IMS IM483 Quick Reference

intelligent motion systems, inc.
Excellence in Motion
IM483
HIGH PERFORMANCE MICROSTEPPING DRIVER
QUICK REFERENCE QUICK REFERENCE
370 N. MAIN ST., PO BOX 457, MARLBOROUGH, CT 06447
PH: (860) 295-6102, FAX: (860) 295-6107
Internet: www.imshome.com, E-Mail: info@imshome.com
M 4 8 3 Q u i c k R e f e r e n c e A n d I n s t a l l a t i o n G u i d e
The primary function of IM483 Quick Reference and Installation
Guide is to acquaint the user with the specifi cations, basic wiring
and confi guration of the IM483 Microstepping Driver. The full prod-
uct manual is available in Acrobat PDF format on the IMS Product
CD, shipped with the product. It also may be downloaded from the
IMS web site at http://www.imshome.com.
N o t e s A n d W a r n i n g s
Please observe the following when handling, connecting and using
your IM483 driver. Failure to observe these points may result in
damage to the drive. All warranty and disclaimer information is
located in the full product manual on the CD and should be refer-
enced for more information.
WARNING! The IM483 Driver components are sensitive to
Electrostatic Discharge (ESD). All handling should be done at
an ESD protected workstation.
WARNING! Hazardous Voltage Levels may be present if you
are using an open frame power supply to power the IM483
Driver.
WARNING! Ensure that the Power Supply output voltage does
not exceed the maximum input voltage of the IM483 Driver.
WARNING! Do not operate the IM483 Driver without a Cur-
rent Adjustment Resistor!
A resistor MUST be placed between the Current Adjust Input
(Pin 2 on P2) and ground (Pin 3 on P2) to keep the IM483
Driver and/or motor in a safe operating range.
E l e c t r i c a l S p e c i f i c a t i o n s
Input Voltage .............................................. +12 to +48 VDC
Phase Output Current (RMS) ........................................... 3A
Phase Output Current (Peak).................................. 0.4 to 4A
Quiescent Current
Inputs/Outputs Floating .................................. 70mA Typ.
Active Power Dissipation (I
T h e r m a l S p e c i f i c a t i o n s
Ambient Temperature ......................................... 0° to 50° C
Storage Temperature..................................... -40° to 125° C
Max. Plate Temperature.............................................. 70° C
R e c o m m e n d e d P o w e r S u p p l i e s
I P 4 0 4 U n r e g u l a t e d L i n e a r S u p p l y
Input 120 VAC Version ....................................... 102-132 VAC
240 VAC Version ....................................... 204-264 VAC
No Load Output Voltage* ................................43 VDC @ 0 Amps
Continuous Output Rating*..............................32 VDC @ 2 Amps
Peak Output Rating* ......................................26 VDC @ 4 Amps
I S P 2 0 0 - 4 U n r e g u l a t e d S w i t c h i n g S u p p l y
Input 120 VAC Version ....................................... 102-132 VAC
240 VAC Version ....................................... 204-264 VAC
No Load Output Voltage* ................................41 VDC @ 0 Amps
Continuous Output Rating*...........................38 VDC @ 1.5 Amps
Peak Output Rating* ......................................35 VDC @ 3 Amps
* Measurements taken at 25°C, 120 VAC, 60 Hz.
Rev. 062105
TM
TM
=3A RMS) ......................... 12W
OUT
Range
Range
© Intelligent Motion Systems, Inc.
M e c h a n i c a l S p e c i f i c a t i o n s
Dimensions in Inches (mm)
0.025
(0.6)
18 1
0.410
(10.4)
3.00 2.710
(76.2) (68.8)
0.290
(7.4)
34 17
IM483-34P1
O p t i c a l l y I s o l a t e d I n p u t s
+5VDC Optocoupler Supply P1:4
Step Clock P1:2
(10 MHz max. Freq.)
CW/CCW Direction P1:3
Enable/Disable P1:5
Reset P1:6
Current Limiting Resistor Values
+VDC 5 10 12 15
R –
681 1300
1000
LIMIT
IM483 Input
Controller
Output
R *
LIMIT
1/4 W 1%
Open Collector Interface
* WARNING! An R Current Limiting Resistor is required when the Opto Supply
LIMIT
Voltage is greater than +5VDC.
C o n n e c t o r P 1 - 8 A n d P 1 - 3 4 P i n A s s i g n m e n t s *
8 Pin # 34 Pin # Pin Name
3 Resolution Select 3
4 Step Clock Input
2
Direction Input
3
6
Opto Supply
4 8
10
5
Enable/Disable
6
12
Reset Input
7
14 Fault Output
8
16, 26
On-Full-Step Output
21 Step Clock Output
22 Direction Output
23 Resolution Select 0
24 Resolution Select 2
25
Resolution Select 1
Ground
27
C o n n e c t o r P 2
Pin # Pin Name
Phase Current Reduction Adjustment Input. A resistor
connected between this pin and pin 2 will
proportionately reduce the current in both motor
Current
windings approximately 0.5 seconds after the last
1
Reduction Adjust
positive edge of the step clock input. The amount of
current reduced will depend upon the value of the
resistor used.
Phase Current Adjustment. A resistor is connected
between this pin and P2:3 (GND) to adjust the
Current
2
maximum phase current in the motor. A resistor
Adjustment
MUST be connected to this input or the IM483 WILL
latch into fault.
Power Ground. The ground, or return, of the power
3
GND
supply is connected here.
4
Motor Supply Voltage. +12 to +48 VDC.
+V
—
5
Phase B
Phase B of the stepping motor.
6
Phase B Phase B of the stepping motor.
—
7
Phase A Phase A of the stepping motor.
8
Phase A Phase A of the stepping motor.
For More In for ma tion:
See the com plete IM483 Product Manual
on the IMS Product CD or at www.imshome.com
2.750
(69.9)
2.45
(62.23)
0.150
(3.8)
4X Ø 0.160
(4X Ø 4.1)
470 Ω
HCP0630
+5 VDC
24
2670
Opto Supply P1:4
Controller
Output
TTL Interface
Function
Microstep Resolution Select 3 Input.
A positive going edge on this input advances the motor
one increment. The size of the increment is dependent
upon the settings of the resolution select switch SW1.
This input is used to change the direction of the motor.
Physical direction also depends upon the connection of
the motor windings.
This +5 VDC input is used to supply power to the
isolated logic inputs. A higher voltage may be used, but
care must be taken to limit the current through the
opto-coupler.
This input is used to enable/disable the output section
of the driver. When in a Logic HIGH state (open), the
outputs are enabled. However, this input does not
inhibit the step clock, therefore, the outputs will update
by the number of clock pulses (if any) applied to the
driver while it was disabled.
When LOW, this input will reset the driver (phase
outputs will disable). When released, the driver will be
at its initial state (Phase A OFF, Phase B ON).
This output indicates that a short circuit condition has
occurred. This output is active LOW.
This open collector output indicates when the driver is
positioned at full step. This output can be used to
count the number of full steps the motor has moved,
regardless of the number of microsteps in between.
This output is active LOW.
Non-isolated step clock output follows step input.
Non-isolated direction output follows direction input.
Microstep Resolution Select 0 input.
Microstep Resolution Select 2 input.
Microstep Resolution Select 1 input.
Non-isolated ground. Common with power ground.
Function
—
—
1.20
(30.50)
0.030
(0.8)
1.00
(25.4)
0.312
(7.92)
IM483 Input
