Summary of Contents for Marcum Technologies Underwater Viewing System VS820

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Features .

  • Page 4: Introduction

    Thank you for purchasing the VS820 underwater viewing system from MarCum Technologies Inc., the most technologically advanced underwater viewing system available. Welcome to the world of underwater viewing. MarCum Technologies has incorporated the latest technology in producing the most compact, technologically advanced and versatile underwater viewing system available.

  • Page 5: Features

    FEATURES • 600v x 800h super-high resolution LCD monitor equipped with a sophisticated, thermostatically controlled heater to enhance your viewing experience in winter conditions. • Sony CCD Super HAD black and white camera. • Manta camera design utilizing Darkwater technology lighting system.
  • Page 6 temperatures. It can take up to several minutes before the screen temperature reaches the appropriate operating range. In order to create an ultra clear - high resolution picture, there needs to be a matching high quality camera. The VS820 uses the best camera module available;...

  • Page 7: Getting Started

    Remove the VS820 from the packaging and place on a level surface with the MarCum Technologies logo facing towards you and right side up. Open the top cover of the soft pack by lifting up on the Velcro closers on each side and front of the soft pack.

  • Page 8: Adjusting The Monitor Settings

    gently tighten the knobs until they are snug. The battery, camera and cable are now accessible behind the monitor. It’s easiest to remove the Velcro straps and unzip the soft pack case. The battery cable connectors can now be connected to the battery by attaching the corresponding wire colors to the correct terminal.

  • Page 9: Lighting

    direction you are depressing. To accept the changes, release the UP / DOWN arrow and settings will be saved. Once the settings are adjusted properly, the on-screen menu will shut off automatically. Contrast - Contrast is the difference in brightness between lightest and darkest tones in a picture.

  • Page 10: Ice Fishing Application

    be illuminated. This indicates that the high intensity infrared LED lights are ON. By pressing the LIGHT key a second time, the same LED light next to the LIGHT key will be illuminated green to indicate the super high intensity blue LED lights are ON. To turn the lighting system OFF, press the light button a third time.

  • Page 11: Open Water Application

    OPEN WATER APPLICATION To locate fish, look for treasure or find that perfect spot, simply turn the camera power ON and drop the Manta camera into the water. If you’re drifting with the wind or using a trolling motor with the VS820, attach the supplied trolling fin to the rear of the Manta Camera for added stability.

  • Page 12: Product Performance Specifications

    warranty batteries beyond 90 days from date of purchase. Tip: To preserve battery run time, try to keep the VS820 in a relatively warm environment to minimize the use of the built in LCD heater system. By starting out with a warm monitor, there is less power consumed and less warm up time required.

  • Page 13: Warranty

    Some problems may be resolvable by a technician over the phone. If the unit is sent back to MarCum Technologies for repair, mark the RMA number on the outside of the package and enclose a letter indicating the problem.

  • Page 14: Service Information

    MarCum Technologies is dedicated to providing you with the best customer service possible. We have designed a web site dedicated to providing you, our customer, with answers to your questions, access to product accessories, repair information, online owner’s manuals, etc. These services can be obtained by going on line at www.marcumcustomerservice.com.
