Owner's Manual
Exeter, PA
St. Catharines, ON
YOU MUST READ THE ENTIRE
CONTENTS OF THIS OWNER’S
MANUAL BEFORE USING
YOUR POWER CHAIR.
1-800-800-8586
www.pridemobility.com

Advertisement

Table of Contents
loading

Related Manuals for Pride Mobility Jazzy 1133

Summary of Contents for Pride Mobility Jazzy 1133

  • Page 1 Owner’s Manual YOU MUST READ THE ENTIRE CONTENTS OF THIS OWNER’S MANUAL BEFORE USING YOUR POWER CHAIR. Exeter, PA St. Catharines, ON 1-800-800-8586 www.pridemobility.com...
  • Page 2 WARNING! Failure to heed the warnings in this owner’s manual may result in personal injury. CAUTION! Failure to heed the cautions in this owner’s manual may result in damage to your power chair. Copyright © 2003 Pride Mobility Products Corp. INFMANU2090 www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...

  • Page 3: Table Of Contents

    IV. THE JAZZY 1133 ..........................14 DISASSEMBLY ..........................19 VI. COMFORT ADJUSTMENTS ......................22 VII. BATTERIES AND CHARGING....................27 VIII.OPERATION ............................31 IX. CARE AND MAINTENANCE ....................... 35 OPTIONAL ACCESSORIES ......................41 XI. WARRANTY ............................42 Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...

  • Page 4: Introduction

    I N T R O D U C T I O N INTRODUCTION Welcome to Pride Mobility Products Corporation (Pride). Congratulations on the purchase of your new Jazzy Power Chair. The Jazzy design combines the most advanced state-of-the-art components with modern, attractive styling.

  • Page 5: Jazzy 1133 Owner's Manual Rev B 03-03 Www.pridemobility.com

    Purchase Date:________________________________________________________________________ NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and we will be glad to send you a new one immediately. Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...

  • Page 6: Safety

    Check all controller connections to the electronics tray. Make sure they are secured properly. n Check the brakes. See IX. “Care and Maintenance.” n Check battery charge. See VII. “Batteries and Charging.” NOTE: If you discover a problem, contact your authorized Pride provider for assistance. www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...

  • Page 7: Weight Limitations

    If your power chair starts to move down the incline faster than you anticipated or desired, allow it to come to a complete stop by releasing the joystick, then push the joystick forward slightly to ensure a safely controlled descent. Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...

  • Page 8: Ii. Safety

    High cornering speeds are not recommended. If you feel that you may tip over in a corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your power chair from tipping. www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 9 Your power chair is equipped with a manual freewheel lever to allow for manual maneuverability by a trained attendant. For more information about how to place your power chair into and out of freewheel mode, see IV. “The Jazzy 1133.”...
  • Page 10 Motor Vehicle Transport Currently, there are no standards approved for tie-down systems in a moving vehicle of any type to transport a person while seated in a power chair. www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...

  • Page 11: Positioning Belts

    Turn the power off. See VIII. “Operation.” n Ensure your power chair is not in freewheel mode. See IV. “The Jazzy 1133.” n Turn both caster wheels toward the transfer destination to improve power chair stability during transfer.

  • Page 12: Reaching And Bending

    Removable Parts WARNING! Do not attempt to lift or move a power chair by any of its removable parts. Personal injury and/ or damage to the power chair may result. www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 13 The FDA has reports of injuries that resulted from the apparent uncontrolled motion of power chairs. However, it is unclear how many of these incidents were actually caused by radio wave interference. Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...

  • Page 14: Iii. Emi/Rfi

    What should I do if my power chair moves unexpectedly? If unintended motion or brake release occurs, turn the power chair off as soon as it is safe to do so. Call Pride at 800-424-8205 to report the incident. www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 15 THE JAZZY 1133 The Jazzy 1133 has three main assemblies: the power base, the seat assembly, and the controller assembly. See figures 3, 4, 5, and 6. Information on the standard seat assembly is in VI. “Comfort Adjustments.” Information on the controller assembly is in VIII.

  • Page 16: Iv. The Jazzy 1133

    Back Battery Box: 49 lbs. (w/ NF-22 battery) Total Power Base Weight: 181 lbs. (w/ batteries) Medium-Back Seat: 33 lbs. Batteries: 38 lbs. each Warranty: Lifetime limited warranty on frame Two-year warranty on electronics Eighteen-month warranty on drive motors www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 17 BACK BATTERY BOX FRONT SEAT TOWERS FRONT BATTERY BOX FRONT SEAT-FRAME BAR ONBOARD BATTERY CHARGER (INSIDE FRONT BATTERY BOX) Figure 4. Jazzy 1133 Power Base Assembly — Seat Removed ONBOARD CHARGER MAIN CIRCUIT AC POWER CORD AMMETER CHARGER FUSE(S) BREAKER...
  • Page 18 CONNECTOR BOX GRIP BACK BATTERY BOX Figure 6. Jazzy 1133 — Back of Power Base The Power Base Assembly The power base assembly consists of the right and left frame assemblies, the front and back battery boxes, and the seat bars. See figures 4, 5, and 6. The battery boxes provide connectivity for the controller, the onboard battery charger, and the batteries.
  • Page 19 NOTE: If a lever is difficult to move in either direction, rock your power chair back and forth slightly. The levers should then move to the desired position. MANUAL FREEWHEEL LEVER MOTOR/BRAKE ASSEMBLY Figure 7. Jazzy 1133 Manual Freewheel Lever (right side shown) Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...

  • Page 20: Disassembly

    D I S A S S E M B L Y DISASSEMBLY You can disassemble your Jazzy 1133 into six pieces (seat not shown) for easy transport. See figure 8. NOTE: Assembly is the reverse of disassembly. BATTERY BATTERY BOX HANDLE...

  • Page 21: V. Disassembly

    14. Remove the ball detent pin from the footrest bracket. See figure 11. SEAT FRAME BRACKET BALL DETENT PIN SEAT TOWER BALL DETENT PIN Figure 12. Front Seat Tower Figure 11. Footrest Bracket Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...
  • Page 22 Figure 14. Crossbar crossbar toward the left power base frame until the cross bar latch clicks. See figures 15 and 16. Figure 15. Crossbar Release Latch Figure 16. Crossbar in Folded Position www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...

  • Page 23: Comfort Adjustments

    4. Reposition the extrusions on a different set of mounting holes. See figure 18. You must move both extrusions the same number of holes either forward or backward. 5. Reinstall the extrusions onto the bottom of the seat. 6. Reinstall the seat. Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...

  • Page 24: Reclining Seat

    See figure 19. 2. Loosen the knobs. 3. Slide the armrests in or out to the desired width. 4. Tighten the knobs. ARMREST KNOB ADJUSTING SCREW Figure 19. Seatback and Armrest Adjustments www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 25 1. Remove the two screws from the side of each leg rest extension. See figure 24. 2. Slide the leg rest in or out to the desired length. 3. Tighten the bolt and reinstall the two screws. Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...
  • Page 26 See figure 24. 2. Slide the leg rest in or out to the desired length. 3. Reinstall the two screws and tighten. LEG REST ADJUSTMENT SCREWS Figure 24. Elevating Leg Rests (Swing-away is similar.) www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...

  • Page 27: Controller Position

    3. Raise or lower the anti-tip wheel. 4. Reinstall the nut and bolt on the anti-tip wheel bracket. 5. Reinstall the wheel. 6. Repeat the same procedure for the other anti-tip wheel. Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...

  • Page 28: Batteries And Charging

    If your AC power cord plugs into the onboard AC power cord receptacle as well, then roll it up and store it in a safe place. www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 29 3. Give the batteries another full charge of 8 to 14 hours and operate your power chair again. The batteries will now perform at over 90% of their potential. 4. After four or five charging cycles, the batteries will top off at 100% charge and last for an extended period. Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...
  • Page 30 Always charge the batteries fully prior to your trip. n Plan your trip in advance to avoid inclines if possible. n Limit baggage weight to essential items. n Try to maintain an even speed and avoid stop-and-go driving. www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 31 If you wish to use a freight company to ship your power chair to your final destination, repack your power chair in the original shipping container and ship the batteries in separate boxes. Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...
  • Page 32 Unless the joystick is damaged, this action should stop your power chair. Keypad The keypad is located in front of the joystick. It contains keys necessary to operate your power chair. See figure 28. www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...

  • Page 33: Viii.operation

    NOTE: We recommend that the first few times you operate your power chair, you set the speed to the slowest setting until you become familiar with your new power chair. Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...
  • Page 34 This reduces your power chair’s “power,” which could also reduce your power chair’s speed, and allows the elec- trical components and motors to cool down. When the temperature returns to a safe level, your power chair re- sumes its normal operation. www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 35 The parking brakes have a bad connection. Check the parking brake and motor connections. Make sure the controller system connections are secure. An excessive voltage has been applied to the controller system. This is usually caused by a poor battery connection. Check the battery connections. Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...

  • Page 36: Care And Maintenance

    Pride provider if there is a problem with any harnesses. Weekly Checks n Disconnect and inspect the controller from the electronics tray. Look for corrosion. Contact your authorized Pride provider if necessary. www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 37 CAUTION! Never hose off your power chair or place it in direct contact with water. Your power chair has a painted, ABS plastic body shroud that allows it to be easily wiped clean with a damp cloth. Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...

  • Page 38: Corrective Maintenance

    The batteries on your power chair are located inside battery boxes, in the power base. See figure 4. For information on how to reconnect the batteries, refer to the battery harness decal which is located inside each battery box. See figure 31. www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 39 UNDER HANDLE FRONT FRONT BACK BACK *NOTE: CHECK BATTERY TERMINALS FOR POS (+) AND NEG (-) TERMINAL LAYOUT. Figure 29. Jazzy 1133 Rear Battery Box Figure 30. Jazzy 1133 Front Battery Box Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...
  • Page 40 NOTE: Your wheel may use one or more small, rectangular keys to connect it to the axle. Make sure you keep them for reassembly. DRIVE WHEEL RIM HALVES Figure 32. Jazzy 1133 Drive Wheel — Exploded View www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 41 Uneven wear on any of the tires n Jerky motion n Pulling to one side n Bent or broken wheel assemblies n Does not power up n Powers up, but does not move Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...

  • Page 42: Optional Accessories

    This option enables you to move the joystick from the front of the armrest to the side of the armrest without disconnecting it. Dust Cover These sturdy canvas covers help protect your Jazzy when not in use. www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...

  • Page 43: Warranty

    This warranty gives you specific rights, and you may also have other rights which vary from state to state. Please fill out and return the warranty card to Pride. This assists Pride in providing the best possible technical and customer service. Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...
  • Page 44 N O T E S www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 45 N O T E S Jazzy 1133 Owner’s Manual Rev B 03-03 www.pridemobility.com...
  • Page 46 N O T E S www.pridemobility.com Jazzy 1133 Owner’s Manual Rev B 03-03...
  • Page 47 Quality Control - 1133 Q u a l i t y C o n t r o l - M o d e l 1 400 Thank you for making the Pride Jazzy your choice in power chairs. We have thoroughly inspected your Jazzy. The following checkmarks indicate that it has been test driven and inspected.
