  • Page 1 TT05 Series DIGITAL TORQUE TESTERS User’s Guide...

  • Page 2: Table Of Contents

    Series TT05 Digital Torque Testers User’s Guide Thank you… Thank you for purchasing a Mark-10 Series TT05 digital torque tester, designed to measure bottle cap application and removal torque. With proper usage, we are confident that you will get many years of great service with this product. Mark-10 instruments are ruggedly built for both laboratory and industrial environments.

  • Page 3: Overview

    User’s Guide 1 OVERVIEW 1.1 List of included items Qty. Part No. Description MTT05-12 / Series TT05 digital torque tester MTT05-25 / MTT05-50 / MTT05-100 08-1026 Battery (inside the instrument) 09-1165 USB cable Resource CD (USB driver, user’s guides, MESUR...

  • Page 4: Power

    Series TT05 Digital Torque Testers User’s Guide 2 POWER The TT05 is powered either by an 8.4V NiMH rechargeable battery or by an AC adapter. Since these batteries are subject to self discharge, it may be necessary to recharge the unit after a prolonged period of storage.

  • Page 5: Home Screen And Controls

    Series TT05 Digital Torque Testers User’s Guide 4 HOME SCREEN AND CONTROLS 4.1 Home Screen Name Description Measurement – indicates clockwise direction direction – indicates counter-clockwise direction indicator These indicators are used throughout the display and menu. Peaks The maximum measured clockwise and counter-clockwise readings, or maximum measured 1 and 2 peaks, when 1...
  • Page 6 Series TT05 Digital Torque Testers User’s Guide Battery / AC Either the AC adapter icon or battery power icon will be shown, depending on adapter indicator power conditions. Refer to the Power section for details. High / low limit Correspond to the programmed set points. Indicator definitions are as follows: indicators –...

  • Page 7: Operating Modes

    Series TT05 Digital Torque Testers User’s Guide 5 OPERATING MODES Caution! In any operating mode, if the capacity of the instrument has been exceeded by more than 110%, the display will show “OVER” to indicate an overload. A continuous audible tone will be sounded (if beeps are enabled) until the MENU key has been pressed or the load has been reduced to a safe level.

  • Page 8: Set Points

    Series TT05 Digital Torque Testers User’s Guide DIGITAL FILTERS (1 = Fastest) Current Reading Displayed Reading 1024 Two filters are available: Current Reading – Applies to the peak capture rate of the instrument. Displayed Reading – Applies to the primary reading on the display. Available settings: 1,2,4,8,16,32,64,128,256,512,1024.

  • Page 9: Data Memory And Statistics

    Series TT05 Digital Torque Testers User’s Guide 8.3 Set Point Indicators When set points are enabled, the following indicators are shown to the left of the primary reading: – the displayed value is greater than the upper load limit (NO GO HIGH) –...
  • Page 10 Press ENTER to output data to an external device. The display will show, “SENDING DATA…”, then “DATA SENT”. If there was a problem with communication, the display will show, “DATA NOT SENT”. Saved data can be downloaded by some Mark-10 data collection programs. Refer to their respective user’s guides for details.

  • Page 11: Communications And Outputs

    It is recommended that the USB driver be installed before physically connecting the tester to the PC with a USB cable. For installation instructions, refer to the Mark-10 USB Driver user’s guide, supplied on the Resource CD or downloadable from www.mark-10.com.
  • Page 12 Series TT05 Digital Torque Testers User’s Guide Selection Description Numeric + Units Output format includes the value and unit of measure. Clockwise values have positive polarity, counter-clockwise values have negative polarity. Numeric Only Output format includes the value only. Polarity same as above. Invert Polarity Clockwise values have negative polarity, counter-clockwise values have positive polarity.
  • Page 13 Series TT05 Digital Torque Testers User’s Guide RS232/USB Output Outputs data via the serial and USB ports Outputs data via Mitutoyo (Digimatic) through the serial port Mitutoyo Output Memory Storage Stores a reading to memory (refer to the Memory section for details) Any combination of the above functions may be selected.

  • Page 14: Break Detection

    Series TT05 Digital Torque Testers User’s Guide 11 BREAK DETECTION 11.1 Configuration Three functions can be triggered automatically upon sample break or slip, defined as a programmable percentage drop in load from the peak: 1. Transmit the peak reading 2. Save the peak value to memory 3.

  • Page 15: First / Second Peak

    Series TT05 Digital Torque Testers User’s Guide 11.3 Auto Output Settings Select the output type. One or both output types may be enabled. The display will appear as follows: AUTO OUTPUT SETTINGS RS232/USB Output Mitutoyo Output Note: The same auto save/output/zero functions are available in First / Second Peak mode. Refer to the First / Second Peak section for details.
  • Page 16 Series TT05 Digital Torque Testers User’s Guide 12.2 Settings The display will appear as follows: PEAK SETTINGS Thresh. 1: 10 % % Drop 1: 50 % Thresh. 2: 10 % % Drop 2: 50 % Auto Zero Delay 5 sec. Sets the percentage of full scale at which the first/second peak detection Threshold 1 feature becomes active.

  • Page 17: Calibration

    Series TT05 Digital Torque Testers User’s Guide 11 CALIBRATION 11.1 Initial Physical Setup The TT05 should be mounted to a fixture rugged enough to withstand a load equal to the full capacity of the instrument. A groove located in the side of table has a diameter of 6.666” [169.32 mm], and may be used to accept a cable for calibration weights.
  • Page 18 Series TT05 Digital Torque Testers User’s Guide CALIBRATION OFFSET Please wait… CALIBRATION CALIBRATION OFFSET OFFSET Sen.Offset Adj.Passed Sen.Offset Adj.Failed Ana.Offset Adj.Passed Ana.Offset Adj.Failed If failed: 5. The following screen appears after the offsets have been calculated: CALIBRATION CLOCKWISE Attach necessary weight fixtures.
  • Page 19 Series TT05 Digital Torque Testers User’s Guide CALIBRATION CLOCKWISE GAIN ADJUST APPLY FULL SCALE LOAD 50.000 LBFIN +/-20% THEN PRESS ENTER Apply torque equal to the full scale of the instrument, then press ENTER. Remove the torque, leave the fixtures in place, then press ZERO. 9.

  • Page 20: Passwords

    Series TT05 Digital Torque Testers User’s Guide CALIBRATION Units must be kgFmm. PLEASE TRY AGAIN PRESS ENTER Displayed at the start of calibration if a disallowed unit is selected. LOAD NOT STABLE PLEASE TRY AGAIN Ensure that the load is not swinging, oscillating, or vibrating in any manner. Then try again. CALIBRATION CLOCKWISE LOAD TOO LOW...
  • Page 21 If the password has been misplaced, it can be reset. Press ENTER to generate a request code. The request code must be supplied to Mark-10 or a distributor, who will then provide a corresponding activation code. Enter the activation code to disable the password.

  • Page 22: Other Settings

    Series TT05 Digital Torque Testers User’s Guide 13 OTHER SETTINGS 13.1 Automatic Shutoff The tester may be configured to automatically power off following a period of inactivity while on battery power. Inactivity is defined as the absence of any key presses or load changes of 100 counts or less. To access these settings, select Automatic Shutoff from the menu.
  • Page 23 For available selections, refer to the Units and Home Screen And Controls sections. 13.6 Information / Welcome Screen The following screen is displayed at power-up and can be accessed at any time by selecting Information: Digital Torque Tester Series TT05 Model No: MTT05-50 Serial No: 1234567 Version: 1.0 (c) Mark-10 Corp.

  • Page 24: Specifications

    MTT05-12 12 x 0.005 192 x 0.1 1 x 0.0005 135 x 0.1 1.35 x 0.001 MTT05-25 25 x 0.01 400 x 0.2 2 x 0.001 290 x 0.2 2.9 x 0.002 MTT05-50 50 x 0.02 800 x 0.5 4 x 0.002...
  • Page 25 Series TT05 Digital Torque Testers User’s Guide 14.4 Factory Settings Parameter Setting Set points Upper Disabled (defaults to 80% of full scale, clockwise, when enabled) Lower Disabled (defaults to 40% of full scale, clockwise, when enabled) Filters Current Displayed 1024 DATA Key Functions RS-232/USB Output Enabled...
  • Page 26 Series TT05 Digital Torque Testers User’s Guide NOTES: Distributed by: ABQ Industrial LP USA Tel: +1 (281) 516-9292 / (888) 275-5772 eFax: +1 (866) 234-0451 Web: https://www.abqindustrial.net E-mail: info@abqindustrial.net...

This manual is also suitable for:

Mtt05-50Mtt05-12Mtt05-100
