Your security system consists of a number of different components. One component is the DSC PC2000 control panel which will be mounted out of the way in a utility room or basement. In addition to the main control electronics, the _‘.
SYSTEMREFERENCE Zone Zone Type Protected Area Number Keypad Zone [1].[3] [ *].[#I Keypad Zone Master Code Number Programmed Code Numbers Monitoring Stalion Information A c c o u n t # Telephone # Notes PRINTED IN CANADA DIGITAL SECURITY CONTROLS LTD. COPYRIGHT 1966 1645 FLINT ROAD, DOWNSVIEW.
MASTER CODE The master security code is a 4 digit code which is supplied at the time of installation. The master code is entered from the keypad and is used for arming and disarming the security system, for programming additional security codes and for changing other features.
TROUBLE DISPLAY The PC2000 continuously monitors a number of possible trouble conditions. If one of these conditions occurs, the keypad ‘TROUBLE’ indicator will light. Press the [XC] then [2] keys to display the type of trouble. The ‘ZONE’ lights indicate the type of trouble condition.
Page 6
MEMORY light on means an alarm has occurred To display zone that caused ARMED light will come on alarm, press @I then &I. indicating system armed. Zone light will come on Ensure READY light on, indicating which zone enter 4 digit code. caused alarm.
Press [#] to return to ‘READY’. SETTING AUTOMATIC ARMING TIME The PC2000 can be programmed to automatically arm each day at the same lime. To set the lime, enter (~1, (61 and a (4 digit security code]. Then enter any [two digits] (from 01 to 23) for the number of hours until arming is to take place.
Page 8
3 times. The “QUICK-ARM” feature allows entering [*I then [O] to arm the PC2000 in place of a [4 digit code]. [x] [0] will not disarm the PC2000. Pressing [4] again will turn off “QUICK-ARM”. The sounder will give one long beep.
AUTO-TEST TRANSMISSION The PC2000 can be programmed, at the time of installation, to send a test code to the monitoring station at regular intervals. The frequency and time of test transmissions is set by the monitoring station and should not be changed without their knowledge.
LIMITED WARRANTY Digital Security Controls Ltd. warrants that for a period of twelve months from the date of purchase, the product shall be free of defects in materials and workmanship under normal use and that in fulfillment of any breach of such warranty, Digital Security Controls Ltd.
