Matrix MX-FW63 Assembly Manual

IMPORTANT SAFETY INSTRUCTIONS
PROPER USAGE
1. Do not use any equipment in any way other than designed or intended by the manufacturer.
It is imperative that weight stack machines as well as any other MATRIX Fitness Systems, Inc. equipment are used properly
to avoid injury.
2. Keep hands and feet clear at all times from moving parts to avoid injury.
CHECK FOR DAMAGED PARTS
1. DO NOT use any equipment that is damaged and or has worn or broken parts. Use only replacement parts supplied by
MATRIX Fitness Systems, Inc.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason. They contain important information.
If unreadable or missing, contact your local dealer for a replacement.
3. SECURING EQUIPMENT: All equipment MUST be secured to the floor to stabilize and eliminate rocking or tipping over.
This must be performed by a licensed contractor.
4. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth operating equipment as well as keeping your
liability to a minimum. Equipment needs to be inspected at regular intervals.
5. Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so.
MATRIX Fitness Systems, Inc. will provide service and maintenance training at our corporate facility upon request.
SPECIFIC OPERATING WARNINGS
1. Routinely inspect all accessory clips that join attachments to the machine and replace at the first sign of wear.
2. Use only weight selector pins supplied by MATRIX Fitness Systems, Inc. on weight stacks. Substitutes are forbidden.
3. Belts and cables pose an extreme liability if used when frayed. Always replace any belts and cables at first sign of wear
(consult MATRIX Fitness Systems, Inc. if uncertain).
4. Do not allow users to wear loose fitting clothing while using equipment. It is also recommended to have users' secure long
hair back and up to avoid contact with moving parts.
5. Fully insert weight selector pins. Partial insertion can cause weights to fall unexpectedly.
Never remove selector pin if any weights are suspended. Never attempt to release jammed weights or parts.
PARTS DESCRIPTIONS
B10 MB0678010A End Cap ABS( 89.0×3.0t) 4
B11 MB0304057AA Foot 4
B12 MB0604046CA Bushing 42
B16 MJ4903005A Weight Plate Horn S45C 38.1×255L 8
B17 MB0501002C Bumper for Weight Plate 8
B18 ME0111022 Bolt, Round-Hex Socket M8×1.25P×20L 12
B19 MB06D4008AA Bolt 4
B20 ME0301014 Bushing ALS7-8125-3.8 (0.5-3.8) 4
B21 ME0112143 Bolt, Cap-End Allen M12×1.75P×30L 12
B22 MJ4905044A Supporting S45C 40×73L 8
B23 ME0502174 Flat Washer 13× 26×2.5t 12
B24 ME0501028 Spring Washer SW12 12.2×21.5×3t 12
F08 MJ4908031C Guide Rod Holder SS41 4
F09 MJ4905043B Hook S45C 18
F11 MB0101014BA Wheel 2
F12 SR1007001DA Adjustment Handle S45C 2
F14 MJ4904005D Shaft S45C 2
F15 MJ4906003C Guide Rod 2
F18 MJ4204001B Bearing Holder S45C 2
F19 ME0104045AB Bolt, Round-Head Allen M6×1.0P×15L 14
F20 ME0104192 Bolt, Round-Head Allen M8×1.25P×30L 8
F21 ME0501028 Spring Washer SW12 12.2×21.5×3t 18
F22 ME0502174 Flat Washer 13× 26×2.5t 18
F23 ME0901029 Internal C-Clip R-47 8
F24 ME0112162 Bolt, Cap-end Allen M12×1.75P×25L 10
F26 ME0902030 Top Plate Guide Sleeve C-clip S-8 2
F27 MD0501008 Sealed Bearing Set 6005ZZ(SKF) 8
F28 MD0504014 Flange Bushing GSM-2023-25 6
F29 MJ4913002H Limited Adjustment Shaft S45C 2
F30 MJ4902055C Housing SS41 2
F31 MJ4907001E Bushing S45C 2
F32 ME0502221A Flat Washer 6.4× 11×1.6t 4
F33 ME0501006AE Spring Washer SW6 6.1×12.2×1.5t 4
F34 ME0112012 Bolt, Cap-End Allen M6×1.0P×10L 4
F36 MJ4205003D Stop Housing STK41 2
F37 MD0501021 Sealed Bearing Set 608ZZ 4
H08 MD0504016 Flange Bushing LFF-2015 4
H09 ME0112037AC Bolt, Cap-End Allen M8×1.25P×30L 4
H10 ME0502172 Flat Washer 8.4× 15.5×1.6t 4
H11 ME0501016 Spring Washer SW8 8.2×15.4×2t 4
H12 SR1207001AA Increntment Weight Hook 4
K03 MB0250025DA Shield ABS 2
K08 SP1027002AA Balance Block 14
M02 MJ4907042B Sliding Bushing S45C 2
M04 MJ4910001B Stop Rod for Slidding Bushing S45C 15×47.5L 2
M05 MD0510006A Linear Bearing THOMSON SSE M30 WW 4
M07 MJ4902058B Housing for Pulling Kit S45C 2
M11 ME0901029 Internal C-Clip R-47 8
N02 MJ2909001C Hook SPHC 2
N06 MD0504038A Weight Stack Bushing LFF-3020 8
N07 MJ4202001C Pulling Kit S45C 1
N16 ME0112162 Bolt, Cap-End Allen M12×1.75P×25L 2
N18 ME0501028 Spring Washer SW12 12.2×21.5×3t 2
N19 ME0502174 Flat Washer 13× 26×2.5t 2
N20 MB0510002AA Rubber Stop 2
N21 ME0512003A Washer 30× 25×6 2
N24 MB0501007CA Bumper 8
V12 ME1201002 Rivet 1/8"×7.5L 2
V15 MG0296008A Index Label 2
Z02 ME1007031A Allen Wrench M6×80L 1
Z03 ME1007027A Allen Wrench M8×120L 1
Z04 ME1005001 Phillips Screwdriver 1
Z05 ME0501028 Spring Washer SW12 12.2×21.5×3t 8
Z06 ME0502174 Flat Washer 13× 26×2.5t 10
Z07 ME0112185A bolt, Cap-End Allen M12×1.75P×35L 8
Z08 ME0112156AB Bolt, Cap-End Allen M6×1.0P×20L 12
Z09 ME0112194AB Bolt, Cap-End Allen M10×1.5P×55L 4
Z10 MB0501003A Bumper for Weight Plate 6
Z22 ME0502173 Flat Washer 10.5× 18×2.0t 12
Z23 ME0501027 Spring Washer SW10 10.2×18.4×2.5t 12
Z24 ME0204028 Nylon Nut M10×1.5P 12
Z25 ME0104173 Bolt, Round-Head Allen M8×1.25P×15L 8
Z26 ME0502172 Flat Washer 8.4× 15.5×1.6t 8
Z27 ME0501016 Spring Washer SW8 8.2x15.4x2t 8
Z28 ME0502064AB Flat Washer 6.5× 13×1.0t 12
Z29 ME0501032A Spring Washer SW6 6.5×13.0×1.0t 12
Z30 ME0112175 Bolt, Cap-End Allen M10×1.5P×80L 4
Z31 ME0112144 Bolt, Cap-End Allen M10×1.5P×25L 4
Z32 ME1007024A Allen Wrench M5×70L 1
Z33 ME1001017A Wrench #13 1
Z34 ME1001019A Wrench #17 1
Sep 24, 2004

ASSEMBLY GUIDE

MX-FW63
RAD TRAINER
F I T N E S S S Y S T E M
