26" HD Ready LED TV with DVD Player
Quick Start Guide
L26HED12
Thank you
for purchasing your new Logik TV.
Your new TV incorporates the latest technology to enhance your
viewing experience. We would suggest that you allow about 20
mins for initial setup.
Please follow this guide for a successful first time installation.
GB
1
1
Unpacking
Remove all packaging from the TV. Retain the packaging.
If you dispose of it please do so according to any local
regulations.
TV
Screw A x 2
TV Stand Support
Screw B x 3
TV Base
Instruction Manual
Remote Control /
Quick Start Guide
AAA Batteries x 2
3
3
Installing the Base Stand
1. Lay the TV down on a flat surface with the back side facing up. Please make sure a soft cushioned material (such as a pillow or thick piece of foam) is
placed beneath the screen.
2. To install the TV stand, first attach the stand support to the TV by using screw A. Align the screw holes then use 2 screw A to fix the stand support to the TV.
3. To install the base stand, align the screw holes, then secure with a screw driver (not included) using the 3 screw B provided.
Screw A x 2
(P.N.: 209100430B1)
2
2
Operating Your Remote Control
1. Press and lift the back cover to open the
battery compartment of the remote
control.
2. Insert two AAA size batteries. Close the
battery compartment cover.
Make sure the (+) and ( – ) ends
of the batteries match the (+)
and ( – ) ends indicated in the
battery compartment.
screw
TV Front
screw
Base Stand
Front
Screw B x 3
(P.N.: 209060410B1)
4
4
Connecting the Aerial
OR
RF Coxial Cable
(not included)
COMMON INTERFACE (CI)
USB
HDMI2
HDMI1
PC IN
HEADPHONE
PC AUDIO
Connect one end of the RF coaxial cable to the aerial socket on the
wall and the other end of the cable to the RF (75Ω) socket at the rear
right side of your TV.
Do not connect the TV to the mains supply until you
have completed all the connections.
6
6
Turning the TV On for the First Time
The first time you turn the TV on, it will go straight into First Time Installation menu.
1. Press the OK button to
First Time Installation
start First Time
Installation menu.
Please ensure aerial is plugged in!
Then press OK button.
3. Press the
Country
buttons to select UK as
the country where you
UK
Belgium
Czech
France
Hungary
will operate the TV.
Australia
Bulgaria
Denmark
Germany
Italy
Press the OK button to
confirm.
Austria
Croatia
Finland
Greece
Luxembourg
OK
7
7
Target Region Descriptor
This will be shown as GBR for the UK.
During tuning your TV may have received signals
This will show the regional country
from more than one transmitter. If this has occurred
(e.g. England, Wales, Scotland, NI).
the Target Region Descriptor screen will be
displayed. This will enable you to select the correct
This will allow you to set the region for
regional transmission for the local news service that
your local news service.
you require.
Press the
buttons to adjust each option's setting
You may receive signals from more than
and then press the OK button to confirm.
one transmitter within the Secondary
Region, (e.g Beds and Cambs may have
Luton or Sandy Heath).
Well done,
your new TV is now ready to use. You will find that there are many exciting features available. To get to know all these
features, please take some time to read the instruction manual provided with your TV.
If after reading the instruction manual you have additional questions related to the use of your TV please call our UK Call Centre on 0844 561 1234.
Our UK Customer Contact Centre is open Monday-Saturday 8am-8pm or Sunday 8am-6pm.
5
5
Connecting to the Mains Socket
RF
1. Connect the mains cable to the mains socket after you have
completed all the connections.
2. At this stage, the TV switches to standby mode. The red LED
indicator will illuminate on the front panel of the TV.
3. In standby mode, press the
button on the right side panel of the
TV or on the remote control to turn the TV on. The red LED
indicator will turn blue.
2. Press the
OSD Language
to select English as your
desired language to be
Cesky
English
Fran ais
Magyar
Polski
displayed on the menu.
Espanol
~
Dansk
Hrvatski
Nederlands
Portugues
Press the OK button to
Deutsch
E
k
Italiano
Norsk
Pycck
confirm.
OK
4. Channel tuning will
Channel Tuning
commence. This operation
may take up to 6 minutes.
The display will show the
TV
: 3 Channel(s)
progress of the tuning and
DTV
: 0 Channel(s)
the number of channels
Radio : 0 Channel(s)
found.
Data
: 0 Channel(s)
36%...
668.75MHz
(TV)
Please press MENU to skip.
Target Region Setting
Country Code
Primary Region
Secondary Region
Tertiary Region
To mains
socket
buttons
GBR
England
London
(P.N.: 4033C266120)
