1.1 Specifications

Control Panel Specifications

Flexible Zone Configuration:

• Six fully programmable zones

• Seven Access Codes: five User, one Master and a

second Master code

• Normally Closed, Single EOL, Double EOL

• 23 Zone Types, 6 Programmable Zone Options

Audible Alarm Output:

• Supervised Bell Output (current limited at 3 amps), 12 V

• Steady or Pulsed Output

EEPROM Memory: Does not lose programming or

system status on complete AC and Battery failure

Programmable Outputs:

• Two Programmable Voltage Outputs, 20

programmable options

- One High Current (300 mA) PGM output on main

panel

- One Low Current (50 mA) PGM output on main

panel

Powerful 1.5 Amp Regulated Power Supply:

• 550 mA Auxiliary Supply, 12 V

• Positive Temperature Coefficient (PTC) components

replace fuses

• Supervision for loss of AC Power, Low Battery

• Internal Clock Locked to AC Power Frequency

Power Requirements:

• Transformer = 16.5 VAC, 40VA

• Battery = 12 volt 4 Ah minimum rechargeable sealed

lead acid

Remote Keypad Specifications:

• Three Different Keypads Available:

- PC5506T 6 Zone LED Keypad

- LCD5500T Alphanumeric Keypad

- PC1575RK 6 Zone LED Keypad

• The PC5506T and LCD5500T keypads have 5 Fully

Programmable Function Keys and Tampers

• Connect up to 8 Keypads

• Four Wire (Quad) Connection to KEYBUS

• Built in Piezoelectric Buzzer

Digital Communicator Specifications:

• Supports Major Formats including SIA, Scantronics 4-8-1

Slot and Contact ID

• Event Initiated Personal Paging

• Three Programmable Phone Numbers

• Two Account numbers

• DTMF and Pulse Dialing

• DPDT Line Seizure

• Anti-jam Feature

• Split Reporting of Selected Transmissions to Each

Telephone Number

System Introduction

System Supervision Features

The PC1580 continuously monitors a number of possible

trouble conditions including:

• AC Power Failure

• Trouble by Zone

• Tamper by Zone

• Fire Trouble

• Telephone Line Trouble

• Failure to Communicate

• Low Battery Condition

• Bell Output Trouble

• Module Fault (Supervisory or Tamper)

• Loss of Internal Clock

• AUX Power Supply Fault

False Alarm Prevention Features

• Audible Exit Delay

• Audible Exit Fault

• Communication Delay

• Urgency on Entry Delay

• Quick Exit

Additional Features

• Auto Arm at Specified Time

• Keypad Activated Alarm Output and Communicator

Test

• All modules connect to the system via a four wire

KEYBUS up to 1000'/330m from main panel

• Event Buffer can be printed using PC5400 RS232 Serial

Interface module

• Supports the ESCORT 5580 Voice Prompt Module with

Automation/Lighting Control

• An Event Buffer which records the past 100 events with

both the time and date at which they occured

• Uploading and Downloading capability

• Local Downloading capability with the use of the

PC-LINK Adaptor

• Time compensation feature

1.2 Additional Devices

1.2.1 Keypads

A maximum of eight keypads can be connected to the

control panel and can be any combination of the following

listed.

• PC5506T 6 zone LED keypad with function keys and

tamper

• LCD5500T LCD keypad with function keys and tamper

• PC1575RK 6 zone LED keypad

1.2.2 ESCORT5580 Module

There are many benefits to adding the ESCORT5580 module

to a security system. The ESCORT5580 module will turn any

touch tone phone in the world into a fully functional keypad.

Imagine the security a customer would feel if they had the

ability to arm, disarm and check status of their alarm system

while at the office or on vacation.
