About the 3 input module slots
The DAC has three input module slots. They are labeled A through C. Input modules can be placed in
any position. Each module is completely self contained. It is recognized by the DAC and identified on
the display. When the module is not in use it is disabled.

Digital Input Modules

XLR S/PDIF A single XLR digital input with a word sync output.
Optical/Coaxial S/PDIF A Toslink and Coaxial digital input with a word sync output.
MQA USB A single USB interface for playback via a computer based device. This
Renderer A renderer interface for use on a home network or server. (See

Output Modules

Balanced output Offers one set of balanced analog outputs. Provides volume control.
Single-Ended output Offers one set of single-ended analog outputs. Provides volume

Clock Modules

Premier Clock This clock comes standard in every Premier DAC
Femto 93 This is an upgradeable clock option that offers audio jitter as low as
(Premier DAC shown above in standard configuration with Premier Powerbase upgrade)
S MSB proprietary interface for use with MSB transports. This module
2
ProI
provides two inputs.
module provides support for MQA decoding. (See USB manual for
operation and setup details)
Renderer manual for operation and setup details)
Pro ISL MSB proprietary interface for use with MSB transports. This module
provides one input.
control
93 femtoseconds
