Temptech 56L User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Wine Coolers
USER MANUAL
55L 56L 130L
22L 58L 88L 116L 145L
270L 428L 468L 490L
This manual contains important information including safety and
installation instructions of the appliances. Please read it carefully before
use and follow all safety information & instructions. It is recommended
to keep this manual for easy reference so that you can be familiar with the
operation of the appliance.
V2/2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 56L and is the answer not in the manual?

Questions and answers

Related Manuals for Temptech 56L

Summary of Contents for Temptech 56L

  • Page 1 Wine Coolers USER MANUAL 55L 56L 130L 22L 58L 88L 116L 145L 270L 428L 468L 490L This manual contains important information including safety and installation instructions of the appliances. Please read it carefully before use and follow all safety information & instructions. It is recommended to keep this manual for easy reference so that you can be familiar with the operation of the appliance.

  • Page 2: Table Of Contents

    03 SCRAPPING OLD APPLIANCES Conformity Energy Saving Service 05 DESCRIPTION OF APPLIANCE AND INSTALLATION 55L Control In Cabinet 56L Control On Door 130L Control In Cabinet 22L Control In Cabinet 58L Control In Cabinet 88L Control In Cabinet 116L Control In Cabinet 145L Control In Cabinet-Height:81.3cm...
  • Page 3 Disconnecting From Power 40 TROUBLESHOOTING 41 REVERSE THE DOOR SWING For 55L Control in Cabinet For 56L Control On Door For 130L Control in Cabinet For 116L Control in Cabinet For 22L/58L/88L/145L Control in Cabinet For 270L/428L/468L/490L Control In Cabinet...

  • Page 4: Important Safety Information

    INSTRUCTION MANUAL • Please removed all packaging, stickers and films from the products surface and clean the product’ s surfaces with a damp cloth and mild deturgent before using for the first time. • Let the appliance stand upright for approximately hours before connecting it to the power source, which helps to reduce the possibility of a cooling-system malfunction from handling during transportation.
  • Page 5 INSTRUCTION MANUAL ● Do not excessively pull or fold the power cord or touch the plug with wet hands. ● Do not damage the plug and/or the power cord; this could cause electrical shocks or fires. ● It is recommended to keep the plug clean, any excessive dust residues on the plug can be the cause fire.

  • Page 6: Scrapping Old Appliances

    INSTRUCTION MANUAL Children should be supervised to ensure that they do not play with the appliance. ● The appliance must be positioned so that the plug is accessible ● If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

  • Page 7: Conformity

    INSTRUCTION MANUAL In many countries, when you buy a new appliance, the old one may be returned to the retailer who has to collect it free of charge on a one-to-one basis, as long as the equipment is of equivalent type and has the same functions as the supplied equipment.

  • Page 8: Description Of Appliance And Installation

    INSTRUCTION MANUAL DESCRIPTION OF APPLIANCE AND INSTALLATION The following pictures only show description of appliance. The dimension and shelf quantity may diff er among the models of the same series. „ 55L Control In Cabinet Single Zone Bottles Control Panel Beech Shelves Glass Door Handle...
  • Page 9 To fix the appliance with Cabinet, pls. screw the 4 screws (ST4.2*12mm) through the Top Bracket. The Top Bracket is pre-installed on top of appliance. A. Top Bracket B. 4�Screws (ST4.2*12mm) „ 56L Control On Door Single Zone Bottles Door Control Panel...
  • Page 10 INSTRUCTION MANUAL 31in Min. (200cm Min.) ¾” (23mm) ⁄ ” Min. (8mm) Min. 18 ⁄ ” Min. (461mm) Min. 17¾” (453mm) ⁄ ” Min. (8mm) Min. 17 ⁄ ” (455mm) 17¾” (451mm) ” ⁄ (3mm) 31in Min. (200cm Min.) ⁄ ” (3mm) .07.
  • Page 11 INSTRUCTION MANUAL Front view of cabinet and Wine Cooler 1. Before inserting the unit into the kitchen cabinet, please unscrew the (in white), and screw the 2�short leveling original 4�leveling feet (in black) , which are packed as the accessory, to the front feet bottom of the unit.
  • Page 12 INSTRUCTION MANUAL „ 130L Control In Cabinet Dual Zone Bottles Door Condenser Outside Cabinet Long Shelf Handle Control Panel Gasket Short Shelf Adjustable Foot 31in Min. (200cm Min.) ¾” (23mm) ⁄ ” Min. (8mm) Min. (886mm) (878mm) Min. (8mm) Min. (885mm) 34½”...
  • Page 13 INSTRUCTION MANUAL Front view of cabinet and Wine Cooler .10.
  • Page 14 INSTRUCTION MANUAL 1. Before inserting the unit into the kitchen cabinet, please unscrew the original 4�leveling feet (in white), and screw the 2�short leveling (in black) , which are packed as the accessory, to the front feet bottom of the unit. 2.
  • Page 15 INSTRUCTION MANUAL „ 58L Control In Cabinet Single Zone Dual Zone Single & Dual Zone Bottles Bottles Door Control Panel Outside Cabinet Long Shelf Handle Control Panel Gasket Short Shelf Front Louver Adjustable Foot • Height Adjustable: 863-883mm .12.
  • Page 16 INSTRUCTION MANUAL „ 88L Control In Cabinet Dual Zone Single & Dual Zone Single Zone Bottles Bottles Control Panel Door Outside Canbinet Long Shelf Handle Control Panel Gasket Short Shelf Front Louver Adjustable Foot • Height Adjustable: 853-873mm >33 ⁄ ”(860) 337 ⁄...

  • Page 17: Control In Cabinet

    INSTRUCTION MANUAL „ 116L Control In Cabinet Left & Right Zone Bottles Control Panel (Left ) Door Outside Cabinet Control Panel(Right) Handle Long Shelf Gasket Short Shelf Front Louver Adjustable Foot • Height Adjustable: 863-883mm >34¼” (863) 34¼” (863) 33½” (850) (150) .14.
  • Page 18 INSTRUCTION MANUAL „ 145L Control In Cabinet-Height:81.3cm Single Zone Dual Zone Single & Dual Zone Bottles Bottles Door Control Panel Outside Canbinet Long Shelf Handle Control Panel Gasket Short Shelf Adjustable Front Louver Foot • Height Adjustable: 813-833mm >32 ⁄ ” (813) 32 ⁄...
  • Page 19 INSTRUCTION MANUAL „ 145L Control In Cabinet-Height:86.3cm Single Zone Dual Zone Single & Dual Zone Bottles Bottles Door Control Panel Outside Canbinet Handle Long Shelf Control Panel Gasket Short Shelf Adjustable Front Louver Foot • Height Adjustable: 863-883mm .16.
  • Page 20 INSTRUCTION MANUAL „ 145L Control On Door-Height:86.3cm Single Zone Dual Zone Single & Dual Zone Bottles Bottles Door Outside Canbinet Control Panel Long Shelf Handle (W/ 3-fold Rail) Gasket Short Shelf (W/ 2-fold Rail) Adjustable Front Louver Foot • Height Adjustable: 863-883mm .17.
  • Page 21 INSTRUCTION MANUAL „ 270L Control In Cabinet Single Zone Dual Zone Single & Dual Zone Bottles Bottles Door Control Panel Outside Canbinet Long Shelf Handle Control Panel Gasket Short Shelf Adjustable Front Louver Foot 1215mm ≥ (47 ¾”) 1215mm (47 ¾”) .18.
  • Page 22 INSTRUCTION MANUAL „ 428L Control In Cabinet Single Zone Dual Zone Single & Dual Zone Bottles Bottles Control Panel Door Outside Canbinet Long Shelf Handle Control Panel Gasket Short Shelf Front Louver Adjustable Foot 1770mm ≥ (69 ¾”) 1770mm (69 ¾”) .19.
  • Page 23 INSTRUCTION MANUAL „ 468L Control In Cabinet Single Zone Dual Zone Single & Dual Zone Bottles Bottles Control Panel Door Outside Canbinet Vintage Shelf Handle Control Panel 癈 癈 癋 癋 Gasket Front Louver Adjustable Foot 1835mm ≥ ¼”) 1835mm (72 ¼”) .20.
  • Page 24 INSTRUCTION MANUAL „ 490L Control In Cabinet Single Zone Dual Zone Single & Dual Zone Bottles Bottles Control Panel Door Outside Canbinet Long Shelf Handle Control Panel Gasket Short Shelf Front Louver Adjustable Foot 1835mm ≥ ¼”) 1835mm (72 ¼”) .21.
  • Page 25 INSTRUCTION MANUAL „ 490L Control On Door Single Zone Dual Zone Single & Dual Zone Bottles Bottles Control Panel Door Outside Canbinet Long Shelf Handle Control Panel Gasket Short Shelf Front Louver Adjustable Foot 1835mm ≥ ¼”) 1835mm (72 ¼”) .22.

  • Page 26: 490L Control On Door-Five Strong Shelves

    INSTRUCTION MANUAL „ 490L Control On Door-Five Strong Shelves Single Zone Dual Zone Singele & Dual Zone  Bottles  Bottles Door Control Panel Outside Cabinet Strong Shelf Handle Gasket Adjustable Front Louver Foot 1835mm ≥ ¼”) 1835mm (72 ¼”) .23.

  • Page 27: 490L -Tripe Zone Control In Cabinet

    INSTRUCTION MANUAL „ 490L -Tripe Zone Control In Cabinet Triple Zone Bottles Door Outside Canbinet Control Panel (Upper Zone) Long Shelf Handle Control Panel Gasket (Mid & Lower Zone) Short Shelf Adjustable Front Louver Foot 1835mm ≥ ¼”) 1835mm (72 ¼”) .24.

  • Page 28: Accessory Installation Before Operating

    • Use a soft cloth to clean the interior surface with lukewarm water. For all models except 55L, 56L, 130L IMPORTANT: The front louver at the base of the appliance is for ventilation. Nothing should be placed in front of this front louver; otherwise your Wine Cooler may not operate properly.

  • Page 29: Installing The Handle

    INSTRUCTION MANUAL IMPORTANT: If the appliance is not level, then the door and door seal may be aff ected. IMPORTANT: Do not move the appliance when the feet are adjusted high. „ Installing The Handle Gasket Handle Washer Handle Screws ●...

  • Page 30: Wine Storage

    INSTRUCTION MANUAL • If the ambient temperature is above or below the designed climate range, the performance of the unit may be affected. For example, the appliance operating in extreme cold or hot conditions may cause interior temperatures to fluctuate, and the temperature set 5-22°C may not be reached sometimes.

  • Page 31: Control Panel (Control In Cabinet)

    INSTRUCTION MANUAL „ CONTROL PANEL (Control In Cabinet) • For Single Zone A. Power B. Lighting C. Display Window D. Temp. Plus E. Temp.Minus F. Lock / Unlock G. Function Indicator H. ºC/ºF Switch ** For models of 116L, it is without the Function Indicator •...

  • Page 32: Unlocking The Control Panel

    INSTRUCTION MANUAL Warning: To avoid damaging the compressor, please do not turn on the appliance again within 5 minutes after you turn it off. „ UNLOCKING THE CONTROL PANEL • To unlock the control panel, touch the power mark and lighting mark with 2 fingers at the same time and hold for 3 seconds .
  • Page 33 INSTRUCTION MANUAL Display Temp.Range (Single Zone) 5 - 22 °C (41 ºF-72ºF) E (Default) 2 - 20 °C (36 ºF-68ºF) 10 - 19 °C (50 ºF-66ºF) 0 - 20 °C (36 ºF-68ºF) * For models of 116L, the defualt temperature setting range is: 5-22 ºC (41-72 ºF) for Left Zone, 2 - 22 °C (36ºF-72ºF) for Right Zone.

  • Page 34: Selecting Fahrenheit(ºf) & Celsius (ºc) Display

    INSTRUCTION MANUAL For Dual Zone • The default temperature setting ranges are E: 5-12 ºC (41-54 ºF ) for the upper zone and 12-22 ºC (54-72 ºF ) for the bottom zone. • You need to select the set zone by touching the mark before touching the mark to set the desired temperature.

  • Page 35: Function Indicating Light

    INSTRUCTION MANUAL „ FUNCTION INDICATING LIGHT For Single Zone o When the compressor starts to work, the Indicator will stay o In other conditions, the Indicator will be off. Function Indicator For Dual Zone o The Indicator 1 will flash every 2 seconds when the unit is plugged in;...

  • Page 36: Control Panel 145L, 490L Control On Door

    INSTRUCTION MANUAL „ CONTROL PANEL 145L, 490L Control On Door • For Single Zone Power °C/°F Display Window Temp.Up Temp.Range Set Set Temp. Actual Temp. Light Unlock On/Off Temp.Down • For Dual Zone Power °C/°F Display Window Temp.Up Temp.Range Set Upper Zone Lower Zone Light Unlock On/Off Temp.Down...
  • Page 37 INSTRUCTION MANUAL „ UNLOCKING THE CONTROL PANEL • Press for 3 seconds to unlock the control panel. Unlock „ INTERIOR LIGHTING ON/OFF CONTROL • Your wine cellar comes equipped with 3 different lighting options: Red, Blue, or a Red & Blue cycle where the color changes every 10 seconds. Press the light button once and the lights will run on a 10-second cycle, alternating between Red &...
  • Page 38 INSTRUCTION MANUAL • Press to increase setting temperature by 1 Temp.Up • Press to decrease setting temperature by 1 Temp. Down • Press to change the temperature set-range among E, F, H, L, and leave it for 3 seconds to confirm your option. Your wine cellar is originally set as “ ”, the ideal temperature for the storage of red wine.

  • Page 39: Temperature Display Window

    INSTRUCTION MANUAL TEMPERATURE DISPLAY WINDOW „ For Single Zone • Set temperature of the wine cellar. • Actual temperature of the wine cellar. • Display Window is on. • Display Window is Off The temperature display will show the set temperature when the Wine Cooler control panel is unlocked and selected to be reset, and show the actual temperature when the control panel is locked.

  • Page 40: Care And Maintenance

    INSTRUCTION MANUAL Note: Temperatures may fluctuate depending on whether the interior light is ON or OFF and depending on the position of the bottles. CARE AND MAINTENANCE „ CLEANING THE WINE COOLER • Turn off the power, unplug the appliance, and remove all items including shelves. •...

  • Page 41: Carbon Filter Change (Option)

    INSTRUCTION MANUAL • For a model with Telescopic Rail, pls. lift the whole Shelf upwards horizontally to get it off from the 4 Locating Pins of Telescopic Rail. Stopper Locating Pin „ Carbon Filter Change (Option) A good ambient air quality is important for wine maturing. The Carbon Filter is very helpful to absorb odor and improve air quality.For the models with Carbon Filter, we suggest to replace it once a year.Pls.contact your dealer to get the fi lter.

  • Page 42: Moving Your Wine Cooler

    INSTRUCTION MANUAL „ Moving Your Wine Cooler If you need to move your Wine Cooler to another location you should follow the steps outlined below. o Remove all items from the Wine Cooler. o Securely tape down all loose items such as the shelves inside of the appliance.

  • Page 43: Troubleshooting

    INSTRUCTION MANUAL TROUBLESHOOTING If you feel the appliance is not working properly, follow these instructions to try to see if you can solve the problem simply by yourself before calling for service. PROBLEM PROBLEM POSSIBLE CAUSE / MEASURE Not plugged in. The wine cooler does not operate The appliance is turned off.

  • Page 44: Reverse The Door Swing

    INSTRUCTION MANUAL REVERSE THE DOOR SWING Remarks: ● The following operations are available for a model with control in cabinet only and with Right Door Hinge installed. ● All removed parts must be saved in order to do the door reinstallation. „...
  • Page 45 INSTRUCTION MANUAL o Unscrew the 3 screws from Top Bracket, move the bracket to the right end and screw the 3 crews. o Rotate the door 180˚ (upside down). .42.

  • Page 46: For 56L Control On Door

    Screw the 4 screws of the upper hinge and bottom hinge tightly to fi x the door in place. „ For 56L Control On Door ● To reverse the door, a professional instruction is needed, pls.contact with your local dealer for help.
  • Page 47 INSTRUCTION MANUAL Unscrew the Upper Mounting Bar and Lower Mounting Bar, remove this two bars from left side to the right edge of the unit. Fix this two bars by screwing it through the leftmost screw holes. Upper Mounting Bar Lower Mounting Bar Unscrew the Upper Hinge and Lower Hinge from the right side of door, move and screw the...
  • Page 48 INSTRUCTION MANUAL Remove the Handle Hole Cap (2pcs) on the right side of Door by prying it out gently with small flat screwdriver. Handle Hole Cap Gently pull the door gasket to one side to reveal the Handle Screws (2pcs) on the left side of the Door.Unscrew it with a cross screwdriver and Remove the Handle (Leave the Washers as where it is).
  • Page 49 INSTRUCTION MANUAL Install the Handle to the right side of the door by screwing tightly the Handle Screws (2PCS). Handle Screw Washer Handle Push the Handle Hole Cap (2pcs) into the Handle Holes on the left side of the Door. Handle Hole Cap .46.

  • Page 50: For 22L/58L/88L/145L Control In Cabinet

    INSTRUCTION MANUAL Screw the 8 screws of Upper Hinge and Bottom Hinge tightly one by one. Screws (4pcs) Upper Hinge Bottom Hinge Screws (4pcs) „ For 116L Control in Cabinet • The unit is with Left and Right door, it is no need to do door reversal. „...
  • Page 51 INSTRUCTION MANUAL Carefully remove the door from the Upper Right Hinge and prevent it from scratching. Take out the Pivot Hinge from the door hinge hole. Upper Right Hinge Door Bottom Right Hinge Pivot Hinge Min. Unscrew the Upper Right Hinge and Bottom Right Hinge from the cabinet. Keep them well for door re-installation.
  • Page 52 INSTRUCTION MANUAL Install the Upper Left Hinge and Bottom Left Hinge to the left side of the cabinet. Make sure the screws are tightened. Upper Left Hinge Bottom Left Hinge Move the Hinge Hole Cap (at the top of the door) from the left side to the right side. Hinge Hole Cap .49.
  • Page 53 INSTRUCTION MANUAL Remove the Handle Hole Cap (2pcs) on the right side of Door by prying it out gently with small flat screwdriver. Handle Hole Cap Gently pull the door gasket to one side to reveal the Handle Screws (2pcs) on the left side of the Door.Unscrew it with a cross screwdriver and Remove the Handle (Leave the Washers as where it is).
  • Page 54 INSTRUCTION MANUAL Install the Handle to the right side of the door by screwing tightly the Handle Screws (2PCS). Handle Screw Washer Handle .Push the Handle Hole Cap (2pcs) into the Handle Holes on the left side of the Door. Handle Hole Cap .51.
  • Page 55 INSTRUCTION MANUAL .Insert the Pivot Hinge into the bottom hinge hole of the door. Pivot Hinge .Install the door to the left hinge side by tightening the Pivot Hinge with the 2 screws. Bottom Left Hinge Pivot Hinge Screws (2pcs) .52.
  • Page 56 INSTRUCTION MANUAL „ For 270L/428L/468L/490L Control In Cabinet IMPORTANT İNFORMATİON We recommend that you secure the racks in place using adhesive tape to prevent causing damage when handling the appliance and store all removed parts carefully. Remove the Hole Cover and Upper Hinge Cover on top side using a flat-head screwdriver. Remove the Upper Hinge by unscrewing the Hex Head Srews (4pcs).
  • Page 57 INSTRUCTION MANUAL Remove the Bottom Hinge Cover by prying it off gently with small flat screwdriver. Remove the Bottom Hinge by unscrewing the Hex Head Screw (4pcs). Unscrew the Pan Head Screw (4pcs) from bottom left side. Now move the Bottom Hinge to the bottom left side and screw it tightly with the Hex Head Screws (4pcs).
  • Page 58 INSTRUCTION MANUAL Remove the Handle Hole Cap (2pcs) on the right side of Door by prying it out gently with small flat screwdriver. Handle Hole Cap Gently pull the door gasket to one side to reveal the Handle Screws (2pcs) on the left side of the Door.Unscrew it with a cross screwdriver and Remove the Handle (Leave the Washers as where it is).
  • Page 59 INSTRUCTION MANUAL nstall the Handle to the right side of the door by screwing tightly the Handle Screws (2PCS). Handle Screw Washer Handle Push the Handle Hole Cap (2pcs) into the Handle Holes on the left side of the Door. Handle Hole Cap --END-- .56.
