press will turn the lights off. Use the camera image along with the monitor
on-screen display to gauge the desired intensity level.
A/V Port
On the back of the monitor there is a rectangular rubber cap that protects
the charging port and the RCA video out jack. Please make sure this cap is
closed when not using the RCA jack to avoid potential water damage.
Utilizing the RCA Jack
There are many anglers with large ice fishing houses that are equipped
with a TV inside. Video is easily sent from the RECON5+ to your TV by
simply running an RCA cable from the RECON5+ to the TV and selecting
the correct input source on the external monitor.
Built-In DVR
The RECON5+ has a built-in DVR that allows you
to capture all the action below. All recorded media is
saved to a micro-SD card (not included). The
RECON5+ will support up to a 32GB Class 10
micro-SD card (be sure the card has a class 10
symbol like the example on the right).

DVR OPERATION

Accessing the micro-SD card
To access the micro-SD card slot, open the rectangular rubber cap on the
back of the unit. The card can be inserted by placing it into the slot and
pressing downwards until it clicks into place. To remove the micro-SD card,
press down on the card. After it clicks and rises from the slot, grab the card
to remove.
Formatting the micro-SD Card
The micro-SD card must be formatted prior to recording media. To format,
insert the micro-SD card into the card slot on the back of the unit. Press the
MENU/ENTER button and select SETTING. In the SETTING sub-menu
select SYSTEM SETTING and use the Up/Down arrows to select FORMAT.
By pressing the Up or Down arrows, set FORMAT to YES and press
MENU/ ENTER. Using the arrows scroll to the SAVE button and press
MENU/ENTER to save the changes.
The micro-SD card MUST be formatted in the RECON5+. Files can be
copied from the RECON5+ to the PC, but you should not copy files onto
the SD card from the PC and should not delete files on the SD Card from
the PC. Files may be deleted on the RECON5+ if desired or the SD can be
reformatted on the RECON5+ after copying files to the PC to "delete all
files".

Recording Video

To record a video press and hold the record button for approximately 3
seconds until a "REC" with a red circle icon appears in the upper left hand
corner of the screen. This icon will blink while the unit is recording. To stop
the recording, press the REC button again. Once the icon disappears, the
unit is no longer recording.
