2.2 Connectors and their Pinouts
2.2

Connectors and their Pinouts

All of VersaSync's connectors are provided at the front panel of the unit, below the Status LEDs.
2.2.1

Power Connector

Table 2-3:
Pin
1
2
3
4
5
2.2.2

Input/Output Connector

VersaSync has a 26- pin input/output connector that offers 8 software- configurable
CHANNELS, plus one fixed DCLS channel, and a USB interface. To learn more about types of
interfaces and signals, and how to configure them, see "Assigning I/O Pins" on page 20.
10
Note: View in mating direction from front.
Power connector pinout
Signal
V (10 to 32 V)
Main
V (10 to 32 V)
Main
V (10 to 32 V)
Batt
GND
GND
