Section 1: Product Overview
1
2
4
5
1 IR LEDs (behind cover)
2 Light Sensor
3 Microphone
4 180-Degree Camera Lens
5 Status LED
MicroUSB Port
6
(for power)
7 microSD Card Slot
8 Reset Button
D-Link DSH-C310 User Manual

Hardware Overview

3
6
Infrared LEDs illuminate the camera's field of view at night
Detects ambient light to automatically switch between day and night mode
Picks up audio from surrounding area
Fixed lens to record video of the surrounding area
Indicates the connection status of the camera
Connects to the power adapter
Insert a microSD card to record video when motion is detected
Press and hold for 10 seconds to reset camera back to the factory default
settings
7
8
5
