DV425/DV425GPS
4CH HD BLACK BOX RECORDER with WiFi

SPECIFICATIONS

- Record Type:
- GPS:
- WiFi:
- Max Resolution:
- Max Card Supported:
- Card Type:
- Continuous Recording (Approx):
- Real Time Recording:
- G-Sensor:
- Motion Detection:
- Recording Output:
- AV Output:
- Monitor View:
- Video Compression:
- Reverse Camera Compatible:
- Camera Connection:
- Lockable SD Cards:
- HDD Support:
- Operating Voltage:
- Alarm Inputs:
- Alarm Outputs:
- Ignition Signal:
- Speed Signal:
- Timer Recording:
- Adjustable Frame Rate & Bit Rate:
- Individual Camera Adjustment:
- User Password Protection:
- Operating Temperature:
- Power Consumption:
- Dimensions:
INSTRUCTION MANUAL
Quad
Yes (DV425GPS)
Yes
1920 x 1080 (100FPS)
4 x 128GB MLC Type
SD/SDHC/SDXC cards
76 Hours 4 x 1080P @ 4Mbps
Yes - Auto or Scheduled
Yes
Yes
USB & HDD Video Recording & Backup
Touchscreen Compatible HDMI, 2 x CVBS
(RCA & 6 Pin)
Normal/Mirror Image Selectable
H.264 for High Quality Video
Yes, compatible with systems that have motorized
cameras and adjustable grid lines
4-Pin
Yes
Up to 2TB HDD
9 to 36V
8 CH
2 CH
Yes
Yes
Yes
Yes
Contrast, Hue, Brightness, Colour
Yes
-20°C to 70°C
15W (Working)
178W x 50H x 171Dmm
INCLUDED
- Lock Key
- Remote Control
- GPS Antenna (DV425GPS)
- 6P to 4P A/V Conversion Cable
- 3V Out Cable for External GPS
- 4 Pin (Female) to 4 Pin (Female) Fly Lead
- Installation Manual
- Installation Hardware
1
