Status LEDs

VersaSync's front panel status LEDs provide a real-time status overview: Eight (8) LEDs indicate
the unit's current operating state:
The LEDs can be disabled, see "Blackout Mode" on page 17.
2.4.1

Blinking Intervals

The status LEDs can communicate five different operating states:
2.4.2

LED Lighting Patterns

The table below indicates LED status light patterns for common VersaSync operating statuses.
CHAPTER •
2 VersaSync Evaluation Kit Quick Reference Guide Rev. 5
"OFF"
"ON"
"FAST" : blinking interval @ 8Hz
"SLOW" : blinking interval @ 2Hz
"HEARTBEAT" : sinus-shaped interval @ 1Hz
