Hardware Overview - D-Link DCS-4633EV User Manual

Section 1: Product Overview
2
1 Cover Screws
2 Protective Cover
3 Ethernet Port
4 Power Port
D-Link DCS-4633EV User Manual

Hardware Overview

1
These four screws can be removed with the included wrench.
Protects the camera lens assembly from the environment.
RJ-45 connector for Ethernet which can also be used to power the camera using Power over
Ethernet (PoE).
Connects to an optional 12 V / 1.5 A power adapter (not included).
3
4
7
