  • Page 1 Leica AT930/AT960 Quick Guide Version 1.2 English...
  • Page 2 Automatic target search, recognition and following. • Remote control of product. • Data communication with external appliances. Laser products The AT930/AT960 instrument contains the following laser products: Laser product Laser class Classification ADM (Absolute Distance Meter) Class 1 IEC 60825-1 (2014-05)
  • Page 3 2) Avoid pointing the beam at other people or at animals.  The AT930/AT960 is classified as a laser class 2 system although the individual laser sources are classified as laser class 1. The possibility of simultaneous emission of the individual laser sources results in an overall classification as laser class 2.
  • Page 4 AT930/AT960, Important Information about your Instrument  The following advice is only valid for the AC power supply. The product is not designed for use under wet and severe conditions. If unit becomes WARNING wet it may cause you to receive an electric shock.
  • Page 5 • FCC Part 15 (applicable in US) Conformity to • Hereby, Leica Geosystems AG, declares that the product is in compli- national regulations ance with the essential requirements and other relevant provisions of the applicable European Directives. The declaration of conformity may be consulted at http://www.leica-geosystems.com/ce.
  • Page 6 Conformity to • FCC Part 15 (applicable in US) • Hereby, Leica Geosystems AG, declares that the product AT Controller with WLAN national module is in compliance with the essential requirements and other relevant regulations provisions of Directive 1999/5/EC and other applicable European Directives. The declaration of conformity can be consulted at http://www.leica-...
  • Page 7 Leica Geosystems has developed Guidelines on “How to carry Leica prod- ucts” and “How to ship Leica products” with Lithium batteries. Before any transportation of a Leica product, we ask you to consult these guidelines on our web page (http://www.leica-geosystems.com/dgr) to ensure that you are in accordance with the IATA Dangerous Goods Regulations and that the Leica products can be transported correctly.

  • Page 8: Container Contents

    AT930/AT960, Container Contents Container Contents Container for Instrument and a) Optical cleaning kit Delivered b) Protective cover for Accessories AT930/AT960 instrument c) Quick Guide and Product Information USB Stick d) Quick Release e) Hinged Hook Wrench AC Power supply g) Universal Stand Fixture h) Wooden box containing 1.5”...

  • Page 9: Technical Data

    • Periodically carry out test measurements and perform the field adjustments indi- cated in the User Manual, particularly after the product has been dropped, stored for long periods or transported. AT930/AT960, Technical Data...
  • Page 10 AT930/AT960, Operation Operation System Components AT930/AT960 AT Controller 008050_002 Component Description AT930/AT960 Absolute Tracker of highest accuracy for measuring, calculating instrument and capturing data. AT930: 3D Measurements AT960: 3D & 6DoF Measurements...
  • Page 11 Controller running the system software which provides the inter- face to the Absolute Tracker. The optional Real-Time Feature Pack for Absolute Tracker AT930/AT960 is designed to provide cyclic measurement data in real-time over an industrial field bus protocol, for example EtherCAT, with minimum jitter and small latency.
  • Page 12 AT930/AT960, Setup Setup Setup Step-by-step 008051_002...
  • Page 13 “Air”. This ensures that you achieve the highest possible measurement accuracy. Connect one end of the sensor cable to the AT Controller. Connect the other end of the sensor cable to the AT930/AT960 instrument. Connect a LAN cable (if applicable). AT930/AT960, Setup...
  • Page 14 AT930/AT960, Setup Step Description Connect the AC power supply to the AT Controller and to a grounded mains socket outlet. To turn on the Absolute Tracker, press the power switch on the frontpanel of the AT Controller. The system automatically detects when the start-up cycle has finished. The system will initialise automatically once the start-up cycle has finished.
  • Page 15 Power status LED b) Clip for Universal Stand Fixture (back side of the AT Controller) c) Touch-sensitive status display with different information pages d) WLAN status LED e) Main power switch for AT Controller and AT930/AT960 Connectors AT930/AT960, Startup...
  • Page 16 AT930/AT960, AT Controller Display AT Controller Display Description The AT Controller has a touch-sensitive VGA colour display. The display shows essen- tial information about the Absolute Tracker system. The following pages are avail- able: • Startup splash screen • Shutdown splash screen •...
  • Page 17 Levelling sensor status d) Meteo data source e) System information Active measurement profile g) Absolute Tracker status h) Controller navigation controls  The icons change their appearance depending on the current status of the feature that they represent. AT930/AT960, AT Controller Display...
  • Page 18 AT930/AT960, AT Controller Display Touch screen sensitive areas: a) Tap on an icon to display the corre- sponding detail page. b) Tap on the navigation control areas to toggle between the detail pages and the main page. Status Icons Description Absolute Tracker Status System is ready.
  • Page 19 Status Icons Description Sensor is not connected. Tracker is not initialised. Firmware problem. (Example: Not all device servers are available.) Laser is off. Laser is not ready. Laser is warming up. AT930/AT960, AT Controller Display...
  • Page 20 AT930/AT960, AT Controller Display Status Icons Description Laser is unable to stabilise. Measurement Profiles Fast Standard Precise Continuous...
  • Page 21 AT930/AT960 Instrument Status LEDs Status LEDs Description The AT930/AT960 has Light Emitting Diode indicators at the front side of the tele- scope. They indicate the following states. Diagram of the Status LEDs a) Blue LED b) Green LED c) Red LED...
  • Page 22 AT930/AT960, AT930/AT960 Instrument Status LEDs Description of the Status LEDs Pattern Status Information Red, Green and Blue The AT Controller or the AT930/AT960 instrument are off. Red, Green and Blue static The system is booting up. Red and Blue LED...
  • Page 23 Pattern Status Information Blue LED flashing slowly PowerLock is temporarily suspended while laser is pointing. AT930/AT960, AT930/AT960 Instrument Status LEDs...

  • Page 24: Ec Declaration Of Conformity

    EC Declaration of Conformity This corresponds to EN ISO/IEC 17050-1. EC Declaration of Conformity We, Leica Geosystems AG, CH-9435 Heerbrugg (Switzerland), declare under our sole responsibility that the product(s) AT930, AT960-MR, AT960-LR, AT960-XR, following the provision of Directive(s) • 2011/65/EU Restriction of hazardous substances (RoHS) •...
  • Page 25  For a signed version and translations into the official EU languages please refer to: http://www.leica-geosystems.com/ce AT930/AT960, EC Declaration of Conformity...
  • Page 26 Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Phone +41 71 727 31 31 www.leica-geosystems.com...
