FleetPC-5-B In-Vehicle Computing User's Manual Version 1.0 Document Name FleetPC-5-B User Manual Document No. UM2018321010 Version Date June 1, 2018 Reversion History : Reversion Date Notes Author(s) From Jane 1 , 2018 Initial document issued Stanley Chou...
Page 2
into any language, or transmitted in any form or by any means such as electronic, mechanical, magnetic, optical, chemical, photocopy, manual, or otherwise, without prior written permission from CarTFT.com e.K. Other brands and product names used herein are for identification purposes only and may be trademarks of their respective owners. Disclaimer CarTFT.com e.K. shall not be liable for any incidental or consequential damages resulting from the performance or use of this product. CarTFT.com e.K. makes no representation or warranty regarding the content of this manual. Information in this manual had been carefully checked for accuracy; however, no guarantee is given as to the correctness of the contents. For continuing product improvement, CarTFT.com e.K. reserves the right to revise the manual or make changes to the specifications of this product at any time without notice and obligation to any person or entity regarding such change. The information contained in this manual is provided for general use by customers. This device complies to Part 15 of the FCC Rules. Operation is subject to the following two conditions:...
Page 3
Safety Information Read the following precautions before setting up a CarTFT.com Product. Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device. Before connecting or removing signal cables from the ...
Page 4
Incorrectly replacing the battery may damage this computer. Replace only with the same or its equivalent as recommended by CarTFT.com e.K. Dispose used battery according to the manufacturer's instructions.
1.0 Introduction TABLE OF CONTENTS Page # 1.0Introduction................................8 1.1 Model Specification............................8 1.2 VBOX-3210 Illustration (MB, System)......................9 1.3 Architecture..............................13 1.4 Power Consumption.............................13 2.0Internal Connector Specification........................15 2.1 Battery Connector (BAT1)...........................15 2.2 COM Port Connector (COM1)........................16 2.3 COM Port Connector (COM2)........................17 2.4 COM Port Connector (COM3)........................18 2.5 COM Port Connector (COM4)........................19 2.6 MCU DOWN Connector..........................20 2.7 DIP Switch Connector..........................21...
Page 6
1.0 Introduction 3.5 LAN Connector (LAN1)..........................43 3.6 LAN Connector (LAN2)..........................44 3.7 LAN + USB 3.0 Connector...........................45 3.8 DIO Connector..............................46 3.9 AUDIO Connector............................47 4.0System Installation..............................50 4.1 System Introduction.............................50 4.2 Opening Chassis............................51 4.3 Installing Memory............................53 4.4 Installing MINI PCIe Expansion Card (Minicard 1, 3G/LTE)..............55 4.5 Installing MINI PCIe Expansion Card (MiniCard 2)................57 4.6 Installing MINI PCIe Expansion Card (MiniCard 3)................59 4.7 Installing M.2 Module..........................61...
1.0 Introduction INTRODUCTION Model Specification System AMD RX‐421BD Quad Core 2.1GHz up to 3.4 GHz* AMD RX‐216GD Dual Core 1.6GHz up to 3.0 GHz (Optional GX‐224IJ, GX‐215JJ) *Config to 15W Memory 2 x SO‐DIMM DDR4 up to 32GB (1 x SO‐DIMM DDR4 for GX series) Graphics AMD Radeon™ graphics 2 x Serial ATA GEN 3.0 LAN Chipset 2 x Intel i210‐AT; Ethernet Swtich: 1 x Marvell 88E6176 Watchdog 1 ~ 255 Level Reset Power Requirement Power Input 9V‐48V DC Power input Power Protection Automatics Recovery Short Circuit Protection Power Management Vehicle Power Ignition for Variety Vehicle Power Off Control Power off Delay Time Setting by BIOS and Software Internal Battery Kit for 10 Mins Operating (Optional) Battery Patent No. : M447854 ‐ Build‐in Battery Storage User’s Manual Page...
1.0 Introduction 1 x 2.5" Drive Bay for SATA Type HDD/SSD Type 1 x Cfast slot Qualification Certifications CE, FCC Class A, E13 Serial Port 2 x RS232/422/485 (option additional 2 x RS232) USB Port 2 x USB 3.0 ports and 2 x USB2.0 Ports 5 x RJ45 Ports GbE (Optinal for 4 x POE 802.3at/af*) Video Port 2 x DP (Option additional 1 x VGA for RX series) GPIO Port 4 In and 4 Out Audio Mic‐in/Line‐out(Optional Line in) 3 x Mini‐card slots Expansion Bus 1 x M.2 A‐E key 2230 slot Antenna Antenna 4 x SMA‐type External Antenna Connectors SIM Card Socket SIM Card Socket 2 x SIM Card Sockets Supported Onboard with eject Environment Operating Temp. ‐40ºC ~ 70ºC (w/SSD) Storage Temp. ‐40ºC ~ 85ºC Relative Humidity 5% RH – 95% RH Vibration (random) IEC60068‐2‐64, random, 2.5G@5~500Hz, 1hr/axis with SSD Vibration Operating MIL‐STD‐810G, Method 514.6, Procedure I, Category 4 Operating: MIL‐STD‐810G, Method 516.6, Procedure I, Trucks and Shock semi‐trailers=15G (11ms) with SSD Mechanical Construction Aluminum Alloy...
Page 10
1.0 Introduction Front I/O User’s Manual Page...
Page 11
1.0 Introduction Rear I/O System User’s Manual Page...
1.0 Introduction Architecture DUAL‐CH Intel MDI BUS PCI‐E X1 #0 RJ45 Type1 Dual Channel SO‐DIMM DDR4 2400 MHz DDR4 BUS WGI210AT PORT 1 Type3 Single Channel (CH‐B) max: 16GB PoE is optional MDI BUS RJ45 PORT 2 (PoE) Display Port 1 Intel MDI BUS PCI‐E X1 #1 WGI210AT Type1 Support DP0,1,2 MDI BUS RJ45 Ethernet Switch R series ‐ SOC PORT 3 (PoE) Type3 Support DP0,1 Display Port 2 Marvell 88E6176 Merlin Falcon (FP4) MDI BUS RJ45 PORT 4 (PoE) CH7517A‐BF MDI BUS RJ45 968‐BALL BGA JST CON PORT 5 (PoE)
2.0 Internal Connector Specification DIP Switch Connector Connector size DIP-Switch 2x2 PIN Connector type pitch=1.27mm Connector location Connector pin Default is set at ON definition Switch Description 1-2 ON SMBUS switched ON for MINICARD2 3-4 ON Switch Description User’s Manual Page...
4.0 System Installation Opening Chassis Step1. Unscrew the six screws of the Back Cover as shown in the picture. Step2. Unscrew the three screws of the Front Panel as shown in the picture. User’s Manual Page...
Page 52
4.0 System Installation Step3. Unscrew the three screws of the Rear Panel as shown in the picture. Step4. Open Bottom Cover as shown in the picture. User’s Manual Page...
4.0 System Installation Installing Memory Step1. Put Memory on this place as shown in the picture. Step2. Hold the Memory with its notch aligned with the Memory socket of the board and insert it at a 30‐degree angle into the socket as shown in the picture. User’s Manual Page...
Page 54
4.0 System Installation Step3. Press down on the Memory so that the tabs of the socket lock on both sides of the module as shown in the picture. User’s Manual Page...
4.0 System Installation Installing MINI PCIe Expansion Card (Minicard 1, 3G/LTE) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture. User’s Manual Page...
Page 56
4.0 System Installation Step 3. Screw one screw to the holder as shown in the picture. Step 4. Done as shown in the picture. User’s Manual Page...
4.0 System Installation Installing MINI PCIe Expansion Card (MiniCard 2) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture. User’s Manual Page...
Page 58
4.0 System Installation Step 3. Screw one screw to the holder as shown in the picture. Step 4. Done as shown in the picture. User’s Manual Page...
4.0 System Installation Installing MINI PCIe Expansion Card (MiniCard 3) Step 1. Put MINI PCIe Expansion Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture. User’s Manual Page...
Page 60
4.0 System Installation Step 3. Screw one screw to the holder as shown in the picture. Step 4. Done as shown in the picture. User’s Manual Page...
4.0 System Installation Installing M.2 Module Step 1. Put M.2 Card on this place as shown in the picture. Step 2. Hold the Module with its notch aligned with the socket of the board and insert it at a 30 degree angle into the socket as shown in the picture. User’s Manual Page...
Page 62
4.0 System Installation Step 3. Screw one screw to the holder as shown in the picture. Step 4. Done as shown in the picture. User’s Manual Page...
4.0 System Installation Installing Internal Antenna Cable Step 1. Take the SMA Connector and Plug into IO Panel as shown in the picture. Step 2. Put the Washer into the SMA Connector as shown in the picture. User’s Manual Page...
Page 64
4.0 System Installation Step 3. Put the Oring to SMA Connector and tighten as shown in the picture. Step 4. Done as shown in the picture. User’s Manual Page...
Page 65
4.0 System Installation Step 5. Take the Ipex Connector and press on the 3G/LTE module as shown in the picture. Step 6. Take the Ipex Connector and press on the GPS module as shown in the picture. User’s Manual Page...
Page 66
4.0 System Installation Step 7. Take the Ipex Connector and press on the wifi module as shown in the picture. Step 8. Take the Ipex Connector and press on the M.2 module as shown in the picture. User’s Manual Page...
4.0 System Installation Installing SIM Card Step 1. Use thin stick to push the button as shown in the picture. Step 2. Take the holder away from front panel as shown in the picture. User’s Manual Page...
Page 68
4.0 System Installation Step 3. Put your SIM Card into the holder and take the SIM card holder and Insert it into the socket as shown in the picture. Attention: When insert a SIM card to the SIM card holder, please remove the main power at input to avoid undetectable SIM card. User’s Manual Page...
4.0 System Installation 4.10 Installing HDD Step 1. Put the HDD into HDD Holder as shown in the picture. Step 2. Screw two screws on both side as shown in the picture. User’s Manual Page...
Page 70
4.0 System Installation Step 3. Push the HDD Holder into the socket as shown in the picture. Step 4. Fully insert the HDD Holder into the socket until a “click” is heard as shown in the picture. User’s Manual Page...
Page 71
4.0 System Installation Step 5. Tighten to Storage Bracket screws as shown in the picture. User’s Manual Page...
4.0 System Installation 4.11 Installing CFast Card Module Step 1. Put CFast Card on this place as shown in the picture. Step2. Unscrew the three screws of the Front Panel as shown in the picture. User’s Manual Page...
Page 73
4.0 System Installation Step 3. Take CFast Card into the holder as shown in the picture. Step 4. Fully insert the CFast Card into the socket until a “click” is heard as shown in the picture. User’s Manual Page...
Page 74
4.0 System Installation Step 5. Put the Front Panel back and screw the three screws of it as shown in the picture. Unscrew the three screws of the Front Panel as shown in the picture. Step 5. Done as shown in the picture. User’s Manual Page...
4.0 System Installation 4.12 Installing POE Module Step 1. Put POE Module on this place as shown in the picture. Step 4. Put the POE‐8P module on the motherboard as shown in the picture User’s Manual Page...
Page 76
4.0 System Installation Step 5. Screw the three screws as shown in the picture Step 6. Done as shown in the picture User’s Manual Page...
5.0 BIOS BIOS Enter The BIOS Power on the computer and the system will start POST (Power On Self Test) process. When the message below appears on the screen, press (DEL) key to enter Setup. Press DEL to enter SETUP If the message disappears before you respond and you still wish to enter Setup, restart the system by turning it OFF and On or pressing the RESET button. You may also restart the system by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. Important The items under each BIOS category described in this chapter are under continuous update for better system performance. Therefore, the description may be slightly different from the latest BIOS and should be held for reference only. Upon boot‐up, the 1st line appearing after the memory count is the BIOS version. It is usually in the format. ABOX‐5000(P)G1 Mainboard V1.0 073109 where : 1st digit refers to BIOS maker as A = AMI, W = AWARD, and P = PHOENIX 2nd ‐ 5th digit refers to the model number. 6th digit refers to the chipset as I = Intel, N = NVIDIA, A = AMD and V = VIA. 7th ‐ 8th digit refers to the customer as MS = all standard customers. V1.0 refers to the BIOS was released. 073109 refers to the date this BIOS was released. 78 78 User’s Manual Page...
Page 79
5.0 BIOS Control Keys Power on the computer and the system will start POST (Power On Self Test) process. When the message below appears on the screen, press (DEL) key to enter Setup. <↑> Move to the previous item <↓> Move to the next item <←> Move to the item in the left hand <→> Move to the item in the right hand <Enter> Select the item <Esc> Jumps to the Exit menu or returns to the main menu from a submenu <+/PU> Increase the numeric value or make changes <‐/PD> Decrease the numeric value or make changes <F1> General Help <F3> Load Optimized Defaults <F4> Save all the CMOS changes and exit Getting Help After entering the Setup menu, the first menu you will see is the Main Menu. Main Menu The main menu lists the setup functions you can make changes to. You can use the arrow keys (↑↓) to select the item. The on‐line descrip on of the highlighted setup function is displayed at the bottom of the screen. Sub‐Menu If you find a right pointer symbol (as shown in the right view) appears to the left of certain fields that means a sub‐menu can be launched from this field. A sub‐menu contains addi onal op ons for a field parameter. You can use arrow keys ( ↑↓ ) to highlight the field and press <Enter> to call up the sub‐menu. Then you can use the control keys to enter values and move from field to field within a sub‐menu. If you want...
5.0 BIOS Main Time Setting » System Date This setting allows you to set the system Date. The time format is <Day> <Month> <Date> <Year>. » System Time This setting allows you to set the system time. The time format is <Hour> <Minute> <Second>. 80 80 User’s Manual Page...
5.0 BIOS Advanced AMT Configuration Serial Port Configuration 81 81 User’s Manual Page...
Page 82
5.0 BIOS » Serial Port 1/2/3/4 Enable or Disable Select an Enable or Disable for the specified serial ports. » COM1 RS232/422/485 Select 82 82 User’s Manual Page...
Page 83
5.0 BIOS » Watch Dog Function 83 83 User’s Manual Page...
5.0 BIOS Boot » 1st/2nd Boot Device The items allow you to set the sequence of boot devices where BIOS attempts to load the disk operating system. » Try Other Boot Devices Setting the option to [Enabled] allows the system to try to boot from other device if the system fail to boot from the 1st/2nd boot device. » Hard Disk Drives, CD/DVD Drives, USB Drives These settings allow you to set the boot sequence of the specified devices. 86 86 User’s Manual Page...
6.0 Packing List PACKING LIST Packing List System Item Part Number Module Name 763210020001 FleetPC‐5‐B‐G215 System 763210020002 FleetPC‐5‐BP‐G215 System 763210020003 FleetPC‐5‐B‐G224 System 763210020004 FleetPC‐5‐BP‐G224 System 763210020005 FleetPC‐5‐B‐R216 System 763210020006 FleetPC‐5‐BP‐R216 System 763210020007 FleetPC‐5‐B‐R421 System 763210020008 FleetPC‐5‐BP‐R421 System Accessory Picture Part Number Module Name Q’ty 326910039661 Cabling MC101‐508‐03G F 90D 326920087061 Cabling 2x5PIN(F) pitch:3.5mm 351102040110 Screw I Type M2*4L ISO NI 351103040250 Screw F Type M3*4L ISO BK User’s Manual Page...
Page 90
6.0 Packing List 351103060250 Screw F Type M3*6L ISO BK 351103060810 ROUND HAND SCREW W/SPRING_P3x0.5Px6L 370831501000 VBOX‐3150 Mount Bracket 417290370250 HDD‐RUBBER FOR H=7mm Silicone Rubber User’s Manual Page...
