- Page 1 COMPACT UNDERWATER VIEWING SYSTEM USER MANUAL...
-
Page 2: Specifications
Versa Electronics www.MarCumtech.com RECON5+ The RECON5+ viewing system comes complete with everything needed to enjoy the world of underwater viewing. It features a 5” Screen with a multi-purpose sun shield/screen protector. The camera features both visible LED lights as well as a stealthy infrared option for viewing in low light situations. -
Page 3: Record Button
Versa Electronics www.MarCumtech.com To charge the RECON5+, power the system off (5 second hold of power button) and locate the rubber cap on the back of the monitor just to the right of the cable storage reel. Lift the rubber cap to expose the USB Charging port. -
Page 4: Monitor Setting
Versa Electronics www.MarCumtech.com RECON5+ MENU OPTIONS For ease of use, the menu system on the RECON5+ times out after a 5 second period of inactivity and defaults back to the camera image without any additional keystrokes required. Enter the Menu system with a single press of the top Menu/Enter button. Use the Up or Down arrow buttons to navigate to the desired selection, followed by the Enter button to enter and change that setting. -
Page 5: Dvr Operation
Versa Electronics www.MarCumtech.com press will turn the lights off. Use the camera image along with the monitor on-screen display to gauge the desired intensity level. A/V Port On the back of the monitor there is a rectangular rubber cap that protects the charging port and the RCA video out jack. -
Page 6: Taking A Photo
Versa Electronics www.MarCumtech.com Taking a Photo The RECON5+ has the ability to take a screen shot photo of what is currently visible on the screen. To take a picture, complete a quick press of the REC button. A red circle icon will momentarily appear in the upper left hand corner of the screen and then disappear, indicating that a picture was taken. -
Page 7: On-Screen Displays
Versa Electronics www.MarCumtech.com water the depth of field can be reduced to only a few inches due to particles suspended in the water. Dirty or murky water and/or low light penetration can detract from the quality of the color picture. Optimum color quality will result from clear water and adequate light penetration. -
Page 8: Operating Positions
Versa Electronics www.MarCumtech.com Outside of water it should read 0. If it does not read 0, a simple powering off of the system and then powering it back on will reset the reading to 0. The units can be changed from Standard to Metric, or vice versa in the MONITOR SETTING menu. -
Page 9: System Maintenance
MarCum Technologies Website: www.marcumtech.com/support. MarCum Technologies will repair or replace any components that fail in normal use. Failures due to abuse, misuse, unauthorized alteration, modification, or repair are not covered. The warranty is valid only for the original owner who purchases the unit from an authorized dealer. -
Page 10: How To Obtain Service
For this reason, strongly consider using the online forms at www.marcumtech.com/support . OUR ADDRESS: MARCUM TECHNOLOGIES ATTN: SERVICE DEPT. 3943 QUEBEC AVE NORTH MINNEAPOLIS, MN 55427 service@versae.com... - Page 11 The customer is responsible for shipping costs associated with returning the unit to MarCum Technologies. MarCum will pay for shipping the repaired unit back to the customer while it is still under warranty. All out of warranty services will be charged a fee for service and shipping which must be paid in advance.
- Page 12 Versa Electronics www.MarCumtech.com www.MarCumtech.com MarCum Technologies 3943 Quebec Ave N Minneapolis, MN 55427 MarCum User Manuals are available for downloads from www.MarCumtech.com 2018-0514 - 12 -...
