Rossmax TG120 Instruction Manual

TG120
Model:
EN
Instruction Manual
www.qutie-rossmax.com
Introduction
The Digital Medical Thermometer provides quick, highly accurate
reading over the human body temperature range. Please read the
instructions completely first.
The quality of the thermometer has been verified and conforms to
the provisions of the EC council directive 93/42/EEC(Medical Device
Directive) Annex I essential requirements and applied harmonized
standards. EN 12470-3: 2000 /A1: 2009 Clinical thermometers-Part
3: Performance of compact electrical thermometers (non-predictive
and predictive) with maximum device.
Attention: Consult the accompanying documents. Please read
this manual carefully before use. Please be sure to
keep this manual.
Display
Probe
Battery
Cover
ON/OFF Button
How to Use
1. Push the On/Off button by the display window. The display will
read for 2 seconds and beep sound will be heard.
2. Releasing the on/off button, last measured temperature will be
shown for about 2 seconds. Then shows the self-test temperature
37.0°C(98.6°F),and then Lo°C (Lo°F) displays.
3. Wipe or dip the probe with alcohol for disinfection. Position the
probe in oral, rectal or axillary site.
4. Once the degree sign °C ( °F) on the display has stopped flash-
ing (usually within 30 to 60 seconds), an Beep signal will sound
for approx. 10 times, the measured temperature is shown on
LCD window. The temperature reading will not change after
the unit is removed from testing position. If the temperature
<37.8°C(100.0°F ), the buzzer will alarm "Bi---Bi---Bi---Bi---". If
the temperature ≥ 37.8°C (100.0°F), the buzzer whose frequency
is higher will alarm "Bi-Bi-Bi----Bi-Bi-Bi--" about 10 times rather
than"Bi---Bi---Bi---Bi---"
5. The unit will automatically turn off in 10 minutes for energy saving.
However, to prolong the life of the battery, it is suggested to press
the On/Off button to turn the unit off once the measurement
is done.
6. Please dispose of any used battery and the thermometer accord-
ing to the local regulations.
Note: After step 2, if the room temperature is greater than
32.0°C (89.6°F ). it will be displayed the room tempera-
ture.
Note: Usage of the probe cover may result in a 0.1°C(0.2°F)
difference from actual temperature.
Note: To clean the probe before and after using the ther-
mometer to ensure an accurate reading and avoid cross
contamination approximately.
Oral Use
Place the probe well under the patient's tongue. Confirm the patient
to keep his mouth closing for about 1 minute.
Do not drink hot or cold fluids, exercise, and smoke or per-
form other activities prior to a reading. These activities will
raise or lower temperature readings when compared to your
normal, average temperature.
Axillary Use
Tightly place probe in the patient's armpit for about 1~5 minutes.
* Please ensure the close contact between the probe and the armpit
of the baby or children.
Rectal Use
Always uses probe cover when taking rectal measurements.
1. Commonly used for young children when it is difficult to take an
oral or axillary temperature.
2. Lubricate with a water-soluble gel. Do not use petroleum jelly.
3. Gently insert the probe tip no more than 1.5-2 cm into the rectum
for about 1 minute. Do not force the tip into the rectum if resist
ance is encountered.
4. Disinfect the thermometer after use. Refer to "cleaning and
disinfection"section.
ºC /ºF Switchable
Temperature readings are available in the Fahrenheit or Celsius scale
(°C / °F; located in the right of LCD.) With the unit off, press and
hold the On/Off Button for approximately 4 seconds to change the
current setting.
Battery Replacement
1. When the appears on the upper right corner of the LCD,
the battery is exhausted and needs replacement.
2. Pull the battery cover off in the direction shown below.
3. Pull out the battery with a sharp objects such as pen. Keep ex-
hausted battery from reaching by the children.
4. Place a new 1.5V D.C. but-
ton size battery type SR41
or LR41 or equivalent in the
chamber with positive side
faced up and negative side
faced down.
5. Install the battery cover back.
Display on the LCD
M: Last measured temperature.
: When the appears on the upper
right corner of the LCD, the battery is
exhausted and needs replacement.
Troubleshooting
Error message Problem Solution
The system is Unload the battery, wait for 1
not functioning mins and repower it.
properly If the message reappears, con-
tact the retailer for service.
Temperature Take a new temperature meas-
taken is higher than urement after 6 sec.
42.9°C (109.2°F)
(bi-bi...bi)x10
Temperature taken Take a new temperature meas-
is lower than 32°C urement after 6 sec.
(89.6°F)
Dead battery: Suggest to replace the battery.
Battery icon is
flashing, can't be
measurable.
Cleaning and Disinfection
1. Clean the unit by wiping it with a dry cloth and sterilize the probe
with ethyl alcohol.
2. Don't let the unit contact any chemical thinner.
3. Not waterproof. Do not soak the display in water. Only the probe
is waterproof.
Caution
• Do not bend or drop the thermometer. It is not shockproof.
• Do not boil probe for disinfect.
• Do not store the unit under direct sunlight, at a high
temperature, in high humidity or dust. Neither store the
unit under the sunlight, nor at the high temperature or
humidity.
• Do not disassemble. See BATTERY REPLACEMENT to replace battery.
• Avoid strong electromagnetic interference such as microwave ovens
and cell phones.
• Please be noticed to keep the probe dry before putting the
thermometer into the carry case.
• The thermometer contains small parts (battery, etc.) that can be
swallowed by children. Therefore never leave the thermometer
unattended to children.
• The thermometer should be cleaned after measurement no matter
the probe cover has been installed or not.
• Battery should not be charged or placed into extreme heat as it
may explode.
• Do not use the thermometer in ear. Intended use is for oral, axillary
and rectal measurement.
• Use of the probe cover may result in a 0.1ºC(0.2ºF) discrepancy from
actual temperature.
• Remove battery from the thermometer when not in operation for
a long time.
• If the unit is stored in an extreme environment before measurement,
please make sure it has been firstly adapted in the room
temperature, so that the unit can be measured normally.
• Please note that this is a home healthcare product only, and it is not
intended to serve as a substitute for the advice of a physician or
medical professional.
• Do not use this device for diagnosis or treatment of any health
problem on disease. Measurement results are for reference only.
Contact your physician if you have or suspect any medical problems.
Do not change your medications without the advice of your
physician or healthcare professional.
• This device may not meet its performance specification if stored
or used outside temperature and humidity ranges specified in
specifications.
• If this device is used according to the operations instruction, periodic
re-calibration is not required. If you still have questions, please send
the device to dealers.
• Please do not dispose of the product in the household waste at the
end of its useful life. Disposal can take place at your local retailer or
at appropriate collection points provided in your country.
• This device is for oral, axillary and rectal use only.
• High, prolonged fever requires medical attention especially for
young children. Please contact your physician.
• For save reason, during children's temperature measurement, please
keep them from crying, walking, talking and any related dangerous
activities.
