Clarion XMD3 Owner's Manual

Clarion Co., Ltd.
All Rights Reserved. Copyright © 2003: Clarion Co., Ltd.
2003/3 (D•C)
Printed in China / Imprimé en Chine / Impreso en China / Stampato in Cina
280-7867-00/XMD3_cover 1
Owner's manual
Mode d'emploi
Manual de instrucciones
Istruzioni per l'uso
XMD3
AM/FM MARINE CD PLAYER
RADIO AM/FM-LECTEUR CD MARIN
REPRODUCTOR DE DISCOS COMPACTOS
NÁUTICO CON RADIO DE AM/FM
RADIO AM/FM CON LETTORE CD PER
USO MARITTIMO
PE-2588B
280-7867-00
Thank you for purchasing this Clarion product.
∗ Please read this owner's manual in its entirety before operating this equipment.
∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.
∗ This manual includes the operating procedures of the CD changer, MD changer, AUX, and TV tuner connected via the CeNET
cable. The CD changer, MD changer and TV tuner have their own manuals, but no explanations for operating them are described.
Contents
1. FEATURES ........................................................................ 2
2. CONTROLS ....................................................................... 3
3. PRECAUTIONS ................................................................. 4
Handling Compact Discs .................................................... 5
4. NOMENCLATURE ............................................................. 6
Names of the Buttons and their Functions ......................... 6
Major Button Operations when External Equipment is
Connected to This Unit ....................................................... 7
Display Items ...................................................................... 8
LCD Screen ........................................................................ 8
1. FEATURES
G Exclusive Marinized Front Panel
G Water Sealed Media Access Door
G Conformally Coated Microprocessor
G Input for Marine Wired Remote Control
G 2 Band Parametric EQ (Z-Enhancer Plus)
G White Positive LCD
G CeNET Control of Optional: TV Tuner, 6 Disc CD Changer, Sirius Satellite Radio Receiver
G Subwoofer Level Control
G 4 Channel RCA Line Level Output
G 208 Watt (52W ✕ 4)
G
® Tuner with 18 FM/ 6 AM Presets
G Magna Bass EX
G Built in Low Pass Crossovers (off/50Hz/80Hz/120Hz)
2/20/03, 3:48 PM
5. WIRED REMOTE CONTROL UNIT OPERATIONS ........... 9
6. OPERATIONS .................................................................. 10
Basic Operations .............................................................. 10
Radio Operations ............................................................. 12
CD Operations .................................................................. 13
Operations Common to Each Mode ................................. 14
7. OPERATIONS OF ACCESSORIES ................................. 16
CD/MD Changer Operations ............................................ 16
TV Operations .................................................................. 17
8. IN CASE OF DIFFICULTY ............................................... 19
9. ERROR DISPLAYS .......................................................... 20
10. SPECIFICATIONS ............................................................ 21
2
XMD3
