User's
Manual
CA12E HANDY CAL
Settings for Use of CA12E in Fahrenheit
"."-
The default temperature read-out of the CAI2E is in Celsius ("C).
To change it to Fahrenheit ("F), it is necessar to proceed as fallows:
Changing the temperature unit setting to Fahrenheit
The following features are available depending on the settngs of the DIP switches above the battery
holder, which can be accessed by removing the cover from the back of the instrument.
SEE ALSO
For more information on DIP switches, see "Section 7. Other Features" of User's Manual
(1M CAl2E-OI E).
DIP switches
o~~~~
1 2
1: Reference junction compensation by the intemal RJ sensor
2: Temperature (Unit ofTemperature)
3: Setting of thermocouple standard (OFF: ITS90/0N: IPTS6B)
4: Disable automatic power off
7.2 Temperature (Unit of Temperature)
Use DIP switch 2 to select the unit of temperature.
OFF: °C
ON: OF
The conversion from Celsius to Fahenheit is performed using the equation
Fahenheit temperature = 1.8 X Celsius temperature + 32
YOKOGAWA +
Yokogawa Meters & Instruments Corporation
1M CA12E-S01E
1 st Edition Dec. 2006 (KP)
