Axxess AX-MLINK-HD Installation Manual

Car audio Wi-Fi A/V mirror interface through HDMI
With this Wi-Fi interface you will be able to mirror your IOS or Android device on your aftermarket in-dash
mobile video screen.
Note: This will not allow the mobile device to be operated from the aftermarket screen. All operations
(button presses) will need to be executed from the mobile device.
Mirroring capabilities are determined by the smart devices' (phone, tablet, etc.) software and the network
provider's permissions given to the device. Software updates can change the devices ability to mirror
certain types of video/audio.
• Wi-Fi mirror interface
• Cable to Car Audio (power connection)
1. Power LED: Blue light on when power on.
2. Antenna connector: For connecting the Wi-Fi
antenna.
3. Reset:
(a) Press 1 second for reset.
(b) Press 5 seconds for factory
default settings.
®
Axxess Integrate
Installation instructions for part AX-MLINK-HD
AX-MLINK-HD
INTERFACE COMPONENTS
• Wi-Fi antenna
INTERFACE DESCRIPTION
4. Upgrade: Press 5 seconds for upgrading
software.
5. USB: Charge (5-volts 1-amp)/software upgrade.
6. Power CVBS connector: Power cable
connections to car audio ACC/GND.
7. HDMI port: Output to radio (HDMI cable
™
sold separately).
axxessinterfaces.com
®
™
• Connect the Black wire to the chassis ground.
• Connect the Red wire to 12v accessory power.
• Connect an HDMI™ cable (not supplied) from the
• Connect the Wi-Fi antenna to the interface.
CAUTION!
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
•
metraonline.com
WIRING THE AX-MLINK-HD
Note: It is suggested to add a 3A fuse in-line with
the accessory wire.
HDMI™ port in the AX-MLINK-HD, to the HDMI™-IN.
(continued on next page)
