Quick Installation Guide
00825-0100-4593, Rev BA
July 2009
Rosemount 1151 Pressure Transmitter
with 4-20 mA HART Protocol
Step 1: Mount the Transmitter
Step 2: Consider Housing Rotation
Step 3: Connect the Wiring and Power Up
Step 4: Set Switches
Step 5: Configuration
Step 6: Trim the Transmitter
Product Certifications
www.rosemount.com
¢00825-0100-4360N¤
P r o d u c t D i s c o n t i n u e d
Start
End
Rosemount 1151
Advertisement
Table of Contents
Related Manuals for Emerson Rosemount 1151
Summary of Contents for Emerson Rosemount 1151
- Page 1 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 Rosemount 1151 Pressure Transmitter with 4-20 mA HART Protocol P r o d u c t D i s c o n t i n u e d Start Step 1: Mount the Transmitter...
-
Page 2: Important Notice
IMPORTANT NOTICE This installation guide provides basic guidelines for Rosemount 1151 transmitters. It does not provide instructions for configuration, diagnostics, maintenance, service, troubleshooting, Explosion-Proof, Flame-Proof, or intrinsically safe (I.S.) installations. Refer to the Rosemount 1151 reference manual (document number 00809-0100-4360) for more instruction. - Page 3 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 1: M OUNT THE RANSMITTER A. Applications Liquid Flow Applications 1. Place taps to the side of the line. 2. Mount beside or below the taps. Flow Gas Flow Applications 1.
-
Page 4: Optional Mounting Brackets
Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 CONTINUED B. Optional Mounting Brackets When installing the transmitter to one of the optional mounting brackets, torque the bracket bolts to 125 in.-lbs. (0,9 N-m). Pipe Mount Panel Mount Flat Mount... -
Page 5: O-Rings With Flange Adapters
Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 CONTINUED C. O-rings with Flange Adapters WARNING Failure to install proper flange adapter O-rings may cause process leaks, which can result in death or serious injury. The two flange adapters are distinguished by unique O-ring grooves. Only use the O-ring that is designed for its specific flange adapter, as shown below. - Page 6 (Loctite 222 – Small Screw Threadlocker) on the threads to ensure a watertight seal on the housing. NOTE If the desired position cannot be attained within the 90° limit, the transmitter will need to be disassembled. See the Rosemount 1151 reference manual (document number 00809-0100-4360) for further instruction. Housing Lock Nut...
- Page 7 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 3: C ONNECT THE IRING AND OWER Use the following steps to wire the transmitter: 1. Remove the housing cover on the side marked TERMINALS on the nameplate. 2. Connect the positive lead to the “+” terminal and the negative lead to the “–” terminal.
-
Page 8: Power Supply
Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 CONTINUED Power Supply The dc power supply should provide power with less than two percent ripple. The total resistance load is the sum of the resistance of the signal leads and the load resistance of the controller, indicator, and related pieces. -
Page 9: Step 4: Configure The Transmitter
Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 4: C ONFIGURE THE RANSMITTER Failure Mode Alarm Switch 1. Remove the housing cover. 2. Locate the failure mode switch (see Figure 3). 3. Move the switch to the desired alarm setting. To set the failure mode to high alarm, position the switch toward “HI.”... -
Page 10: Step 5: Calibrate The Transmitter
Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 5: C ALIBRATE THE RANSMITTER Verify Transmitter Configuration NOTE: A check (✓) indicates the basic configuration parameters. At minimum, these parameters should be verified as part of the configuration and startup procedure. - Page 11 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 CONTINUED Configure LCD Display Figure 4. Sample 1151 LCD Display Digital Bar Graph Retaining Ring Left Right Configuration Configuration Button Button NOTE The LCD display time-out is approximately 16 seconds. If keys are not pressed within this period, the indicator reverts to reading the signal.
- Page 12 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 CONTINUED Set the Display Equivalent to a 4 mA Signal 1. Unscrew the retaining ring shown in Figure 4 and remove the LCD display cover. 2. Press the left button for two seconds.
-
Page 13: Step 6: Trim The Transmitter
Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 6: T RIM THE RANSMITTER NOTE Transmitters are shipped fully calibrated per request or by the factory default of full scale (span = upper range limit). Full Trim A full trim is a two-point sensor calibration where two end-point pressures are applied, and the transmitter process variable output is adjusted to agree with the pressure input. - Page 14 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 CONTINUED Using the Transmitter Zero Adjustment Buttons Perform the following steps to perform a rerange using the zero adjustment buttons (see Figure 3). 1. Apply a pressure equivalent to the lower calibrated value on the high side of the transmitter.
-
Page 15: Product Certifications
The EC declaration of conformity can be found on page 19. The most recent revision can be found on www.emersonprocess.com/rosemount. ATEX Directive (94/9/EC) Emerson Process Management complies with the ATEX Directive. European Pressure Equipment Directive (PED) (97/23/EC) 1151GP9, 0; 1151HP4, 5, 6, 7, 8 Pressure Transmitters —... - Page 16 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 Canadian Certifications Canadian Standards Association (CSA) Approvals E6 Explosion Proof for Class I, Division 1, Groups C and D; Class II, Division 1, Groups E, F, and G; Class III, Division 1 Hazardous Locations. Suitable for Class I, Division 2, Groups A, B, C, and D;...
- Page 17 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 N1 ATEX Type N and Dust Certification Certificate Number: BAS99ATEX3293X ATEX Marking: II 3 GD Ex nL IIC T5 (-40 °C T 40 °C) EX nL IIC T4 (-40 °C T ...
- Page 18 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009 N7 Type N Certificate Number: Aus Ex 122X Ex n IIC T5 (T = 80 °C) / T6 IP66 Special Conditions for safe use (x): 1. It is a condition of safe use that a nominal voltage of 30 V for Ex n application shall not be exceeded.
- Page 19 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009...
- Page 20 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009...
- Page 21 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009...
- Page 22 Quick Installation Guide 00825-0100-4593, Rev BA Rosemount 1151 July 2009...
