- Page 1 EDGEWINDER OWNER’S MANUAL PAGE 1 OWNER’S MANUAL THE EDGEWINDER Propane Edger WWW.AZTECPRODUCTS.COM 800-331-1423 * 201 COMMERCE DRIVE, MONTGOMERYVILLE, PA 18936 05-2017...
-
Page 2: Table Of Contents
EDGEWINDER OWNER’S MANUAL PAGE 2 TABLE OF CONTENTS TABLE OF CONTENTS PG 2 INTRODUCTION PG 3 GENERAL SAFETY MESSAGE INFORMATION PG 3 IMPORTANT SAFETY INSTRUCTIONS PG 4 GENERAL OPERATION SAFETY INFORMATION PG 4-5 STORAGE AND HANDLING SAFETY INFORMATION PG 6... -
Page 3: Introduction
All information in this Owner’s Manual is up to date and based on the latest product information available at the time of printing. Aztec Products, Inc. reserves the right to make changes at any time without notice or incurring obligation. This Owner’s Manual and the maintenance log must be kept as a permanent part of the machine and remain with the machine if resold. -
Page 4: Important Safety Instructions
Observe the following safety messages to get the best performance, lowest emissions, and longest life out of your equipment. The EPA has rated the PurePower by Aztec 603cc engine cleanest in the industry for CO (carbon monoxide) emissions. - Page 5 EDGEWINDER OWNER’S MANUAL PAGE 5 Operate only in well ventilated areas. Buildings must be provided with: A continuous mechanical ventilation that removes the products of combustion to the outdoors of not less than 300 CFM for each 10,000 BTUH or fraction thereof; or Natural ventilation of not less than 300 CFM for each 10,000 BTUH input or fraction thereof, based on a maximum of one-quarter air exchange per hour for the net building volume.
-
Page 6: Storage And Handling Safety Information
A “NO SMOKING” sign should be permanently displayed at the storage area. RETAILER/DISTRIBUTOR CONTACT INFO PURCHASE DATE: DISTRIBUTOR NAME: DISTRIBUTOR PHONE NUMBER(S): PROTECT YOUR WARRANTY! Read carefully; all questions regarding the care and safety of this equipment, please call AZTEC PRODUCTS: (800) 331-1423 05-2017... -
Page 7: Maintenance Safety Information
Tilting the machine back will result in a very unstable and dangerous situation. In order to service or clean the Edgewinder, while standing in operator’s position, gently tilt and lay down the machine on its RIGHT side. -
Page 8: Safety Label Locations
Do not run the engine without adequate ventilation. Do not remove machine/engine labels and/or WARNING stickers on machine or engine. If any labels or stickers come lose, call Aztec at (800) 331-1423 for replacement. 05-2017... -
Page 9: Before Operation Checklist
EDGEWINDER OWNER’S MANUAL PAGE 9 BEFORE OPERATION CHECKLIST For your safety, to ensure compliance with environmental regulations, and to maximize the service life of your equipment, it is very important to take a few minutes before you operate this machine to check its condition. - Page 10 EDGEWINDER OWNER’S MANUAL PAGE 10 E. CHECK THE ENGINE OIL Make sure the machine is level when checking the oil. Always take two (2) readings of the dipstick before adding oil. If the oil level is below the full mark, add just enough oil to the engine to bring the oil level up to the full mark.
-
Page 11: Starting The Engine
EDGEWINDER OWNER’S MANUAL PAGE 11 STARTING THE ENGINE Understand the operation of all controls and learn how to stop the engine quickly in case of emergency. Although this HONDA engine is equipped with a catalytic muffler for safety, its exhaust still contains small amounts of poisonous carbon monoxide. -
Page 12: Control Lever
Easily cuts through layers of edge build up. No other application of this equipment should be attempted nor is recommended. Call Aztec (800) 331-1423 for any additional application questions. First, refer to the SAFETY INFORMATION on pgs 3-8, and complete the BEFORE OPERATION CHECKLIST on pgs 9-10. -
Page 13: Getting Started - Edgewinder
EDGEWINDER OWNER’S MANUAL PAGE 13 Engine speed not to exceed 3400 RPM. High and low idle speeds may vary depending on the equipment on which the engine is used. Refer to the equipment specifications. This machine is not suitable for picking up hazardous dust. -
Page 14: Transporting The Edgewinder
Remove the propane tank from the machine, or disconnect the connection and securely fasten tank to machine. Pull the Edgewinder in reverse or push forward by raising brush off floor. EDGEWINDER CLEAN UP First, refer to the SAFETY INFORMATION on pgs 3-8. Once the job is complete for the day/night, clean up is required. -
Page 15: Storing The Machine & Propane Tanks
EDGEWINDER OWNER’S MANUAL PAGE 15 STORING THE MACHINE AND PROPANE TANKS Once the job is complete for the day/night, remove the propane tank from the machine and store the tank in a well ventilated approved area. Complete the MACHINE CLEAN UP list on pg 14. -
Page 16: Engine Oil & Maintenance
EDGEWINDER OWNER’S MANUAL PAGE 16 ENGINE OIL AND MAINTENANCE Hot engine oil can cause severe burns. Allow engine temperature to drop from hot to warm level before attempting to remove oil filter. Check the engine oil daily before starting the engine, otherwise shortage of the engine oil may cause serious damage to the engine such as seizure. -
Page 17: Recommended Oil
EDGEWINDER OWNER’S MANUAL PAGE 17 RECOMMENDED OIL Oil is a major factor affecting performance and service life of your engine. Use 4-stroke automotive detergent oil that meets or exceeds the requirements for API service classification SJ or later equivalent. Always check the API service label on the oil container to be sure it includes the letters SJ or later (or equivalent). -
Page 18: Oil Change
EDGEWINDER OWNER’S MANUAL PAGE 18 OIL CHANGE First, review to the HONDA ENGINE MAINTENANCE SCHEDULE on pgs 22-23. It is important to follow these guidelines to protect your engine. Drain the used oil when the engine is warm. Warm oil drains quickly and completely. To change the oil, follow these steps: 1.) Stop the engine and make sure the machine is... -
Page 19: Oil Filter Change
EDGEWINDER OWNER’S MANUAL PAGE 19 OIL FILTER CHANGE (IF EQUIPPED) Change the oil filter every 100 hours of operation. Before removing the oil filter, place a suitable pan under filter connection. 1.) Drain engine oil into a suitable container. 2.) Rotate the oil filter (A) counterclockwise to remove it. -
Page 20: Air Cleaner
EDGEWINDER OWNER’S MANUAL PAGE 20 AIR CLEANER A dirty air cleaner will restrict air flow to the carburetor, reducing engine performance. If you operate the engine in very dusty areas, clean the air filter more than specified in the MAINTENANCE SCHEDULE on pg 22. -
Page 21: Spark Plug
EDGEWINDER OWNER’S MANUAL PAGE 21 SPARK PLUG An incorrect spark plug can cause engine damage. For good performance, the spark plug must be properly gapped and free of deposits. Recommended Spark Plugs: BPR5ES (NGK) The recommended spark plug is the correct heat range for normal engine operating temperatures. -
Page 22: Honda Engine Maintenance
EDGEWINDER OWNER’S MANUAL PAGE 22 HONDA ENGINE MAINTENANCE Consistent maintenance is essential for safe, economical and trouble-free operation. It will also help reduce pollution. Improper maintenance, or failure to correct a problem before operation, can cause a malfunction in which you can be seriously hurt or killed. Always follow the inspection and maintenance recommendations and schedules in this Owner’s Manual. -
Page 23: Maintenance Schedule
EDGEWINDER OWNER’S MANUAL PAGE 23 ENGINE MAINTENANCE SCHEDULE REGULAR SERVICE PERIOD (3) Each First Every 3 Every 6 Every Refer to Owner’s Perform at every indicated month or operating Month months Months Year interval, whichever comes first. or 50 or 100... -
Page 24: Engine Troubleshooting
EDGEWINDER OWNER’S MANUAL PAGE 24 ENGINE TROUBLESHOOTING COMMON PROBLEMS & PROBABLE CAUSES SOLUTIONS * ENGINE WILL NOT START: Check battery Battery may be discharged; recharge battery Check engine oil Engine oil level may be low; fill with recommended oil to the proper level (see pgs 16-19) -
Page 25: Electrical Troubleshooting
EDGEWINDER OWNER’S MANUAL PAGE 25 TROUBLESHOOTING THE ELECTRICAL SYSTEM Always wear a face shield, safety glasses and protective clothing when working around a battery. The gases can be explosive and the acid is highly corrosive to metals, cloth and ALL HUMAN TISSUE (skin, eyes, etc.). -
Page 26: Technical & Consumer Information
EDGEWINDER OWNER’S MANUAL PAGE 26 TECHNICAL AND CONSUMER INFORMATION BATTERY CONNECTIONS FOR ELECTRIC STARTER Use a 12-volt battery with an ampere-hour rating of at least 18 Ah. Be careful not to connect the battery in reverse polarity, as this will short circuit the battery charging system. Always connect the positive (+) battery cable to the battery terminal before connecting the negative (–) battery cable, so... - Page 27 The control is provided with a hole for cable attachment. Install a solid wire cable as shown below. Do not use braided wire cable. EMISSION CONTROL SYSTEM INFORMATION Aztec utilizes lean carburetor settings and other systems to reduce the emissions of carbon monoxide, oxides of nitrogen, and hydrocarbons. The U.S., California Clean Air Acts and Environment Canada EPA, California and Canadian regulations require all manufacturers to furnish written instructions describing the operation and maintenance of emission control systems.
- Page 28 EDGEWINDER OWNER’S MANUAL PAGE 28 Tampering and Altering Tampering with or altering the emission control system may increase emissions beyond the legal limit. Among those acts that constitute tampering are: • Removal or alteration of any part of the intake, fuel, or exhaust systems.
-
Page 29: Edgewinder Quick Start Guide
EDGEWINDER OWNER’S MANUAL PAGE 29 AZTEC EDGEWINDER QUICK START GUIDE 1.) Read, understand and observe all important 5.) Open the LPG tank by turning the knob (B) SAFETY INSTRUCTIONS before operating counter-clockwise. the machine (see pgs 3-8). 6.) Set throttle lever (C) to idle SLOW position 2.) Complete the BEFORE OPERATION... -
Page 30: Edgewinder Repair Parts
EDGEWINDER OWNER’S MANUAL PAGE 30 AZTEC EDGEWINDER REPAIR PARTS ITEM # DESCRIPTION PART # THROTTLE CABLE 212-1 IDLER SPRING 173-7599-DWG GUIDE WHEEL 156-PB-03041-08 3 1/2 SWIVEL CASTER 156-2-3056-445 CENTRIFUGAL CLUTCH 311-160015 BELT 113-L568 IDLER ASSEMBLY 017-600I V IDLER 188-V42B SPLASH STRIP BRACKET... -
Page 31: Warranty
Engine tune up parts Aztec Products, Inc. warrants its products to be free from defects in material and workmanship for a period of one year from the date of sale. All engines are warranted by the manufacturers (Honda) for a period of two years when engine maintenance schedules are followed.
