Chapter 8: Utility; Clock; Mode; Time - Midtronics EXP-1002 Instruction Manual

EXP-1002
Use the Utility Menu to customize the tester—from
interface language to display contrast The utilities
also have default settings that can be user-adjusted.
Setup Function

CLOCK

TIME

The current Central Standard Time

MODE

AM

DATE

Current

FORMAT

MM/DD/YYYY (month/day/year)

SHOP

Generic header for printouts with 12
lines of text and a maximum of 17
characters per line
DISPLAY
CONTRAST LEVEL Range: 0 (lightest) to 10 (darkest). The
default is set at 9.
BACKLIGHT TIME Range: 0 to 60 seconds. The default is
set at 15 seconds.
COUPON Disabled (NO COUPON PRINTED)
EDIT COUPON Eight lines of text with 17 characters
per line.
Default: USER COUPON LINE 1
through USER COUPON LINE 8
TEMPERATURE DEGREES F (Fahrenheit)
LANGUAGE English is the default language.
French-Canadian and Spanish are
also available.
1. In the Main Menu, select the Utility icon.
2. Select the icon of the utility you want to adjust.
The Utility Menu has nine utilities to customize your analyzer.
Each utility described in this section is listed in order by its icon
title.
If you use the keypad to enter the number preceding the
option button, no additional keypress is needed to save or
continue to the next step.
Clock
The CLOCK ADJUST utility has four settings. Use the
ARROW keys to highlight the setting you want to
change.
MODE :
TIME :
FORMAT :
DATE :
www.midtronics.com

Chapter 8: Utility

Default Settings
AM/PM
9:07 PM
MMM/DD/YYYY
6/17/5/17/2013
Mode
1. Use  or  to select the desired Mode and press NEXT or
press the corresponding number key.

1 24 HOUR

2 AM/PM
Press SAVE to save your setting or BACK to return to the
2.
CLOCK ADJUST screen without saving.
Time
1. Use  or  to highlight the hour, minutes, or AM or PM. To
rapidly scroll, hold down an ARROW key.
Press SAVE to save your setting or BACK to return to the
2.
CLOCK ADJUST screen without saving.
Format
1. Use  or  to select the desired time display Format and
press NEXT or press the corresponding number key.

1 MM/DD/YYYY (month/day/year)

2 DD/MM/YYYY (day/month/year)
2. Press SAVE to save your setting or BACK key to return to
the CLOCK ADJUST screen without saving.
Date
1. Use  or  to highlight the month, day, or year. To rapidly
scroll, hold down  or .
Press SAVE to save your setting or BACK to return to the
2.
CLOCK ADJUST screen without saving.
Shop
The SHOP INFO utility allows you to create a header
for your printed test results showing your business
location information. The utility's two information
screens contain eight lines of text with a maximum of
17 characters per line.
Screen 1
1–YOUR SHOP NAME
2–1000 ANY STREET
3–YOUR TOWN, STATE
4–YOUR POSTAL CODE
25
Midtronics Inc.
Chapter 8: Utility
9 : 19 PM
6 / 04 / 2013
Screen 2
5–YOUR COUNTRY
—
6–YOUR PHONE NUMBER
7–WWW.WEBSITE.CO
8–SHOP ID NUMBER
7000 Monroe Street Willowbrook, IL 60527
—
