EcoSense
®
EcoSense
Portable Conductivity, Salinity and
Temperature Instruments
U S E R M A NUA L
E n g l is h, Français, E spa ño l, Port ugu ês
For Sales & Service Contact
2650 E. 40th Ave. • Denver, CO 80205
Phone 303-320-4764 • Fax 303-322-7242
1-800-833-7958
www.geotechenv.com
EC300A
EC300M
User Manual
DOCUMENT #606042REF
Advertisement
Table of Contents
Related Manuals for Geotech EcoSense EC300M
Summary of Contents for Geotech EcoSense EC300M
- Page 1 User Manual DOCUMENT #606042REF ® EcoSense EC300A ® EcoSense EC300M Portable Conductivity, Salinity and Temperature Instruments U S E R M A NUA L E n g l is h, Français, E spa ño l, Port ugu ês For Sales & Service Contact 2650 E.
- Page 2 WARRANTY The EcoSense® EC300A/EC300M Instrument is warranted for one year from date of purchase by the end user against defects in materials and workmanship. EC300A/EC300M probes and cables are warranted for one year from date of purchase by the end user against defects in material and workmanship.
-
Page 3: Table Of Contents
C O N T E N T S Safety Information ................1 The Instrument Case ..............1 Package Contents ................1 Unpacking ....................2 Installation ...................2 Battery Installation ..............2 Intended Use and General Overview ..........2 Display Description ................4 Operational Keys Description ............5 Operational Procedures..............6 Measurement Modes .............6 Calibration ................7 TDS ...................7... - Page 4 Accessories / Part Numbers .............14 Technical Services ................14 Specifications ..................14 606042REF-B-EC300A-EC300M-Manual-English.indd 4 12/11/2017 10:07:39 AM...
-
Page 5: Safety Information
S A F E T Y I N F O R M A T I O N Please follow the guidelines below, and read this manual in its entirety to ensure safe operation of the unit. Avoiding Damage to the Instrument - Precautions The Instrument Case Though the instrument is housed in a water-proof IP67 case, DO NOT use it underwater. -
Page 6: Unpacking
Item # Contents 601037 EC300M meter, manual, USB cable, 9V battery, transport case, probe with 10 meter cable U N P A C K I N G Carefully unpack the unit and accessories, and inspect for shipping damages. Compare received parts with materials listed in the Package Contents section. - Page 7 This instrument is waterproof (IP67) when the connector cap is installed. The mechanical touch keys are highly reliable with tactile and audio feedback. This instrument uses one 9V battery. Recalibration is not required when power is restored. The front of the instrument has a large LCD that displays temperature and either temperature compensated or non-temperature compensated conductivity, salinity or TDS simultaneously along with user prompts and mode indicators.
-
Page 8: Display Description
D I S P L A Y D E S C R I P T I O N Figure 2 Number Description Displays when measuring conductivity. Low battery indicator Recal Timer indicator (EC300M only) Main display for compensated and uncompensated conductivity, salinity and TDS values. -
Page 9: Operational Keys Description
Number Description Save, Full, Recall, Each, All, Delete: Instrument’s data storage indicators. Date/Time display (EC300M only) O P E R A T I O N A L K E Y S D E S C R I P T I O N Mode EcoSense ®... -
Page 10: Operational Procedures
INPUT Recal Timer key (EC300M Date Recal only). Press to enter the Recal Timer Time Timer input display. Mode key. Selects display mode. In Normal operation, press Mode to switch the display between Mode uncompensated conductivity, temperature compensated conductivity, salinity, total dissolved EcoSense DO200M solids (TDS), Recall and Delete. -
Page 11: Calibration
3. Uncompensated Conductivity – Direct measurement of conductivity, not compensated to a specific temperature. Expressed as uS/cm or mS/cm. 4. Salinity – Measurement of salinity; expressed in parts per thousand (ppt). 5. TDS – Measurement of total dissolved solids (TDS); expressed in milligrams per liter (mg/L) Carefully observe the units displayed at the far side of the LCD to determine the desired mode. -
Page 12: Temperature Coefficient
Note: Be certain to press Enter to reset the cell constant to 5.00. If MODE is pressed, the unit retains the previous cell constant and calibrates from a value that is already offset. Temperature Coefficient The unit uses the temperature coefficient to calculate temperature compensated conductivity. -
Page 13: Saving, Viewing And Deleting Data
Saving, Viewing and Deleting Data The EC300A can save 50 data records, while the EC300M can save 250 data records. When in measurement mode, press Enter to save a record. The instrument will confirm saving the data by displaying “Save” and the data record number for one second. “Full” is displayed when trying to save data and memory is full. -
Page 14: Recal Timer - Ec300M Only
4. Copy and paste the .csv file from the instrument to a location on the computer. This file can be opened in Excel®. Note: The original .csv file should be left on the EC300M instrument. Do not try to modify this file. Note: If the .csv file is opened with Excel®... -
Page 15: Troubleshooting
T R O U B L E S H O O T I N G Error Messages on Display Main Display Problem Possible Solution OvEr • Conductivity is • Completely submerge >200.0 mS the probe. • Salinity is > 70.00 ppt •... - Page 16 3. Choose to Import the data file you have copied to your PC. Don't select the original data file that is still on the instrument. 4. Under Step 1 of the Text Import Wizard, choose Delimited. 5. Under Step 2 of the Text Import Wizard, choose Semicolon. 6.
-
Page 17: Maintenance
7. Select Finish, then choose where you want the data to be placed on your opened spreadsheet. M A I N T E N A N C E The most important requirement for accurate and reproducible conductivity measurements is a clean cell. A dirty cell changes the conductivity of a solution through contamination. - Page 18 A C C E S S O R I E S / P A R T N U M B E R S Part Number Description 606044 1 meter probe and cable assembly 605395 4 meter probe and cable assembly 605396 10 meter probe and cable assembly 606043...
- Page 19 Reference Temperature 15.0 to 25.0°C (59 to 77°F) (Input during calibration) Temperature Coefficient 0.0% to 4.0% (Input during calibration) TDS Constant 0.3 to 1.00 (Input during calibration) Cell Constant Range 4.50 to 5.50 ATC Probe Thermistor, 10KΩ, at 25 °C Calibration Backup Audio Feedback Yes, on all keys...
- Page 20 Conforms to the following: Directives: EMC 2014/30/EU RoHS 2011/65/EU WEEE 2012/19/EU Harmonized Standards: EN61326-1:2013 (IEC 61326-1:2012) IEC 61000-3-2:2005 IEC 61000-3-3:2008 IEC 61000-4-2:2008 IEC 61000-4-3:2006 IEC 61000-4-4:2004 IEC 61000-4-6:2008 IEC 61000-4-8:2009 Item #606042REF Revision B; December 2017 For the latest version of this manual, visit ysi.com 606042REF-B-EC300A-EC300M-Manual-English.indd 16 12/11/2017 10:07:45 AM...
