2.6 Assigning I/O Pins
2.6

Assigning I/O Pins

VersaSync's I/O connector is software configurable, i.e. the pin interfaces and the signal mod
ulations can be configured by the user via the VersaSync Web UI.
The software-configurable 26-pin I/O connector comprises 9 user-configurable Channels, plus
one fixed USB interface. Channels can be used for the following input or output interfaces:
20
As of September 2017, some of the functionality (e.g., CAN bus) is still
Note:
under development and has not been enabled yet.
CHAPTER •
2 VersaSync Evaluation Kit Quick Reference Guide Rev. 5
