Rotel RSX-1067 Technical Manual

Surround sound receiver

Hide thumbs Also See for RSX-1067:

Command list (6 pages)

Owner's manual (48 pages)

Brochure & specs (4 pages)

See also: Owner's Manual

T echnical

Manual

Specification......................................1

Parts List...........................................2~14

Upgrade............................................15

Disassembly Diagram &List..............16~17

Specifications

Audio

Continuous Amplifier Power

(seven channels driven)

100 watts/ch (20-20k Hz, <0.05% THD, 8 ohms)

Continuous Amplifier Power

(two channels driven)

120 watts/ch (1kHz, <1.0% THD, 8 ohms, DIN)

Total Harmonic Distortion

<0.05%

Intermodulation Distortion (60 Hz:7 kHz)

<0.05%

Frequency Response

10 Hz - 120 kHz, ±3dB (analog bypass)

10 Hz - 95 kHz, ±3dB (digital input)

Signal to Noise Ratio (IHF A-weighted)

95dB (analog bypass)

92dB (Dolby Digital, dts) 0dBFs

Input Sensitivity/Impedance

Line Level: 200 mV/100K ohms

Preamp Output Level/Output Impedance

1.0 V / 1K ohms

Contour (LF/HF)

±6dB at 50 Hz/15 kHz

Decodable Digital Input Signals

Dolby Digital, Dolby Digital EX, DTS, DTS-ES,

DTS 96/24, LPCM (up to 192K), HDCD, MP3,

MPEG Multichannel

Video

Frequency Response

3 Hz - 10 MHz, ± 3dB (Digital Input)

3 Hz - 100 MHz, ± 3dB (Component V ideo)

Signal to Noise Ratio

45dB

Input Impedance

75 ohms

Output Impedance

75 ohms

Output Level

1.0 volt

THE ROTEL CO., LTD.

SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU,

TOKYO 150-0045, JAPAN

Quality Uncompromised

FM Tuner

Usable Sensitivity

14.2dBf

Signal to Noise Ratio (at 65dBf)

70dBf

Harmonic Distortion (at 65 dBf)

0.03%

Stereo Separation (1 kHz)

45dB

Output level

1 V

Antenna Input

75 ohms unbalanced

AM Tuner

Sensitivity

500 m V/m

Signal to Noise Ratio

40dBf

Output level

500 mV

Antenna Input

Loop Antenna

General

Power Consumption:

990 watts

130 watts (idle)

19 watts (standby)

Power Requirements (AC)

115 volts, 60Hz (USA version)

230 volts, 50Hz (CE version)

Weight

20.4 Kg/44.97 lb.

Dimensions (W x H x D)

432 x 189 x 427 mm

17.01" x 7.44" x 16.81"

Front Panel Height

(feet removed for rack mount)

176 mm / 6.93"

SURROUND SOUND RECEIVER

RSX-1067

Wiring................................................18

PCB Assembly..................................19~25

Schematic Diagram ..........................26~41

Serial. NO.

Beginning

Y-373A-0403/pdf

Table of Contents

Need help?

Do you have a question about the RSX-1067 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rotel RSX-1067

Page 1: Table Of Contents
17.01" x 7.44" x 16.81" Output Impedance Front Panel Height 75 ohms (feet removed for rack mount) Output Level 176 mm / 6.93" 1.0 volt Serial. NO. THE ROTEL CO., LTD. Beginning SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU, Y-373A-0403/pdf TOKYO 150-0045, JAPAN...
Page 2 RSX-1067 Appearance Surround Sound Receiver SURROUND SOUND RECEIVER RSX-1067 VOLUME TUNER TAPE VIDEO1 VIDEO2 VIDEO3 VIDEO4 VIDEO5 DOLBY MULTI PL /3ST Neo 6 INPUT MUTE ZONE TUNING BAND STANDBY DIRECT MONO MEMORY FRONT L REAR L CB 1 CENTER Manufactured under license from Digital...
Page 3: Parts List 1/10
RSX-1067 Parts List 1/10 SYMBOL.NO PARTS NO. DESCRIPTION 016 E-1309A00 PCB ASSY 501 E-1309 PCB ASSY (FL DISPLAY) IC34 031 SBX3010-52B REMOTE MODULE (REMOTE EYE) IC31,32,33 031 TD62C950RF IC (FL DRIVER) SMD FL31 035 HNR22ML02 FL TUBE 037 KDS184RTK DIODE CHIP...
Page 4 RSX-1067 Parts List 2/10 SYMBOL.NO PARTS NO. DESCRIPTION R502-504,602-604,702-704 054 TMF16-3302 METAL RESISTOR 1/6W 33K R113,114,213,214,313,314,413,414 054 TMF16-3302 METAL RESISTOR 1/6W 33K R513,514,613,614,713,714 054 TMF16-3302 METAL RESISTOR 1/6W 33K R105,205,305,405,505,605,705 054 TMF16-4700 METAL RESISTOR 1/6W 470 R116,216,316,416,516,616,716 054 TMF16-4700 METAL RESISTOR 1/6W 470...
Page 5 RSX-1067 Parts List 3/10 SYMBOL.NO PARTS NO. DESCRIPTION R294,295,348-351,376,411-414 055 ERJ6GEYJ104V RESISTOR CHIP 100K R446 055 ERJ6GEYJ105V RESISTOR CHIP 1M R444 055 ERJ6GEYJ122V RESISTOR CHIP 1.2K R450 055 ERJ6GEYJ181V RESISTOR CHIP 180 R367,368 055 ERJ6GEYJ182V RESISTOR CHIP 1.8K R296,297 055 ERJ6GEYJ182V RESISTOR CHIP 1.8K...
Page 6 RSX-1067 Parts List 4/10 SYMBOL.NO PARTS NO. DESCRIPTION C301-304,310,321,334-336,345,356 047 ECJ2VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF C372,373,376,385,386 047 ECJ2VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF C317,322,352,357 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF C365 047 ECJ2VG1H102J CERAMIC CAPACITOR CHIP 1000pF C366 047 ECJ2VG1H221J CERAMIC CAPACITOR CHIP 0.0022uF...
Page 7 RSX-1067 Parts List 5/10 SYMBOL.NO PARTS NO. DESCRIPTION IC402 031 IS62C256 IC (SRAM) IS62C256 SMD IC439 031 K4S161622D IC (MEMORY) K4S161622D SMD IC406,407 031 LTV817 IC (PHOTO COUPLER) IC433-435,451-454 031 TL072CD IC (OPE DUAL) TL072CD SMD IC401 031 TMP95C063F IC (CPU) TMP95C063F SMD...
Page 8 RSX-1067 Parts List 6/10 SYMBOL.NO PARTS NO. DESCRIPTION R404,420-425 055 ERJ6GEYJ472V RESISTOR CHIP 4.7K R419 055 ERJ6GEYJ472V RESISTOR CHIP 4.7K R429,449,450,474,475,4394,5383 055 ERJ6GEYJ473V RESISTOR CHIP 47K RAL/R403 055 ERJ6GEYJ473V RESISTOR CHIP 47K RBL/R451-453,455,456,RCT451-453,455,456 055 ERJ6GEYJ562V RESISTOR CHIP 5.6K RFL/R451-453,455,456,RSW451-453,455,456 055 ERJ6GEYJ562V RESISTOR CHIP 5.6K...
Page 9 RSX-1067 Parts List 7/10 SYMBOL.NO PARTS NO. DESCRIPTION RBL/R704,RCT704,RSL/R704 055 ERJ6GEYJ122V RESISTOR CHIP 1.2K RBL/R703,RCT703,RMW706,707,RSL/R703 055 ERJ6GEYJ123V RESISTOR CHIP 12K RSW709 055 ERJ6GEYJ153V RESISTOR CHIP 15K R721-730,RMW705 055 ERJ6GEYJ182V RESISTOR CHIP 1.8K RSW703 055 ERJ6GEYJ203V RESISTOR CHIP 20K R701,702,706,707,711,712,716,717 055 ERJ6GEYJ221V...
Page 10 RSX-1067 Parts List 8/10 SYMBOL.NO PARTS NO. DESCRIPTION JAK501,503,504 067 C-4761A01 4P SPEAKER TERMINAL JAK502 067 C-4762A01 2P SPEAKER TERMINAL CP501-504 068 B2P-VH 2P CONNECTOR POST 016 X-1403C01-04 PCB ASSY 501 X-1403 PCB ASSY (POWER) HS1-HS5 017 C-4682A11 SUB HEAT SINKER H=60 (BLK)
Page 11 RSX-1067 Parts List 9/10 SYMBOL.NO PARTS NO. DESCRIPTION CP120 068 B7P-VH CONNECTOR WAFER CP105-109,112,130,131 068 B2P3-VH CONNECTOR WAFER F1090(2),1091(2) 069 C-4865A00 LONG FUSE CLIP FC61B CP303 069 B1P-LA-TA 1P LA PIN 016 X-1404C01-02 PCB ASSY 501 X-1404 PCB ASSY (FRONT) 023 CST16.0MXW...
Page 12 RSX-1067 Parts List 10/10 SYMBOL.NO PARTS NO. DESCRIPTION CP123,124 024 SE2408PTB1-0260 FAN MOTOR WITH CONNECTOR 034 SEL1124R LED (RED) 1X5 034 SEL1E24W LED (BLU) 1X5 069 18-24 F CONNECTOR 069 C-4629A01 AC 2P INLET 6102.3100 071 RE4-11A03 BOLT SCREW 8X110MM...
Page 13 Addendum List for Black and Silver RSX1067 SYMBOL PARTS DESCRIPTION 011 FP-567-B BLACK PANEL ASSY 011 FP-567-S SILVER PANEL ASSY 011 UY3-01A00 H/S PANEL H176 012 RV4-09A00 PUSH BUTTON 14F (BLK) 012 RV4-09A01 PUSH BUTTON 14F (SLV) 012 TB3-16A00 KNOB 44F NO MARK (BLK) 012 TB3-16A00S KNOB 44F NO MARK (SLV) 012 TB3-17A00...
Page 14 <MEMO> 1. Light-up ALL FL segments to check: Press “2CH” and “MUTE” of front panel while turn on the rear panel master power switch. When release the lighting, press STANDBY switch or master power switch.
Page 15: Upgrade
2. Remove all of connections between RSX-1067 and other equipments. 3. Connect RSX-1067 and PC with RJ45/DB9 cable. RJ45 jack should be connected to COMPU TER I/O port in RSX-1067 rear panel. DB9 jack will be connected to PC serial port (ex. COM1 or COM2,,,).
Page 16 PARTS NO. DESCRIPTION PARTS NO. DESCRIPTION 51 024 SE2408PTB1-0260 FAN 014 TD3-08A00 UPPER COVER 52 019 4TSH-19#2 FOOT 011 TD3-01B00 H/S PANEL 013 TD4-11A00 SUPPORT SIDE (2EA) 53 016 E-1325A00 TUNER PCB 013 SG4-14D00 SUPPORT B (2EA) 54 071 4TVL-7#12 CYNDER BUSH H=35 013 UY4-06A00 HS SUPPORT (A)
Page 17: Disassembly Diagram &List
RSX-1067 Disassembly Diagram...
Page 18: Wiring
RSX-1067 Wiring Diagram...
Page 19: Pcb Assembly - 1/7
RSX-1067 PCB Assembly - 1/7 Front PCB 016X-1404C01~02 FIP PCB 016E-1309A00 Top side view FIP PCB 016E-1309A00 Bottom side view Speaker Terminal PCB 016E-1402A00...
Page 20 RSX-1067 PCB Assembly - 2/7 Input PCB 016 E-1397C00 Input PCB Top View Input PCB Bottom View...
Page 21: Video
RSX-1067 PCB Assembly - 4/7 Video PCB 016 E-1398E00 Top View Bottom View...
Page 22 RSX-1067 Digital PCB 016 E-1399C00 PCB Assembly - 3/7 Top View Bottom View...
Page 23 PCB Assembly - 5/7 RSX-1067 Multi-Input PCB 016 E-1401A00 Output PCB 016 E-1400 Top View Top View Bottom View Bottom View...
Page 24 RSX-1067 PCB Assembly - 6/9 Power Amplifier PCB 016 X-1358A01 - 02 Top View Bottom View...
Page 25 PCB Assembly - 7/7 Power PCB 016 X-1403C01 - 04 Top View Bottom View...
Page 26 Block Diagram RSX-1067...
Page 27 RSX-1067 Level Diagram...
Page 28: Schematic Diagram
Schematic Diagram (1/14) RSX-1067 Input PCB (1/3) 016 X -1397C00...
Page 29 Schematic Diagram (2/14) RSX1067 Input PCB (2/3) 016 X-1397C00...
Page 30 RSX-1067 Schematic Diagram (3/14) Input PCB (3/3) 016 X-1397C00...
Page 31 RSX-1067 Schematic Diagram (4/14) Front PCB 016 X-1404C01~02 STANDBY SW Nov.13.'03...
Page 32 RSX-1067 Schematic Diagram (5/14) FIP PCB 016 E-1309A00 Multi-input PCB 016 E-1401A00...
Page 33: Video
RSX-1067 Schematic Diagram (6/14) Video PCB (1/2) 016E-1398E00...
Page 34 RSX-1067 Schematic Diagram (7/14) Video PCB (2/2) 016E-1398E00...
Page 35 RSX-1067 Schematic Diagram (8/14) Digital PCB (1/2) 016 E-1399C00...
Page 36 RSX-1067 Schematic Diagram (9/14) Digital PCB (2/2) 016 E-1399C00...
Page 37 Schematic Diagram (10/14) RSX-1067 Output PCB (1/3) 016 E-1400B00...
Page 38 RSX-1067 Schematic Diagram (11/14) Output PCB (3/3) 016 E-1400B00 Speaker Terminal PCB 016 E-1402A00...
Page 39 RSX-1067 Schematic Diagram (12/14) Power Amp PCB 016 X-1358A01~02...
Page 40 RSX-1067 Schematic Diagram (13/14) Power PCB 016 X-1403C01~04...
Page 41: Schematic Diagram
RSX-1067 Schematic Diagram (14/14) Tuner Module 092 MB114MA-1-1B "...
Page 42 Addendum List for Black and Silver RSX1067 SYMBOL PARTS DESCRIPTION 011 FP-567-B BLACK PANEL ASSY 011 FP-567-S SILVER PANEL ASSY 011 UY3-01A00 H/S PANEL H176 012 RV4-09A00 PUSH BUTTON 14F (BLK) 012 RV4-09A01 PUSH BUTTON 14F (SLV) 012 TB3-16A00 KNOB 44F NO MARK (BLK) 012 TB3-16A00S KNOB 44F NO MARK (SLV) 012 TB3-17A00...
