Advantech MIC-7420 Startup Manual

MIC-7420 Compact Fanless System with Intel
Gen Core™ i Processor
Startup Manual
Packing List
Before installing the board, please ensure that the following
items have been shipped:
1. MIC-7420 bare-bone system x 1
2. MIC-7420 Startup manual x1
3. MIC-7420 Driver CD x1
4. SATA cable 7P x2
5. SATA power cable 4P x1
6. SATA power cable 5P x1
7. HDD rubber x4
8. 2.5" HDD bracket x4
9. 2U rackmount ear x2
10. Handle bracket x2
If any of the above items are missing or damaged, please
contact your distributor or sales representative immediately.
Note: Adobe Acrobat Reader is required to view PDF
files. Adobe Acrobat Reader can be downloaded at www.
adobe.com/Prodindex/acrobat/readstep2.html (Acrobat is a
trademark of Adobe).
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://www.advantech.tw/support
This manual is for the MIC-7420 Series.
Part No. 2001742000
Printed in China
P/N: 2001742000
P/N: 2061223100
P/N: 1700008941
P/N: 1700017929
P/N: 1700022322-11
P/N: 1990001365
P/N: 1960018229N100
P/N: 1960018229N100
P/N: 1961613000S00G
1st Edition
Jan 2018
Specifications
Standard Functions
• Chip & Chipset: Intel Core™ i7-6822EQ/i3-6100E
processor with QM170 Chipset
• BIOS: AMI SPI 128 Mb
• Memory: Onboard 8GB DDR4-2133 and 1 x 260-pin
DDR4 SODIMM socket, maximum capacity up to 24GB
• Display:
Intel® HD Graphics 530, supports DirectX 12
• Dual display mode:
1 x DVI-I + 1 x DVI-D, supports resolutions up to
1920x1200@60Hz
• Storage:
- 2 x 3.5"HDD or 2 x 2.5"HDD
- 1 x 2260 size M.2 (M key with SATA signal only)
• Expansion slot:
- 2 x PCI slot
- 2 x PCIe x4 slot
- 1 x Mini PCIe slot
System Specifications
• Ethernet: 2 x 10/100/1000Mbps
• USB: 2 x USB3.0, 6 x USB2.0
• DVI: 1 x DVI-D, 1 x DVI-I
• Serial port: 2 DB9 ports, supports RS-232/422/485 with
2.5KV Isolation protection
• Audio: 1 x Speaker out (supports 4W Amp),1 x Mic-in
• PS/2 : 1 x PS/2 connector for KB/MS
Mechanical and Environment
• Dimensions (W x H x D): 427 x 88 x 325 mm
• Voltage input: AC 100-240 or DC 110V
• Working temperature:
0~40°C with HDD & add-on card
-20~40°C with SSD & add-on card
-20~60°C with SSD only
• Weight: 7.7kg (16.98 lb)
6
® th
MIC-7420 Startup Manual 1
