Low Level & Full Height Thermal Electric Radiator
Installation and Operation Guide
Type
Wattage
DPL 10
DPL 15
DP 450
DP 600
DP 900
DP 1200
DP 1500
DP 1800
ADVANCED ELECTRIC HEATING
Richmond DPL & DP
Models
No. of Fins
950
10
1425
15
450
600
900
1200
1500
10
1800
12
Size (WxHxD) (mm)
865
340
1265 340
3
310
575
4
390
575
6
550
575
8
710
575
870
575
1030 575
1
Net Weight (kg)
96
12.8
96
19.2
96
6.1
96
8.1
96
11.8
96
15.7
96
19.3
96
25.7
Advertisement
Table of Contents
Related Manuals for Ducasa Richmond DPL 15
Summary of Contents for Ducasa Richmond DPL 15
- Page 1 ADVANCED ELECTRIC HEATING Richmond DPL & DP Low Level & Full Height Thermal Electric Radiator Installation and Operation Guide Models Type Wattage No. of Fins Size (WxHxD) (mm) Net Weight (kg) DPL 10 12.8 DPL 15 1425 1265 340 19.2 DP 450 DP 600 DP 900...
-
Page 2: Installation
Installation Main Principles This appliance must be connected to a 230V 50Hz power supply. This appliance must be connected to a switched fused spur or a plug. Main installation must be provided by an omni- polar device where the distance between contacts must be a minimum of 3mm. Power Cord Wires = Neutral (Grey or Blue) Live (Brown) - Page 3 Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the applince in a safe way and understand the hazards involved.
-
Page 4: Electric Power
Directions for the Installer Installation should only be completed by a qualified professional. Electric Power The electrical circuits within your house should be of the correct type and size for the appliance wattage. We recommend that the fused spur outlet is placed 10cm to the right of the appliance and 15cm from the floor. - Page 5 Mark the appropriate location and fix the brackets in place with the supplied plugs and screws, ensuring the brackets are installed in the correct position (figure 2). Figure 2 Once the brackets have been installed the radiator can be hung from the supports (figure 3). To lock the radiators in place press on the ratchet and turn until a click is heard (figure 4).
-
Page 6: Operation
Operation The room temperature is controlled by the electronic thermostat in the control end placed at the side of the appliance. The thermostat has a precision of ±0.3ºC. Controller: Buttons and Symbols Switching On Once power has been supplied to the radiator it will initially be in the standby mode. Setting the Clock 1. - Page 7 Mode Change Press the Mode button to change between the mode screens shown below: Pilot Wire When in the pilot wire mode and if connected to a spate pilot wire controller the appliance can receive four type of control signal: 1.
-
Page 8: Programme Mode
Programme Mode The programme mode has three options; programme 1 and programme 2 are pre-set as shown below and programme 3 can be amended by the user. To select a programme, press the mode button until the programme mode is selected and use the time button to select P1, P2 or P3. - Page 9 Programming – Quick Guide Tip: Write down required times and modes before starting. Before we set the programme we must set the clock. When we programme we set the times for the comfort and economy modes to be in operation. Setting the mode's temperature is done seperately.
-
Page 10: General Description
The Remote Control (Optional) General Description The remote control communicates with the radiator using infra-red signal from a maximum distance of 10m from the appliance and requires 2x AAA batteries. ECO Button Temperature IR transmision (not compatible with Richmond DPL) ‘+’... -
Page 11: Low Battery Warning
IR Transmission Any alterations made using the remote control will be sent to the radiator via an IR signal after 1 second of inactivity. This can be seen by the IR transmission symbol flashing in the top right hand corner. Keypad lock This function allows the user to lock the keypad on the remote to avoid inadvertent changes. - Page 12 Civic Office, your household waste disposal service or the shop where you purchased the product. ADVANCED ELECTRIC HEATING UK Distributor of Ducasa Products: Heattend Products Ltd Web: www.heattend.co.uk Email: enquiries@heattend.co.uk...
