for the installation.) -
Page 10: Download Firmware
If the radio is authorized in your country, an authorization code appears on the web page. Note If the radio is not yet authorized in your country, Fluke will contact you when the radio is authorized for use in your country. -
Page 11: Accessories
Thermal Imagers Accessories Accessories Table is a list of the accessories available for the Imager. Table 4. Accessories Model Description Contact Fluke Contact Fluke Tripod/Accessory Stand 3413459 BOOK-ITP Introduction to Thermography Principles 4961174 FLK-0.75X-WIDE-LENS Wide-Angle Infrared Smart Lens 4961163 FLK-2X-LENS... -
Page 12: Maintenance
RSE300, RSE600 Users Manual Maintenance Cleaning and lens care are the only maintenance required to the Product. Clean the Case Clean the case with a damp cloth and a weak soap solution. Do not use abrasives, isopropyl alcohol, or solvents to clean the case. - Page 13 Thermal Imagers Specifications Weight ........1.04 kg (2.3 lb) Enclosure Rating .......IP67 Safety ..........IEC 61010-1 Wireless Radio Frequency.........2412 MHz to 2462 MHz Output Power......<100 mW Electromagnetic Compatibility (EMC) International ......IEC 61326-1: Industrial Electromagnetic Environment CISPR 11: Group 1, Class A Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio frequency energy that is necessary for the internal function of the equipment itself.
- Page 14 RSE300, RSE600 Users Manual...
