DSC PC5020 Installation Manual

DSC PC5020 Installation Manual

Power864 security system
Hide thumbs Also See for PC5020:
Table of Contents

Advertisement

Quick Links

See also: User Manual
IMPORTANT
WARNING:This manual contains information on limitations regarding product use and function and informa-
tion on the limitations as to liability of the manufacturer. The entire manual should be carefully read.
Installation
Manual
®
PC5020 Version 3.1
DLS-3 v1.3 and higher

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC5020 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DSC PC5020

Summary of Contents for DSC PC5020

  • Page 1: Installation Manual

    WARNING:This manual contains information on limitations regarding product use and function and informa- tion on the limitations as to liability of the manufacturer. The entire manual should be carefully read. Installation Manual ® PC5020 Version 3.1 DLS-3 v1.3 and higher...
  • Page 3 See Section [018] Option 2&3, Sixth System Option Codes, Verbal Door Chime and Verbal Alarm, Pg 32. See associated Installation Manuals. Fast Loop Response by The PC5020 v3.1 can configure any or all onboard zones for 36 ms Loop Response. See Section [030] Zone - Fast Loop Response, Pg 33...

  • Page 5: Table Of Contents

    Table of Contents Section 1: Introduction Viewing Programming ..........11 About the Power864 System ........1 Section 4: Keypad Commands About the Power864 Manual Set ......... 1 Access Codes .............. 12 Main Panel Specifications ..........1 Arming and Disarming ..........13 Additional Devices ............
  • Page 6 PC5020 Wiring Diagram...

  • Page 7: Section 1: Introduction

    • Three low current (50 mA) PGM outputs on main panel (PGM1, PGM3, PGM4) The PC5020 main board comes with 4 programmable outputs, and you can add up to 12 more using PC5204 and PC5208 • One high current (300 mA) PGM output with 2-wire smoke modules.

  • Page 8: Additional Devices

    Escort5580 Installation Manual for details.) • PC5508Z: 8 zone LED keypad, with one zone input NOTE: Please see the PC5020 Module Compatibility Chart on the back cover for compatible versions. • PC5532Z: 32 zone LED keypad, with one zone input •...
  • Page 9 DLM-4L v1.0 Video Transmis- • HS-CAB200 structured wiring cabinet for PC5020 main panel. sion module and the PC5020 control panel. The PC5108L is also Dimensions are 362mm x 362mm x 102mm / 14.25” x 14.25”...

  • Page 10: Section 2: Installation And Wiring

    Section 2: Installation and Wiring The following sections provide a complete description of how to wire and configure devices and zones. 2.1 Installation Steps Step 10 Programming the System (Sections 4 & 5) Section 4.0 provides a complete description of how to program The following steps are provided to assist with the installation of the panel.

  • Page 11: Keybus Operation And Wiring

    • PC5532Z Keypad: 85 mA • PC5516Z Keypad: 85 mA • PC5508Z Keypad: 85 mA For example, if you are installing a PC5020 with a LINKS1000/ • PC5108 Zone Module: 35 mA GSM1000 and a PC5936 Intercom module, connect the incom- •...

  • Page 12: Assigning Zones To Zone Expanders

    3.0 A. jumpers so the panel can determine the correct zone assignment. Short Term. Available only with stand-by bat- tery connected. NOTE: Please see the PC5020 Module Compatibility Chart on the PC5200 VAUX: 1.0 A. back cover for compatible versions.

  • Page 13: Keypad Assignment

    8. Do not assign more than one keypad to the [21] PC5936 same slot. [22] LINKS2X50/Skyroute™ NOTE: Please see the PC5020 Module Compatibility Chart on the [23] DLM-4L v1.0 back cover for compatible versions. [24] Escort5580 1. Enter Installer Programming...
  • Page 14 11200Ω (contact open) Violated ANY Z ANY COM ANY Z ANY COM TERMINAL TERMINAL TERMINAL TERMINAL End-of-Line Resistors ... . . Section [013], Option [1] Double End-of-Line Resistors ..Section [013], Option [2] Fire Zone Wiring - 4-wire Smoke Detectors All zones defined as Fire (see section 5.3 Basic Programming on page 20) must be wired according to the following diagram:...

  • Page 15: Keypad Zones

    I n s t a l l a t i o n a n d W i r i n g : 2 . 1 0 K e y p a d Z o n e s LINKS1000 Answer keypad circuit board. Connect the four Keybus wires from the If the LINKS1000 cellular communicator is being used a zone control panel: the red wire to R, the black to B, the yellow to Y may be configured for LINKS1000 Answer to allow download-...

  • Page 16: Section 3: How To Program

    Section 3: How to Program 3.3 Programming Hexadecimal Data The following section of the manual describes how to enter Installer Programming and how to program the various sections. On occasion, hexadecimal (HEX) digits may be required. To pro- NOTE: It is extremely important that you read the following sec- gram a HEX digit press the [*] key.

  • Page 17: Viewing Programming

    3.5 Viewing Programming LED and LCD5501Z Keypads Any programming section can be viewed from an LED or LCD5501Z keypad. When a programming section is entered, the keypad will immediately display the first digit of information pro- grammed in that section. The keypad displays the information using a binary format, according to the following chart: See Hex data...

  • Page 18: Section 4: Keypad Commands

    Section 4: Keypad Commands Use any system keypad to enter commands, or to program the Power864 security system. The LED (PC55XX) and LCD5501Z keypads use function and zone indicator lights to represent alarm functions and status. The LCD5500Z keypad provides a written description on the display and uses function indicator lights to communicate alarm status to the user.

  • Page 19: Arming And Disarming

    4.4 “Function Keys”). If the Event Buffer Follows Swinger Shutdown feature is NOTE: The PC5020 has a built-in feature called Audible Exit Fault. enabled the event buffer will not store events after the swinger (See Section 5.3 Basic Programming PWS Sect 3 [001]-[004] for...

  • Page 20: Commands

    • Step 2 - Select ‘View Event Buffer’ bypass group. To program a bypass group, in the [*][1] menu, select the zones to be bypassed. Press [95] to save the group. The keypad will display the Event Number, Partition, Time and To recall the group, press [*][1] followed by [91].
  • Page 21 (24 hour zones). Instructions on viewing alarms in hour format (i.e. enter a 4-digit number in [hhmm] format). memory are located in the PC5020 Instruction Manual (“Disarm- The system will return you to the day selection menu. Scroll to ing the System”).

  • Page 22: Function Keys

    4.4 Function Keys • Contrast Control: When this option is selected the keypad There are five function keys on the PC5020 keypads labelled will allow you to scroll through 10 different contrast level Stay, Away, Chime, Reset and Exit. The operation of these keys is options.
  • Page 23 K e y p a d C o m m a n d s : 4 . 4 F u n c t i o n K e y s the partition when the exit delay expires (see section [*] [9] [16] - [*]+[0] Quick Exit Arming Without Entry Delay on page 16).

  • Page 24: Global And Partition Keypad Operation

    4.5 Global and Partition Keypad Operation A global keypad will display limited information until a partition is selected: the Trouble light will turn on if a trouble condition is present, and the Armed light will turn on if all the partitions are armed.

  • Page 25: Section 5: Programming Sections

    Opening/Closing Communicator Call Directions Restore PC5132 to Factory Default Programming System Maintenance Communicator Call Directions Restore PC5400 to Factory Default Programming System Test Transmissions Communicator Call Directions Restore PC5936 to Factory Default Programming Communication Variables Restore PC5020 to Factory Default Programming...

  • Page 26: For The Record

    5.1 For the Record 5.3 Basic Programming This Section identifies the Client, Installation Date, Installers [001]-[004] - Zone Definitions Code, Hardware configuration and Programming summary for These sections require 16 two digit entries. Each two digit num- each zone. Remove these pages and retain for reference. ber entered determines how a zone will operate.
  • Page 27 P r o g r a m m i n g S e c t i o n s : 5 . 3 B a s i c P r o g r a m m i n g [001]-[004] ZONE DEFINITIONS Option Zone Type Description...

  • Page 28: System Times

    Function Key Arming) the Exit Delay will be twice the programmed on the following devices: value (090-510 seconds). • PGM 1, PGM 2, PGM 3, and PGM 4 on the PC5020 main [09] Bell Cut-off: (001-255) Minutes board The Bell Cut-off for all 8 partitions is one entry.
  • Page 29 P r o g r a m m i n g S e c t i o n s : 5 . 3 B a s i c P r o g r a m m i n g [009] - [011] PROGRAMMABLE OUTPUT OPTIONS Option Output Description...
  • Page 30 [009] - [011] PROGRAMMABLE OUTPUT OPTIONS Option Output Description System Tamper This output will activate (switch to ground) when any Tamper condition is present and will deactivate when all Tamper conditions are cleared. These tampers include zone tampers (DEOL), 24 hour latching tamper zone type, module and keypad tampers.

  • Page 31: Keypad Lockout Options

    P r o g r a m m i n g S e c t i o n s : 5 . 3 B a s i c P r o g r a m m i n g [012] - Keypad Lockout Options The panel can be programmed to ‘lockout’...
  • Page 32 Section Option On/Off Description [013] - [018] SECOND SYSTEM OPTION CODES [013] Zone Loop Type Normally Closed Loops. All zones are wired as normally closed circuits with returns con- nected to a COM terminal. The end-of-line resistor is not required. An alarm will be gener- Option ated when the circuit is opened.

  • Page 33: Second System Option Codes 27

    P r o g r a m m i n g S e c t i o n s : 5 . 3 B a s i c P r o g r a m m i n g Section Option On/Off Description...

  • Page 34: Third System Option Codes

    Section Option On/Off Description [015] THIRD SYSTEM OPTION CODES Section Option On/Off Description [015] [F] Key [F] Key Enabled. Pressing and holding the [F] key for 2 seconds will generate a Fire alarm. The keypad will sound a set of 3 beeps to acknowledge the valid alarm and the bell Option or siren will pulse one second on, one second off if option 8 of Section [013] is disabled (Standard Fire option).

  • Page 35: Fourth System Option Codes

    NOTE: This option must be enabled when using a PC5132 v2.1 or earlier. NOTE: When using wireless keys with access codes, if you default the PC5020, you should also default the PC5132(See Section 5.9 Special Installer Functions PWS Sect 9 [996]).
  • Page 36 Section Option On/Off Description [017] Auto-Arm Schedule Pro- Auto-arm Schedule in [*][6]. The Auto-Arm Schedules (Sect [181] - [188]) are accessible gramming via [*][6] as well as Installer’s Programming. Option NOTE: Refer to “Setting Date and Time” in the User’s Guide. Auto-arm Schedule in Installer’s.

  • Page 37: Sixth System Option Codes

    When an audible non-fire zone goes into alarm with this feature is enabled, the PC5020 will sound the alarm condition via the Bell Outputs, but every 15 seconds (as programmed in the Alarm Tone Period –...
  • Page 38 Section Option On/Off Description [018] Burglary Verification Cross Zoning is Enabled. The panel will use the Cross Zone Attribute for Burglary Ver- ification. Option This feature requires two or more trips on a zone(s) specified as “cross zones” within a specified time before starting an alarm sequence.

  • Page 39: Advanced Programming

    P r o g r a m m i n g S e c t i o n s : 5 . 4 A d v a n c e d P r o g r a m m i n g [020] - Keypad Zone Assignment [030] - Fast Loop Response An eight bit toggle option controls which main board zones have...

  • Page 40: No Activity Arming Pre-Alert

    001-255, and the default value is 15 seconds. The default value is 007 attempts. Valid entries are 001-015. NOTE: The PC5020 will not allow more than 15 dialing attempts [181]-[188] - Auto Arm Schedules to a single phone number. If a value higher than 15 is pro- Sections [181] through [188] allow the Installer to program seven grammed in Section [165], the panel will still only dial 15 attempts.

  • Page 41: Partition And Zone Programming

    5.5 Partition and Zone Programming Telephone numbers can be up to 32 digits which will allow you to add special digits if required. To program the telephone num- [202]-[265] - Partition Zone Assignments ber enter numbers 0 through 9 as required. Partitions and Zone Assignment Pressing [#] in these sections from an LED keypad will exit and A partition is a limited area of the premises which will operate...
  • Page 42 This account code can be up to six digits in length for the SIA Communications format. Only SIA supports six digit account codes. If the last two digits of the account code are FF, the panel will only use the first four dig- its.

  • Page 43: Miscellaneous Alarm Reporting Codes

    [320]-[349] REPORTING CODES Option Report Code Description [320]-[327] ZONE ALARMS & ALARM RESTORE [320]-[327] Zone Alarms & Alarm These reporting codes are used by the communicator to transmit zone alarms and restores for zones Restores 1 to 64. These codes are sent to the Alarm & Restore call direction group of the Partition. [328] MISCELLANEOUS ALARM REPORTING CODES Duress Alarm This reporting code will be transmitted to the monitoring station whenever a Duress code is used to...
  • Page 44 [320]-[349] REPORTING CODES Option Report Code Description Special Closing If the system is closed (armed) using any of the following methods, this reporting code will be trans- mitted. “Armed in Stay Mode” or “Armed in Away Mode” will be logged for all closing types. •...

  • Page 45: Miscellaneous Closing (Arming) Reporting Codes

    • Aux Trouble (PC5020) • Bell Trouble (PC5020) • Module Supervisory • Ground Fault (PC5700) • TLM Trouble (PC5020, PC5700 Line 1-2) • FTC Trouble This reporting code is sent to the System Test Transmission Call Direction Group. Periodic Test The panel can send a Periodic Test Transmission Reporting Code at the programmed Test Trans- mission Time of Day (See section[378]).

  • Page 46: Communicator Format Options

    [320]-[349] REPORTING CODES Option Report Code Description 3, 4, 5, 6, PC5700 TLM Line 1/2 These codes are sent when a TLM Trouble/Restore occurs on the PC5700 Line 1 and 2. Troubles & Restore [350] - Communicator Format Options NOTE: Do not program the second telephone number for the SIA Communicator - Reporting Formats reporting code format (Section [360]) if the Automatic Reporting Code option is enabled (Section [381]).
  • Page 47 P r o g r a m m i n g S e c t i o n s : 5 . 6 C o m m u n i c a t o r P r o g r a m m i n g The panel will attempt to call the pager one time.
  • Page 48 • BPS Formats - 0 is not valid in Account or Rep Code (A must be used) • SIA - This format uses 300 Baud FSK as the communication media. The Account Code can be 4 or 6 hexadecimal digits in length, All reporting codes must be 2 digits in length.

  • Page 49: Communication Variables

    P r o g r a m m i n g S e c t i o n s : 5 . 6 C o m m u n i c a t o r P r o g r a m m i n g [377] COMMUNICATION VARIABLES [377] - COMMUNICATION VARIABLES Variable...

  • Page 50: Test Transmission Time Of Day

    [377] - COMMUNICATION VARIABLES Variable Description Delinquency Transmission Delay The value in this section determines the period of time that the Delinquency Event will be postponed until it is logged to the Event Buffer and transmitted. Whether this value is in hours or days is deter- mined if Delinquency is for Activity (hours) or Closing (days) as specified in Section [380] Option 8.

  • Page 51: First Communicator Option Code

    P r o g r a m m i n g S e c t i o n s : 5 . 6 C o m m u n i c a t o r P r o g r a m m i n g [380]-[382] COMMUNICATOR OPTION CODES [380] - FIRST COMMUNICATOR OPTION CODES Option...

  • Page 52: Second Communicator Option Code

    [381] - Second Communicator Option Codes [381] - SECOND COMMUNICATOR OPTION CODES Option Communicator Code On/Off Description Opening After Alarm Key- Opening After Alarm Keypad Ringback Enabled. When the Opening After Alarm pad Ringback reporting code is successfully transmitted to a programmed telephone number, the key- pad will sound a series of 8 beeps to confirm to the end user that the Opening After Alarm Code was sent and received.
  • Page 53 P r o g r a m m i n g S e c t i o n s : 5 . 6 C o m m u n i c a t o r P r o g r a m m i n g [382] - THIRD COMMUNICATOR OPTION CODES Option Communicator Code...

  • Page 54: Downloading Options

    Downloading Options Downloading If the User Initiated Call-Up option is enabled, the user can Downloading allows programming of the entire control panel via have the panel initiate a call to the downloading computer by a computer, modem and telephone line. All functions and fea- pressing [*][6][Master Code][6].

  • Page 55: Programmable Output Programming

    P r o g r a m m i n g S e c t i o n s : 5 . 8 P r o g r a m m a b l e O u t p u t P r o g r a m m i n g [401] - First Downloading Option Codes [401] - FIRST DOWNLOADING OPTION CODES Option...
  • Page 56 [551]-[564] PGM Partition Assignment) This field is supported by PGMs that have multiple partition The PC5020 has a 8-bit toggle field per output that determines capabilities (i.e. Command Outputs, Away Arming) It does not which partitions the output is assigned to (outputs PGM 1-14).

  • Page 57: International Programming

    P r o g r a m m i n g S e c t i o n s : 5 . 9 I n t e r n a t i o n a l P r o g r a m m i n g 5.9 International Programming [700] - Automatic Clock Adjust •...

  • Page 58: Module Programming

    [702] - Second International Options Code [702] SECOND INTERNATIONAL OPTION CODES Option International Code On/Off Description Pulse Dial Pulse Dialing Make/Break Ratio is 33/67 Pulse Dialing Make/Break Ratio is 40/60 Force Dial Force Dialing Enabled. If the first attempt by the panel to call the monitoring station fails to detect a dialtone, on every subsequent attempt the panel will dial regardless of the presence of dialtone.

  • Page 59: Special Installer Instructions

    P r o g r a m m i n g S e c t i o n s : 5 . 1 1 S p e c i a l I n s t a l l e r I n s t r u c t i o n s 5.11 Special Installer Instructions [903] MODULE SUPERVISION FIELD [901] - Installer Walk Test Mode Enable / Disable...
  • Page 60 When this section is successfully entered, all programming in the [993]-[999] FACTORY DEFAULTS PC5020 will be returned to the factory defaults. The program- On occasion it may be necessary to default the main control ming for the ESCORT, PC5132, PC5400 and PC59XX modules panel or one of the modules that can be connected.

  • Page 61: Appendix A: Reporting Codes

    R e p o r t i n g C o d e s Appendix A: Reporting Codes The following tables contain Contact ID and Automatic SIA for- SIA Format - Level 2 (Hardcoded) mat reporting codes. For more information on reporting code The SIA communication format used in this product follows the level 2 specifications of the SIA Digital Communication Standard formats and notes about individual reporting codes, (See Sec-...
  • Page 62 Opening (disarming) using one of the following methods: (4) AA OP-00 keyswitch, maintenance code, DLS software, wireless key [345]-[346] Battery Trouble/Rest. PC5020 battery is low/battery restored MA/R (3) A2 YT-00/YR-00 [345]-[346] AC Line Trouble/Rest. AC power to control panel is disconnected or interrupted/...
  • Page 63 P r o g r a m m i n g S e c t i o n s : 5 . 1 1 S p e c i a l I n s t a l l e r I n s t r u c t i o n s Table 3: SIA Format Automatic Zone Contact ID SIA Auto Rep...
  • Page 64 F C C C O M PL IA N CE S TATE M E N T CAUTION: Changes or modifications not expressly approved by Digi- the terminal equipment. Standard jacks shall be so arranged that, if the tal Security Controls Ltd. could void your authority to use this equip- plug connected thereto is withdrawn, no interference to the operation of ment.

  • Page 65: Limited Warranty

    They have multiple beams of detection and motion can only be detected Any products returned to DSC which have the Installer’s Lockout option enabled and exhibit no other prob- in unobstructed areas covered by these beams. They cannot detect motion which occurs behind walls, ceil- lems will be subject to a service charge.
  • Page 66 PC5020 Module Compatibility Compatible Module Comments PC5108 v2.x Fully compatible with Power864. PC5200 Fully compatible with Power864. PC5204 Fully compatible with Power864. PC5208 Fully compatible with Power864. PC5320 Fully compatible with Power864. LCD5500Z v3.X Fully compatible with Power864. LCD5501Z v2.x Fully compatible with Power864.
