D C
ISPLAY ONFIGURATION
T 12: SMART-S
ABLE
Frame
Backlight
After making changes to the SMART-Space Controller Setup dialog box, click the OK
button, and click the Mode button at the bottom of the Display Configuration dialog box to
send the changes to the controller.
D C
ISPLAY ONFIGURATION
Table 13 describes the columns of the Display Configuration worksheet.
T 13: C
ABLE OLUMNS OF THE
Column
Display Name
Point
Value
Type
Range
82
C S
PACE ONTROLLER ETUP DIALOG BOX FIELDS
Field
Timeout
Always off
Disable Hand/Off/Auto
Feature
W C
ORKSHEET OLUMNS
D C
ISPLAY ONFIGURATION WORKSHEET
Description
Six character display name that will be displayed on the LCD
screen along with the current value of the object when the user
scrolls to the point. If this column field is left empty, the row
number will be displayed.
The mnemonic (e.g., 1301AV1, 1301SCHED1, etc) or name of the
BACnet object to be displayed. Objects can be dragged and
dropped from other worksheets.
The current value of the object.
Toggles between Analog or State to match the type of the object.
Successive clicks in this field will scroll to the possible ranges
associated with the Type selected, as follows:
State No/Yes, Stop/Start, Close/Open, Close/Open/Idle,
Off/On, Low/High, Cool/Heat, Off/Low/High,
On/Off/Auto, Fan: Off/Low/Med/High,
Off/Auto/Manual, Unoccupied/Occupied,
Auto/Manual, Low/High/Auto, Cool/Heat/Auto,
Cool/Heat/Auto/Off, Off/Low/High/Auto
Description
The number of seconds the backlight will stay
on after the last use of the SMART-Space
Controller adjustment buttons. A value of 0 in
the Time-out field causes the backlight to be
continuously on.
Select this field to disable the backlight.
Select this field to disable the output Hand/
Off/Auto feature via the LCD screen. This
feature is normally enabled by default.
