Dealer Manual
Greens King
62302 – 16 HP Briggs & Stratton
62305 – 16 HP Briggs & Stratton
Greens King
with ROPS
62303 – 18 HP Briggs & Stratton
62304 – 17.7 HP Kubota
62306 – 18 HP Briggs & Stratton
62379 – 17.7 HP Kubota
WARNING
Warning: If incorrectly used, this machine can
cause severe injury. Those who use and maintain
this machine should be trained in its proper use,
warned of its dangers, and must read the entire
manual before attempting to set up, operate, adjust,
or service the machine.
GB
IV with ROPS
™
IV Plus
™
®
®
®
®
This manual is designed to assist dealer
personnel with the proper set up and
preparation of the equipment prior to
delivery to the customer. You may wish to
keep a copy in your customer file.
Do Not Remove the Safety & Operation
Manual or Parts & Maintenance Manual
from the mower.
For additional information not included in
®
this manual, refer to your office copy of:
• The Safety & Operation Manual
• The Parts & Maintenance Manual
®
Use the pre-delivery checklist provided on
the inside back cover of this manual. You
may wish to provide a copy to the
customer upon delivery of the unit.
4190462-Rev D
Dealer
Advertisement
Table of Contents
Related Manuals for Jacobsen Greens King IV 62302
Summary of Contents for Jacobsen Greens King IV 62302
- Page 1 4190462-Rev D Dealer Manual Greens King IV with ROPS ™ Dealer ® 62302 – 16 HP Briggs & Stratton ® 62305 – 16 HP Briggs & Stratton This manual is designed to assist dealer personnel with the proper set up and preparation of the equipment prior to delivery to the customer.
-
Page 2: Table Of Contents
FOREWORD This manual contains safety and operating instructions The serial plate is attached to the frame near the battery. for your new Jacobsen machine. This manual should be Jacobsen recommends you record these numbers below for easy reference. stored with the equipment for reference during operation. -
Page 3: Safety
20. Operate the machine up and down the face of slopes the job. Only use accessories and attachments (vertically), not across the face (horizontally). approved by Jacobsen. 21. To prevent tipping or loss of control, do not start or stop Stay alert for holes in the terrain and other hidden suddenly on slopes. -
Page 4: Important Safety Notes
Adjustments and maintenance should always be performed by a qualified technician. If additional information or service is needed, contact your authorized Jacobsen Dealer who is kept informed of the latest methods to service this equipment and can provide prompt and efficient service. -
Page 5: Controls
CONTROLS CONTROLS ICONS ___________________________________________________________________ Read Manual Engine Throttle Parking Brake Service Foot Brake Engaged Disengaged Fast Slow Fuse Reel Rotation Hour Meter Fuel Forward Reverse Engine Traction Lever Choke Start Headlight Transport Neutral Reverse WARNING Never attempt to drive the mower unless you have read the Safety and Operation Manual and know how to operate all controls correctly. - Page 6 CONTROLS Reel Control Levers Choke Parking Brake Lever Accelerator Pedal Traction Lever Brake Pedal Volt Meter Mow/Lift Pedal Ignition Switch Hour Meter Mechanics (Backlap) Switch Seat Control Lever Light Switch (Optional) W Hydraulic Cap/Dipstick Fuse, Lights (Optional) Fuel Cap Fuse, Charging Circuit Fuse, Interlock System Parking Brake Light Engine Oil Pressure Light...
-
Page 7: Control Descriptions
CONTROLS CONTROL DESCRIPTIONS __________________________________________________ A. Reel Control Levers - Used to operate the cutting M. Engine Oil Pressure Light - Indicator will light if engine oil pressure drops below a safe level. Stop units. Push lever(s) forward for forward rotation. Pull lever(s) back for Reverse rotation. -
Page 8: Set-Up 3.1 General
SET-UP SET-UP GENERAL________________________________________________________________ The set-up and initial testing of the unit should always be Accessories not included with this product must be performed by a trained technician, familiar with the ordered separately. See instructions provided with operation of the equipment. accessory for installation and parts. -
Page 9: Torsion Springs
SET-UP TORSION SPRINGS ________________________________________________________ 1. Slide one clamp (F) over each lift arm and secure with 5/16-18 x 1-1/4” carriage bolt and 5/16-18 locknut (G and E). Do not tighten. 2. Slide the right (J) and left (H) torsion spring over their respective lift arms. -
Page 10: Steering Wheel
SET-UP STEERING WHEEL ________________________________________________________ 1. Remove hex jam nut (R) from steering column. 2. Position the steering wheel over the shaft then reassemble the hex jam nut. Torque nut to 25-30 ft. lb. (34-41Nm) and install the steering wheel cap (S). Figure 3E ROPS ___________________________________________________________________ The ROPS mounting bracket (Y) has been assembled to... -
Page 11: Fuel Hose Routing
SET-UP FUEL HOSE ROUTING______________________________________________________ Gas Units Only 1. Remove temporary hose from fitting in top right corner of tank to rollover valve. 2. Assemble goose neck tube (BA) to right side ROPS tube using four clamps (BB) and #10-24 x 1/2” thread cutting screws (BC). -
Page 12: Operating Checks
SET-UP 3.12 OPERATING CHECKS ______________________________________________________ After the initial inspection and set-up of reels and 3. Operate traction pedal and check that tractor accessories, test the tractor and implements for proper operates smoothly in both directions. Check that operation. tractor stops when traction pedal is released. 4. -
Page 13: Adjustments
ADJUSTMENTS ADJUSTMENTS GENERAL ________________________________________________________________ adjustment cannot be made, contact an authorized Jacobsen Dealer. WARNING 2. Replace, adjust, worn damaged To prevent injury, lower implements to the ground, components. disengage all drives, engage parking brake, stop 3. Long hair, jewelry, or loose fitting clothing may get engine and remove key from ignition switch before tangled in moving parts. -
Page 14: Bedknife Adjustment
ADJUSTMENTS BEDKNIFE ADJUSTMENT __________________________________________________ 1. Read Section 4.2 before making the adjustment. c. When the reel is properly adjusted to the bedknife, the reel will spin freely and you should 2. Start adjustment at the leading end of the reel, be able to cut a piece of newspaper, along the followed by the trailing end. -
Page 15: Reel Bearing
ADJUSTMENTS REEL BEARING ___________________________________________________________ Excessive end play or any radial play indicates bad bearings, a weak tension spring, or a backed off nut. 1. Check bearing housing mounting hardware. Tighten or replace components as required. Carefully clean 1-27/32 in. threads with degreaser. (46 mm) 2. -
Page 16: Leveling Procedure
ADJUSTMENTS LEVELING PROCEDURE____________________________________________________ 1. Lower the implements until they are about 1/4 in. (6.35 mm) above the ground. If they are not level with the ground, adjust torsion spring (Z). Clamp WARNING The torsion spring is under extreme tension and will tend to uncoil very rapidly if the clamp is loosened. -
Page 17: Parking Brake
ADJUSTMENTS 4.11 PARKING BRAKE__________________________________________________________ Disengage brake lever and measure the distance between nut (AB) and bottom of pivot. Adjust nut so the distance is 3/16 in. (5 mm). 3/16 in. (5 mm) GKV-13 Figure 4M 4.12 INTERLOCK SWITCHES ____________________________________________________ 1. Refer to the Interlock System check in your Safety & 3. -
Page 18: Traction Lever
ADJUSTMENTS 4.14 TRACTION LEVER _________________________________________________________ 1. Remove front cowling and adjust lever to align with the four positions on the instrument panel. 2. Adjust ball joints (AC) on rod (AD) and/or adjust position and number of washers (AE) for proper alignment. -
Page 19: Choke Control
ADJUSTMENTS 4.17 CHOKE CONTROL _________________________________________________________ 1. Push choke control knob to the OFF Position. 3. Adjust control wire (at the carburetor) then clamp wire housing in place while keeping choke butterfly 2. Set Choke lever at carburetor to OFF (butterfly open and the control knob in the OFF position. -
Page 20: Torque Specification
All torque values included in these charts are approximate and are for reference only. Use of these torque values is at your sole risk. Jacobsen is not responsible for any loss, claim, or damage arising from the use of these charts. -
Page 21: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING GENERAL ________________________________________________________________ The troubleshooting chart below lists basic problems that may occur during start-up and operation. For more detailed information regarding the hydraulic and electrical systems contact your area Jacobsen Dealer. Symptoms Possible Causes Action Engine will not start. -
Page 22: General
LUBRICATION CHART LUBRICATION CHART GENERAL________________________________________________________________ 2. Lubricate with grease that meets or exceeds NLGI Grade 2 LB specifications. Apply grease with a WARNING manual grease gun and fill slowly until grease begins to seep out. Do not use compressed air guns. Before you clean, adjust, or repair this equipment, disengage all drives, lower implements to the ground, 3. - Page 23 NOTES NOTES...
- Page 24 NOTES...
-
Page 25: Electrical System
