S A
OFTWARE PPLICATIONS

SOFTWARE CONFIGURATION

S A
OFTWARE PPLICATIONS
RC-T BAC MS
OOLKIT NET
The RC-Toolkit BACnet MSet Tool found in update 2.40, or later, is used to configure one
or more SMART-Space Controllers with a name, MAC address, and BACnet device ID.
A PC running the BACnet MSet Tool can discover and configure SMART-Space
Controllers from anywhere in a BACnet network without the presence of a slave proxy
device.
RC-T OS S A
OOLKIT END
The RC-Toolkit BACnet OS Send Tool found in update 2.40, or later, is used to send
firmware to SMART-Space Controllers.
A PC running the BACnet OS Send Tool can only discover and display configured SMART-
Space Controllers if a slave proxy device is connected directly to the same EIA-485
network as the SMART-Space Controllers. If a slave proxy device is not installed, it is
possible to OS Send to SMART-Space Controllers if the MAC address is known, using the
Send To feature. It is not possible to OS Send to unconfigured SMART-Space Controllers.
RC-S
TUDIO
RC-Studio update 1.50, or later, is used to program and handle custom pan files for
SMART-Space Controllers.
A PC running RC-Studio cannot discover and display SMART-Space Controllers unless a
device capable of acting as a slave proxy is connected directly to the same EIA-485
network as the SMART-Space Controllers. Possible slave proxy devices are the MACH-
ProCom, MACH-ProSys, MACH-Pro2, and MACH-Pro1 controllers, and the X-Port-2
converter.
