RECON5+
The RECON5+ viewing system comes complete with everything needed to
enjoy the world of underwater viewing. It features a 5" Screen with a
multi-purpose sun shield/screen protector. The camera features both visible
LED lights as well as a stealthy infrared option for viewing in low light
situations. A built in DVR allows for video recording as well as capturing
photos of the action. Incorporated into the camera system are on screen
displays of depth, temperature, and camera direction. A removable weight
and camera-positioning clip come standard with the system. The system is
powered by an internal rechargeable Lithium Ion battery that provides up to
6 hours of continuous run-time. Included with your system are a charger
and cable, protective soft-pack, and camera storage sack. The RECON5+
features a ¼"- 20 insert as well as additional inserts that allow for limitless
mounting options (Mounts not included). These are located behind the
cable storage reel (see "Removing the camera cable storage reel" section).
The charging port and video out jack are located on the rear of the monitor,
and can be accessed by lifting the protective rubber cap.

SPECIFICATIONS

Display:
• 5" Widescreen LCD Monitor
• 6:9 Aspect Ratio, Sunlight
Readable
• 800 x 480 Pixel Hi-Res Color
Power:
• Rechargeable Internal Lithium
Battery
• (Up-to 6 Hours of Continuous
Run-Time)
• USB Charger & Cable
Display Adjustments:
• Brightness
• Sharpness
• Contrast
• Color
• Color Kill
• On Screen Display
• Units

GETTING STARTED

Charging:
The RECON5+ has an on-screen display of the battery status found in the
upper left side of the video image. Once the video image starts the battery
status indicator will detail a series of green bars. Three full green bars will
indicate a full charge.
www.MarCumtech.com
Camera:
• 1/3" CMOS Sensor Offers
Optimal Low-Light Performance
• 110° Field of View
• Darkwater Adjustable LED or IR
Lighting
• Color Kill, Color or B/W Image
Options
• 50 ft. Camera Cable
• Removable weight

Additional Features:

• Built-In DVR
• Built-In Sunshield & Screen
Protector
• RCA Video Out
• Soft Pack & Camera Sack
• Removable Camera/Cable
Storage
• 1-Year Warranty
• Supports up to a 32 GB
Micro-SD card
- 2 -
