Display Description

1. Relative Humidity %
2. T1
3. T1-T2
4. Dew Point
5. Wet Bulb
6. T2-Dew Point
7. °C/°F
8. T2
9. Maximum
10. Minimum
11. Low Battery/Hold

Operation

Open the Protective Sensor Cap
Twist the protective sensor cap, located at the top of
meter, counter-clockwise a quarter of a turn to expose
sensor
Plug in the optional external temperature probe (if
needed).
Turn Power ON or OFF
Press the ON/OFF button to turn power on or off. The meter will perform a short self-test when
turned on.
Taking measurements
1. Hold the probe in the area to be tested.
2. Allow adequate time for readings to stabilize.
3. The Relative Humidity measurement appears in
the top display.
T/DP
4. Pressing the
display between T1-T2 (internal temperature-
external temperature), DP (Dew Point), and T1
(internal temperature).
/WB
5. Pressing the
display between T2-DP (external temperature-
Dew Point), WB (Wet Bulb), and T2 (external
temperature).
Note: If the external probe is not connected, T1-T2, T2-DP, and T2 measurements will not be
displayed.
Selecting temperature units of measure (C/F)
o
Press and hold the
netzerotools.com
1
2
3
4
button toggles the lower left
T1
button toggles the lower right
T2
o
C/ F button momentarily to toggle the temperature units.
netzerotools.com
6
5
CLOSE
3
11
10
9
8
7
OPEN
the
the
